- Page 1 HOME | SINGLE SHOT OWNERS MANUAL SKU #: PASHOM18-01 www.Pop-A-Shot.net...
- Page 2 There you’ll find more hints and hacks to help you put together your new game. We hope you love your Pop-A-Shot and will let your friends and family (and any review sites) know how you feel. If you do have a problem (and it happens), please let us know first and give us a chance to fix it.
- Page 3 Side Arm Forward Tube Diagonal Tube Back Board Scoreboard Adapter Screws Ball Return Ramp Bolt Balls Pump Extra Long Bolt Bolt Short Bolt Medium Bolt Shorter Bolt Washer Wrench Allen Wrench WWW.POP-A-SHOT.NET Pop-A-Shot Home | Single Shot Page 3/15 SKU# PASHOM18-01...
- Page 4 Insert the Board Tubes (#2) into the Base Tubes (#3) (Fig. 2A). STEP 2 Hole Note: The upper holes on the Board Tubes (#2) should face forward. Hole Fig. 2A WWW.POP-A-SHOT.NET Pop-A-Shot Home | Single Shot Page 4/15 SKU# PASHOM18-01...
- Page 5 Connector Tube (#5) using the Medium Bolt (#26), two Washers (#28) and a Nut (#30) (Fig. 4B). Tip : Your game includes Fig. 4A just one Medium Bolt (#26). Pop-A-Shot Home | Single Shot WWW.POP-A-SHOT.NET Page 5/15 SKU# PASHOM18-01...
- Page 6 Arm is on the outside of the Board Tube (#2). Attach the Forward Tubes (#12) Fig. 6A to the Top Tubes (#1) using the spring locks (Fig. 6B). Make sure the Top Tubes flare outward. Pop-A-Shot Home | Single Shot WWW.POP-A-SHOT.NET Page 6/15 SKU# PASHOM18-01...
- Page 7 Attach the Side Tubes (#7), Base Tube (#3) and Side Arms (#11) using an Extra Long Bolt (#23), two Washers (#29) and a Nut (#30 ) (Fig. 8A). Fig. 8A Pop-A-Shot Home | Single Shot WWW.POP-A-SHOT.NET Page 7/15 SKU# PASHOM18-01...
- Page 8 Attach the Rim (#21) to the Backboard (#14) using a Short Bolt (#26) and a Washer (#29) on the front and a Washer (#29) and Nut (#30) on the back. Pop-A-Shot Home | Single Shot WWW.POP-A-SHOT.NET Page 8/15 SKU# PASHOM18-01...
- Page 9 (Fig 10B) and screwed all the way into the Backboard (#14)(Fig 10C). Fig 10C AC Adapter Put 4 AA Batteries into Scoreboard (#15) and/or plug in AC Adapter (#15) to Scoreboard (#15). Pop-A-Shot Home | Single Shot WWW.POP-A-SHOT.NET Page 9/15 SKU# PASHOM18-01...
- Page 10 (Fig 12B). Put the tab of the Ball Return Ramp (#18) on the Bolt (#24) and fasten with a Washer (#29) and a Nut (#30) (Fig. 12C). Fig.12C Cross Tube (#6) WWW.POP-A-SHOT.NET Pop-A-Shot Home | Single Shot Page 10/15 SKU# PASHOM18-01...
- Page 11 Fig. 14A to the Lean Bar (#9) using a Bolt (#25), two Washers (#29) and a Nut (#30) (Fig. 14A). Attach the Velcro straps around the Lean Bar (#9 )(Fig. 14B). WWW.POP-A-SHOT.NET Pop-A-Shot Home | Single Shot Page 11/15 SKU# PASHOM18-01...
- Page 12 “Control Panel” in the Scoring Unit. Tip: You’ll find complete game directions and operations in this booklet. The “Cheat Sheet” is intended as a quick handy reference guide. Fig 15A WWW.POP-A-SHOT.NET Pop-A-Shot Home | Single Shot Page 12/15 SKU# PASHOM18-01...
- Page 13 COMPLETED GAME Pop-A-Shot Home | Single Shot WWW.POP-A-SHOT.NET Page 13/15 SKU# PASHOM18-01...
- Page 14 If no basket is made within :03, next basket is 2 points 4. Overtime: 1:00 on clock 5. Sudden Death: :15 on clock 6. Free Play: All baskets count as 2 points Pop-A-Shot Home | Single Shot WWW.POP-A-SHOT.NET Page 14/15 SKU# PASHOM18-01...
-
Page 15: Troubleshooting
• Make sure the nets are correctly attached to the rims (incorrect placement can block the sensors). The net’s longer loops should go through the hooks of the rim (Step 10). Please visit www.pop-a-shot.net/support for more troubleshooting tips and hacks. Pop-A-Shot Home | Single Shot WWW.POP-A-SHOT.NET...
