Parts & Service
Spray Star 3180
Model 30-000-E
SN: 300G600
January 2021
Product Support:
Hwy SS & Poplar Ave; Cameron WI 54822
1-800-891-9435
productsupport@smithco.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 300G600 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Smithco 300G600

Summary of Contents for Smithco 300G600

  • Page 1 Parts & Service Spray Star 3180 Model 30-000-E SN: 300G600 January 2021 Product Support: Hwy SS & Poplar Ave; Cameron WI 54822 1-800-891-9435 productsupport@smithco.com...

  • Page 2: Table Of Contents

    CONTENTS Introduction ..........1-3 Accessories ........58-119 3182 System ..........58-59 Introduction ................ 1 Plumbing 3184 System Plumbing..........60-61 General Safe Practices............2 TeeJet Radion Wiring ............. 62 ® Specifications ..............3 TeeJet 744A Wiring ............63 ® Optional Spray Equipment..........3 Plumbing Star Command I&II System ......64-65 Service ..........4-11 Star Command I Rear Module Mount ......

  • Page 3: Introduction

    All Smithco machines have a Serial Number and Model Number. Both numbers are needed when ordering parts. The machine serial number is located on the main frame behind the left front wheel. Refer to engine manual for placement of engine serial number.

  • Page 4: General Safe Practices

    17. Stop engine before making repairs/adjustments or checking/adding oil to the crankcase. 18. Use parts and materials supplied by Smithco only. Do not modify any function or part. 19. Use caution when booms are down as they extend out beyond the center line of the machine.

  • Page 5: Specifications

    SPECIFICATIONS SPRAY STAR 3180 WEIGHTS AND DIMENSIONS Length 128" (3.3m) Width 72" (1.8m) Width w/ Booms Open 20' - 260" (6.6m) 18' - 240" (6.1m) Height w/ Roll Bar 84" (2.1m) Height w/ Booms Folded 20' - 136" (3.5m) 18' - 110"(2.8m) Wheel Base 68"...

  • Page 6: Service

    MAINTENANCE Before servicing or making adjustments to machine, stop engine and remove key from ignition. Use all procedures and parts prescribed by the manufacturer's. Read the en- gine manual before operation. LUBRICATION Use No. 2 General purpose lithium base grease and lubricate every 100 hours. The Spray Star 3180 has 8 grease fittings.
  • Page 7 MAINTENANCE ENGINE OIL Change and add oil according to chart below based on air temperature at the time of operation. Do not over- fill. Use a high quality detergent oil classified "For Service use API classification SJ or higher" oil. Use no spe- cial additives with recommended oils.

  • Page 8: Wheel Creep

    MAINTENANCE BATTERY Batteries normally produce explosive gases which can cause personal injury. Do not allow flames, sparks or any ignited object to come near the battery. When charging or working near battery, always shield your eyes and always provide proper ventilation. Battery cable should be disconnected before using “Fast Charge.”...

  • Page 9: Adjustments

    ADJUSTMENTS SPRAY PUMP WITH BELT Located to the right of the engine. The belt should have approximately " (13mm) of deflection in the center of the top strand. SAFETY INTERLOCK SWITCH To adjust the interlock switch on the back hydrostatic pump loosen the set screw on the front half of the switch, with the ignition switch OFF.
  • Page 10 ADJUSTMENTS SPRAY BOSS CONTROL Engages and disengages speed boss. Forward is engage and all the way back is disengage. When the lever is engaged it sets a stop for the accelera- tor. The accelerator pedal must be used to maintain this speed.

  • Page 11: Service Chart

    SERVICE CHART Before servicing or making adjustments to the machine, stop engine, block wheels and remove key from ignition. Follow all procedures and ONLY use parts prescribed by the manufacturer. Read the engine manual before maintenance. The suggested maintenance checklist is not offered as a replacement for the manufacturer’s engine manual but as a supplement.
  • Page 12 SERVICE CHART Item Maintenance Procedure Torque the wheel lug nuts. (64-74 ft/lb (87-100 Nm)) After the first 8 operating hours Change the engine oil filter. Check the engine oil level. Clean area around muffler and controls. Check the hydraulic fluid level. Before each use daily Check the tire pressure.

  • Page 13: Storage

    STORAGE To prevent damage from freezing, pour window washer fluid into spray sys- tems tank and operate pump to circulate mix through gun and hose back to tank. Open boom control to circulate through rest of spray system. 1. Clean the exterior surfaces of the engine. 2.

  • Page 14: Diagrams

    WIRING DIAGRAM Color Code Chart Blue Brown Yellow Green Orange Black Purple White Use dielectric grease on all electrical connections.
  • Page 15 WIRING DIAGRAM REF# PART# DESCRIPTION QUANTITY 20-730-01 GPS Antenna (part of speedometer) 30-356 GPS Speedometer 33-084 Magnetic Coil 32-637 LED Lights 33-509 Cruise Foot Switch 15-725 Mount Panel End 15-727 Rocker, No Light 15-782 Non-Lighted Switch 15-729 Mount Panel Middle 15-726 Lighted Switch 15-732...

  • Page 16: Hydraulic Diagram

    HYDRAULIC DIAGRAM Letter Code Chart Center Inside Outside Bottom...
  • Page 17 HYDRAULIC DIAGRAM PARTS LIST REF# PART# DESCRIPTION QUANTITY 30-156 Hydraulic Hose 30-091 Hydraulic Hose 15-301 Orbital 30-094 Hydraulic Hose 15-839 Steering Hydraulic Cylinder 14-531 Seal Kit 18-171 Seal Loc Adapter 30-025 Oil Tank 13-747 Filler Breather 13-586-03 Neck 8833-9 1" Suction Hose 18-222 Hose Clamp 8833-17...

  • Page 18: Parts

    BODY & FRAME DRAWING...

  • Page 19: Body & Frame

    - 13 x 1 HNFL-12-13 Flange Whiz-loc Nut, - 13 16-557 Square Cap 30-095 318 Gallon Tank (Fiberglass) 25-372 Decal, Smithco 4" Star 30-016 Decal, Spray Star 3180 16-953 16" Hinged Lid Well 16-953-01 Gasket for Lid 16-169 Strainer Basket...
  • Page 20 NOSE CONE DRAWING...

  • Page 21: Nose Cone

    PART# DESCRIPTION QUANTITY 76-364 Square Boot HNJ-58-18 Jam Nut, - 18 13-726 Center Cap 27-077 Decal, Smithco Round 13-718 15" Steering Wheel 76-362 Mini Tilt Steering(includes * items) HB-516-18-150 Hex Bolt, - 18 x 1 HNFL-516-18 Flange Whiz-loc Nut, 48-187...

  • Page 22: Seat/Control Panel

    SEAT PANEL DRAWING...
  • Page 23 SEAT PANEL PARTS LIST REF# PART# DESCRIPTION QUANTITY 76-198-03 Seat Belt 30-358 Seat Panel - Fiberglass 30-371 Cup Holder Panel 15-719 Decal, Speed Control HSD-8-075 Drill Screw, #8 - 32 x 15-781 Cup Holder 10-120 Spray Boss Handle HB-716-14-100 Hex Bolt, - 14 x 1 HNTL-716-14 Nylon Lock Nut,...

  • Page 24: Steering Orbital Drawing

    ORBITAL DRAWING REF# PART# DESCRIPTION QUANTITY 76-362 Mini Tilt Steering 15-844 Tilt Steering Spacer 48-187 Stub Shaft 31-056 Tilt Steering Plate 31-057 Steering Spacer 15-301 Orbital 18-306 Straight Thread Connector 7-867 Connector, SAE #6 HBM-6-1-16 Metric Hex Bolt, M6-1-16 HWLM-6 Metric Lock Washer, M6 HB-516-18-150 Hex Bolt,...

  • Page 25: Fuel Tank

    FUEL TANK DRAWING REF# PART# DESCRIPTION QUANTITY HB-38-16-100 Hex Bolt, - 16 x 1 HNFL-38-16 Flange Whiz-loc Nut, - 16 30-321 Tank Mount 32-641 Tank Mount Plate 30-336 Tank Mount Plate HB-38-16-100 Hex Bolt, - 16 x 1 HNFL-38-16 Flange Whiz-loc Nut, 32-531 20 Gal.

  • Page 26: Foot Pedal Linkage

    FOOT PEDAL LINKAGE DRAWING...
  • Page 27 FOOT PEDAL LINKAGE PARTS LIST REF# PART# DESCRIPTION QUANTITY 15-692 Pedal Relay 31-055 Linkage Rod 21-462 Ball Joints HN-516-24 Hex Nut, - 24 10-163 Forward Foot Pedal 48-066 Pedal Grip HSTP-516-18-075 Phillips Machine Screw, -18 x HNFL-516-18 Flange Whiz-loc Nut, 76-296 Pedal Mount 18-234...

  • Page 28: Spray Boss Linkage

    LINKAGE DRAWING...
  • Page 29 LINKAGE PARTS LIST REF# PART# DESCRIPTION QUANTITY 15-781 Drink Cup Holder 30-371 Cup Holder Panel 10-120 Speed Boss Handle 30-370 Spray Boss Mount HB-14-20-150 Hex Bolt, 1/4 - 20 x 1-1/2 HNFL-14-20 Flange Whiz-loc Nut, 1/4-20 HB-516-18-100 Hex Bolt, -18 x 1 HW-516 Flat Washer, HNTL-516-18...
  • Page 30 FRONT AXLE DRAWING...

  • Page 31: Front Axle

    FRONT AXLE PARTS LIST REF# PART# DESCRIPTION QUANTITY HP-18-150 Cotter Pin, 33-073-02 Dust Cap 30-071 Hub Assembly (includes * items) HNAR-100-14 Slotted Jam Nut, 1 - 14 30-070 Left Spindle HG-14-28-180 Grease Fitting, -28 x 180° 20-617 Shock Absorber HB-58-11-300 Hex Bolt, - 11 x 3 HNTL-58-11...

  • Page 32: Oil Tank

    OIL TANK DRAWING...
  • Page 33 OIL TANK PARTS LIST REF# PART# DESCRIPTION QUANTITY 30-025 Oil Tank 13-586-02 Bottom Gasket 13-586-03 Fuel Tank Neck HSM-10-32-063 Machine Screw, #10-32 x HWL-10 Lock Washer, #10 13-586-01 Cap Gasket 13-747 Filler Breather 18-397 90° Hose Barb Fitting 18-396 Reducer 72-146 Oil Filter Assembly 60-334...
  • Page 34 SEAT PANEL DRAWING...

  • Page 35: Seat Panel

    SEAT PANEL PARTS LIST REF# PART# DESCRIPTION QUANTITY HSM 10-32-112 Machine Screw, #10-32 x 1 HNFL-10-32 Flange Whiz-loc Nut, #10-32 15-437 Rubber Latch 30-307 Latch Mount 30-308 Engine Cover (Fiberglass) 27-055 Flush Hinge HSM 10-32-100 Machine Screw, #10-32 x 1 HNFL-10-32 Flange Whiz-loc Nut, #10-32 30-362...
  • Page 36 ENGINE DRAWING...

  • Page 37: Engine

    ENGINE PARTS LIST REF# PART# DESCRIPTION QUANTITY HBM-10-1.25-30 Hex Bolt, #10 - 1.25 x 30 HWLM-10 Lock Washer, #10 30-206 Pulley Radiator Kit 32-521 57HP Kubota Gas Engine 32-561-06 Air Cleaner 32-561-07 Primary Filter 32-561-08 Secondary (inner)Filter HB-716-14-300 Hex Bolt, - 14 x 3 HW-716 Flat Washer,...

  • Page 38: Hydrostatic Pump

    HYDROSTATIC PUMP DRAWING...
  • Page 39 HYDROSTATIC PUMP PARTS LIST REF# PART# DESCRIPTION QUANTITY HB-38-16-200 Hex Bolt, -16 x 2 HW-38 Flat Washer, HN-38-16 Hex Nut, - 16 30-082 Idler Arm HG-14-28-180 Grease Fitting, - 28 x 180° HMB-12-14 Machine Bushing, x 14GA 48-109 Spring 14-266 Ball Bearing 18-270 Oilite Bushing...

  • Page 40: Cooler And Exhaust

    COOLER AND EXHAUST DRAWING...
  • Page 41 COOLER AND EXHAUST PARTS LIST REF# PART# DESCRIPTION QUANTITY HB-38-16-275 Hex Bolt, - 16 x 2 HNFL-38-16 Flange Whiz-loc Nut, - 16 30-043 Oil Cooler Cover 60-406 Spacer 30-105 Thermal Transfer Heat Exchanger 18-107 Pipe Thread Reducer 18-402 Hose Barb, x 90°...

  • Page 42: Rear Wheel Drive

    REAR WHEEL DRIVE DRAWING REF# PART# DESCRIPTION QUANTITY 18-394 Elbow 18-301 Straight Thread Elbow 30-099 Auburn Wheel Drive 30-100 Micro Spring Hydraulic Brakes 30-101 Eaton 2000 Series Hydraulic Motor 30-101-11 Seal Kit 17-615 Boom Tube 17-614 Boom Spacer HB-516-18-100 Hex Bolt , - 18 x 1 HW-516-18 Flat Washer,...

  • Page 43: Spray Pump

    SPRAY PUMP DRAWING REF# PART# DESCRIPTION QUANTITY 30-326 Valve Mount 18-372 3-Way Valve 18-372-01 Handle 16-180 Quick Coupler Male 16-935 Quick Coupler Cap 16-156 Elbow 16-161 Fitting 16-998 Hypro Pump 16-880 Close Nipple 18-390 16-182 90° Elbow 10-389 Plug 16-825 Hex Bushing 33-480 Pressure Switch...

  • Page 44: Spray Tank

    TANK DRAWING...
  • Page 45 TANK PARTS LIST REF# PART# DESCRIPTION QUANTITY 30-095 318 Gallon Tank (fiberglass) HB-38-16-200 Hex Bolt, - 16 X 2 HW-38 Flat Washer, HNTL-38-16 Nylon Lock Nut, - 16 30-051 Rear Tank Mount 8828-16 Foam Tape HB-38-16-300 Hex Bolt, - 16 x 3 HW-38 Flat Washer, HNFL-38-16...

  • Page 46: Turbo Quad Agitator

    TURBO-QUAD AGITATOR REF# PART# DESCRIPTION QUANTITY 16-036 Agitator Jet (Includes one each ", ", and " orifices) 4 16-173 Reducer, 16-158 Close Nipple, 16-157 Female Pipe Thread Tee, 16-172 Nylon Nipple, NPT x 3...

  • Page 47: Hypro ® Pump

    16-998 HYPRO PUMP ® WHEN SERVICING THE SPRAY PUMP OR FILTER, ALL CONTROL VALVES MUST BE SHUT OFF IF THERE IS LIQUID IN THE TANK. REF# PART# DESCRIPTION QUANTITY 16-998-01 Drain Plug 16-998-02 Pump Casing Impeller Nut 16-966-16 Impeller 16-966-11 16-998-10 Gasket 16-998-04...

  • Page 48: Orbital

    15-301 ORBITAL DRAWING...
  • Page 49 15-301 ORBITAL PARTS LIST REF # PART # DESCRIPTION QUANTITY Dust Seal Housing O-Ring Seal Quad Seal 10-576-03 Thrust Bearing 10-576-02 Bearing Race Manual Steering Relief Valve O-ring Plug 10‡ Standard Torque Centering Springs Sleeve 15-301-06 Wear Plate 10-576-01 Drive 15-301-08 Drive Pin Spool...

  • Page 50: Eaton Gear Pump

    76-197 EATON GEAR PUMP REF# PART# DESCRIPTION QUANTITY Body 76-197-01 Front Plate Washer 76-197-06 Cap Screw 76-197-07 Retaining Ring Shaft Seal 33-061-15 Washer O-Ring Backup Gasket Seal Wear Plate 76-197-04 Shaft (comes with Idler Gear) 76-197-02 Back Plate Plug 76-197-08 Seal Kit...

  • Page 51: Eaton Motor

    30-101 EATON MOTOR DRAWING REF# PART# DESCRIPTION QUANTITY 30-101-01 Shaft and Bearing Kit ( splined 13T) Seal Exclusion Seal Shaft Seal Back Up Ring 30-101-02 Bearing Housing Shaft Face Seal 30-101-03 Wear Plate 30-101-04 Main Drive 30-101-05 Geroter 30-101-06 Valve Plate 14-207 Valve Drive 14-208...

  • Page 52: Hydrostatic Pump

    30-102 EATON PUMP DRAWING...
  • Page 53 30-102 EATON PUMP PARTS LIST REF# PART# DESCRIPTION QUANTITY 33-058-16 Valve Plate (CW Rotation) 33-058-26 Bearing (Press Fit) Back Plate Assembly Relief Valve S/A O-Ring Molded O-Ring 33-058-38 Inner Ring Gerotor 33-058-39 Outer Ring Gerotor 33-058-35 Charge Pump Adapter Assembly 33-058-46 Bearing (Press Fit) Hex Bolt and Washer...
  • Page 54 30-102 EATON PUMP DRAWING...
  • Page 55 30-102 EATON PUMP PARTS LIST REF# PART# DESCRIPTION QUANTITY 33-058-02 Jam Nut 33-058-42 Washer Seal Washer Retaining Ring 33-058-10 Thrust Race 33-058-11 Thrust Bearing 33-058-31 Washer 33-058-52 Shaft Seal Retaining Ring 33-058-28 Drive Shaft Housing Assembly 33-058-18 Bearing (Press Fit) 33-058-33 Plug S/A O-Ring...

  • Page 56: Auburn Power Wheel

    30-099 AUBURN POWER WHEEL DRAWING ®...
  • Page 57 30-099 AUBURN POWER WHEEL PARTS LIST ® REF# PART# DESCRIPTION QUANTITY Coupling Input Shaft Spindle 30-099-02 Boot Seal 5*† 30-099-06 Oil Seal Bearing Cone Bearing Cup Wheel Hex Bolt Hex Head Hex Bolt (Grade 8) 6-12 Flat Washer 6-12 Bearing Cone 13*†...

  • Page 58: Disc Brake

    30-100 BRAKE DRAWING...
  • Page 59 30-100 BRAKE PARTS LIST REF# PART# DESCRIPTION QUANTITY Cap Screws Retaining Ring Retaining Ring Bearing 5*† Oil Seal Pressure Plate 7*†‡ Case Seal 8† O-ring 9† Back-up Ring Piston 11† O-ring 12† Back-up Ring O-ring 14‡ Stator Disc 15‡ Rotor Disc 16‡...

  • Page 60: Accessories

    3182 PLUMBING DRAWING ® (RADION 8140) 15-817 #50 Fitting O-ring 15-818 #75 Fitting O-ring Boom Left Hose Center Hose Right Hose 9032-138 9032-96 9032-134 9032-148 9032-96 9032-144...
  • Page 61 3182 PLUMBING PARTS LIST ® (RADION 8140) REF# PART# DESCRIPTION QUANTITY 8896-85 1" Discharge Hose 85" 18-222 Hose Clamp 15-746 #50 - 90° Hose Barb 15-740 #50 Series Clamp 15-738 Flanged Ball Valve 15-808 #50 Straight Hose Barb 20-689 Valve Bracket 15-870 #50 1 Hose Barb...

  • Page 62: 3184 System Plumbing

    3184 PLUMBING DRAWING ® (TEEJET 744 15-817 #50 Fitting O-ring 15-818 #75 Fitting O-ring Boom Left Hose Center Hose Right Hose 9032-138 9032-96 9032-134 9032-148 9032-96 9032-144...
  • Page 63 3184 PLUMBING PARTS LIST ® (TEEJET 744 REF# PART# DESCRIPTION QUANTITY 15-739 #75 x 90° x 1 Hose Barb 15-741 #75 Series Clamp 15-780 Poly Hex Plug HB-38-16-500 Hex Bolt, - 16 x 5 HNFL-38-16 Flange Whiz-loc Nut, - 16 15-737 Flanged Strainer 16-968-03...

  • Page 64: Teejet ® Radion Wiring

    3182 SYSTEM WIRING [RADION 8140] ® If using Simulated Speed with a Radion 8140, one needs to change back to Ground Speed for proper rate control when spraying. REF# PART# DESCRIPTION QUANTITY Antenna 20-687-02 GPS Speed Sensor 20-697-01 Radion 8140 Console 20-697-02 Wire Harness 15-743...

  • Page 65: Teejet ® 744A Wiring

    3184 SYSTEM WIRING [TEEJET 744 ® REF# PART# DESCRIPTION QUANTITY 20-688-02 744A Console 20-688-07 Circuit Board 20-782 Rain Cover 20-727 Mount Bracket 20-540 Ram Mount Console harness Fused Power Cable 33-271 Fuse Block Ball Valve Wire Harness 15-743 Manifold Ball Valve Regulator Valve Adapter 20-817 Regulating Valve...

  • Page 66: Plumbing Star Command I&Ii System

    STAR COMMAND I & II PLUMBING DRAWING 15-817 #50 Fitting O-ring 15-818 #75 Fitting O-ring Boom Left Hose Center Hose Right Hose 9032-138 9032-96 9032-134 9032-148 9032-96 9032-144...
  • Page 67 STAR COMMAND I & II PLUMBING PARTS LIST REF# PART# DESCRIPTION QUANTITY 8896-85 1" Discharge Hose x 85" 18-222 Hose Clamp 15-746 #50 90° Hose Barb 15-740 #50 Series Clamp 15-738 Flanged Ball Valve 20-689 Valve Bracket 15-808 #50 Straight Hose Barb 8897-24 "...

  • Page 68: Star Command I Rear Module Mount

    STAR COMMAND I MODULE MOUNTS REF# PART# DESCRIPTION QUANTITY 20-665 Drive Module Bracket 20-664 Z Bracket HSTP-14-20-075 Machine Screw, - 20 x HNFL-14-20 Flange Whiz-loc Nut, Center Boom Mount HB-516-18-100 Hex Bolt, -18 x 1 17-614 Boom Spacer HNTL-516-18 Nylon Lock Nut, 20-555 U-Hex Bolt HNFL-12-13...

  • Page 69: Star Command I Wiring

    STAR COMMAND I WIRING...

  • Page 70: Star Command Ii Rear Module Mount

    STAR COMMAND II MODULE MOUNTS REF# PART# DESCRIPTION QUANTITY 17-562 LH Break-Away Arm 11-050 Spring 17-560 Hinge Mount 17-559 Break-Away Mount 20-796 Bracket Cover 20-795 LH Driver Module Bracket HB-516-18-150 Hex Bolt, -18 x 1 HNFL-516-18 Flange Whiz-loc Nut, 20-794 Module Cover Bracket 10-625 Module Mount Bracket...

  • Page 71: Star Command Ii Wiring

    STAR COMMAND II WIRING REF# PART# DESCRIPTION QUANTITY RAM Mount Aeros Harness w/ ISO CAN 32-709 RAM Base 20-805 Aeros Console 20-806 DynaJet Console 20-736-01 Antenna Cable 20-767 RX720 Receiver 20-686-02 Switch box Power Cable 20-670-04 Pressure Sensor 20-684 Flow Meter Terminator Terminator DynaJet Interface Boom Harness...

  • Page 72: Control Mounts

    CONTROL MOUNTS TEEJET 744 RADION 8140 STAR COMMAND I...
  • Page 73 CONTROL MOUNTS STAR COMMAND II REF# PART# DESCRIPTION QUANTITY 32-528 Control Cover 32-524 744 Control Mount 20-688-02 744 Console 20-540 RAM mount 20-697-01 Radion Console 32-709 RAM Base GPS Speed Sensor 20-670-06 DynaJet Console for Star Command I Aeros RAM Mount 32-691 Aeros Mount Spacer 32-690...

  • Page 74: Regulator Valve

    20-817 REGULATOR VALVE REF# PART# DESCRIPTION QUANTITY Motor, 15-552-24 Retaining Clip Socket Head Cap Screw, Stainless Steel 15-552-26 Motor Adapter, Polypropylene 15-517-11 Thrust Washer, Teflon 15-552-27 Stem, Stainless Steel 15-552-05 O-ring, Viton 15-517-16 Body, Nylon Nylon Lock Nut, Stainless Steel Ball, Polypropylene 15-552-13 Gasket, Viton...

  • Page 75: Regulator Valve

    20-785 REGULATOR VALVE REF# PART# DESCRIPTION QUANTITY 20-785-01 Motor, 6RPM 15-552-24 Retaining Clip 15-552-25 Socket Head Cap Screw, Stainless Steel 15-552-26 Motor Adapter, Polypropylene 15-517-11 Thrust Washer, Teflon 15-552-27 Stem, Stainless Steel 15-552-05 O-ring, Viton 15-517-16 Body, Nylon Lock Nut, Stainless Steel Ball, Polypropylene 15-552-13 Gasket, Viton...

  • Page 76: Manifold Ball Valve

    15-743 MANIFOLD BALL VALVE REF# PART# DESCRIPTION QUANTITY 15-552-23 Motor 15-878 Metri-Pack Cable (comes with motor) 15-552-24 Retaining Clip 15-552-25 Socket Head Cap Screw, Stainless Steel 15-552-26 Motor Adapter, Polypropylene 15-517-11 Thrust Washer, Teflon 15-552-27 Stem, Stainless Steel 15-552-05 O-ring, Viton 15-517-16 Body, Nylon Lock Nut, Stainless Steel...

  • Page 77: 15-737/14-628 Flanged Strainer

    15-737/14-628 FLANGED STRAINER REF# PART# DESCRIPTION QUANTITY 15-737-01 Strainer Head 75 Series 16-968-03 50 Mesh Strainer 16-968-05 80 Mesh Strainer 14-521-02 EPDM Gasket 14-521-03 Bowl 1" NPT 14-521-04 EPDM Rubber gasket 14-521-05 15-737 Flanged Strainer Assembly with 50 Mesh Screen 14-628 Flanged Strainer Assembly with 80 Mesh Screen...

  • Page 78: Agitation Strainer

    14-801 FLANGED STRAINER ASSEMBLY WITH 80 MESH REF# PART# DESCRIPTION QUANTITY QC Strainer Head 14-801-01 Bowl Strainer QC Retaining Clip 14-802 50 Mesh Strainer 14-801-02 Viton O-ring 15-553-01 Retaining Clip 15-553-02 Viton O-ring...
