Bison VB1253W Instruction Manual

—— Instruction Manual ——
3 N
P A R T S L I S T
Item Qty Description
A 1 Dome Base
C 3 Net Carousel
1
E 4 1/2" x 1" Hex Bolt
G 3 1/2" Nylock Nut
I 4 1/2" Flat Washer
♦
Inspect all contents prior to installation. Report any missing parts to dealer immediately.
♦
Read all instructions before proceeding.
1. Using a 1/2" x 1" Hex Bolt (E), 1/2" Flat Washer (I), Plastic Washer (F), and a 1/2" Nylock Nut (G) assemble the
Net Winding Racks (D) to the 3 Net Carousel (C). See Figure 1.
2. Attach the carousel assembly to the threaded end of the Upright Pole (B) using a 1/2" x 1" Hex Bolt (E), 1/2" Lock
Washer (H), and a 1/2" Flat Washer (I). See Figure 2.
3. Mount the assembled Upright Pole (B) onto the Dome Base (A). See Figure 2.
Date: 4/11/2012 Rev: I.R.
S W
ET TORAGE
VB1253W Net Winders
D
Figure 1
B.A. N.J.C.
INDER
Item Qty Description
B 1 Upright Pole
D 3 Net Winding Rack
F 3 Plastic Washer
H 1 1/2" Lock Washer
C
G
File: \Pub\Instructions\Volleyball\Netwinder.pub.
1
Customer Service
(800) 247-7668
E
I
F
Ref#: 960712
