- Page 1 SUPER SLAM OVER DOOR A S S E M B L Y I N S T R U C T I O N S Model: PASOTD23 REV 8/22/23 support@popashot.net www.popashot.net...
- Page 2 Warranty As described in and as limited by this Warranty, Pop-A-Shot Enterprise, LLC (the “Company”) warrants this product to be free from defects in workmanship and materials for a period of 90 days from the date of original purchase. The term defects shall mean any imperfections that impair the use of the product.
- Page 3 PLEASE READ THIS PAGE It’ll only take a minute and will save you time! BEFORE PUTTING TOGETHER YOUR GAME We strongly recommend scanning the QR code here (or going to www.popashot.net/qr-otd) to visit the Super Slam Over The Door Game Hub. Here you’ll find a wealth of resources to get the most out of your game, including: •...
- Page 4 PARTS, HARDWARE & ACCESSORIES Backboard Instruction Part ID# Part Name Part # Part Image Step Used In Part Quantity OTD371 OTD321 STEPS 1-3 STEPS 2-4 Rim Plate Door Hook Scoreboard & Sensors OTD322 OTD001 OTD200 STEP 2 STEP 1 PRE-ATTACHED Basketball Rim Bolt OTD331...
- Page 5 STEP 1 ID# Name Qty. Backboard Door Hook Door Hook Bolt Attach the two (#4) Door Hooks to the top of the (#1) Backboard using the four (#11) Door Hook Bolts. Tighten these bolts with the Allen Wrench. PAG E support@popashot.net www.popashot.net...
- Page 6 STEP 2 Attach the (#2) Rim ID# Name ID# Name Qty. Qty. to the front of the (#1) Backboard with Backboard Backboard three (#8) Rim Bolts. Door Hook Bolt Rim Plate Rim Bolt Rim Nut Washer FRONT VIEW REAR VIEW While holding the (#8) Rim Bolts in place, flip over the (#1) Backboard and place the (#3) Rim Plate in place.
- Page 7 STEP 3 ID# Name Qty. Backboard Gently pull the (#2) Rim down from its folded position by grabbing the front with one hand and the Rim Lock with the other. When the (#2) Rim is level, pull the Rim Lock down so that it is Note: To fold the (#2) Rim back up, gently pull the (#2) touching the (#1) Backboard.
- Page 8 STEP 5 ID# Name Qty. Scoreboard Basketball Unscrew the back of the (#5) Scoreboard with your Allen Wrench, and add three AAA batteries (not included). Then pump up your two (#7) Basketballs using the provided Ball Pump. STEP 6 Hook the game over a door, turn it on, and you’re ready to slam and score!
