Installing The Discharge Tubes - Toro 78479 Operator's Manual

13
Installing the Discharge
Tubes
Parts needed for this procedure:
1 Upper tube
1 Lower tube
3 Bolt (#10 x 3/4 inch)
3 Locknut (#10)
3 Washer (7/32 inch)
Procedure
1. Lower the machine deck to the lowest
height-of-cut position.
2. Remove the bags for viewing the tube under
the hood.
3. Install the upper tube into the bagger opening
and pull it back out so that the hopper seal is
protruding out (Figure
Figure 40
1. Upper tube
2. Bagger opening
4. Align the dimple in the upper tube equally
between the screws securing the hopper seal to
the hopper (Figure
40).
3. Bagger hood
41).
Note:
The hopper seal must protrude outward
from the bagger hood.
1. Dimple
5. Install the lower tube into the upper tube
42).
1. Lower tube
g376098
6. Slide the lower tube onto the blower housing
and latch them together
29
Figure 41
Figure 42
2. Upper tube
(Figure 43).
g007027
(Figure
g003424
