Model No. PETL15717.0
Serial No.
USER'S MANUAL
Write the serial number in the space
above for reference.
Serial Number
Decal
CUSTOMER SERVICE
UNITED KINGDOM
Call: 0330 123 1045
From Ireland: 053 92 36102
Website: www.iconsupport.eu
E-mail: csuk@iconeurope.com
Write:
ICON Health & Fitness, Ltd.
Unit 4, Westgate Court
Silkwood Park
OSSETT
WF5 9TT
UNITED KINGDOM
AUSTRALIA
Call: 1800 993 770
E-mail: australiacc@iconfitness.com
Write:
ICON Health & Fitness
PO Box 635
WINSTON HILLS NSW 2153
AUSTRALIA
CAUTION
Read all precautions and instruc-
tions in this manual before using
this equipment. Save this manual
for future reference.
www.iconeurope.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PETL15717.0 and is the answer not in the manual?

Questions and answers

Related Manuals for ICON Health & Fitness PETL15717.0

Summary of Contents for ICON Health & Fitness PETL15717.0

  • Page 1 Model No. PETL15717.0 Serial No. USER’S MANUAL Write the serial number in the space above for reference. Serial Number Decal CUSTOMER SERVICE UNITED KINGDOM Call: 0330 123 1045 From Ireland: 053 92 36102 Website: www.iconsupport.eu E-mail: csuk@iconeurope.com Write: ICON Health & Fitness, Ltd.

  • Page 2: Table Of Contents

    TABLE OF CONTENTS WARNING DECAL PLACEMENT ............. . .2 IMPORTANT PRECAUTIONS .

  • Page 3: Important Precautions

    IMPORTANT PRECAUTIONS WARNING: To reduce the risk of burns, fire, electric shock, or injury to persons, read all important precautions and instructions in this manual and all warnings on your treadmill before using your treadmill. ICON assumes no responsibility for personal injury or property damage sus- tained by or through the use of this product.
  • Page 4 21. The treadmill is capable of high speeds. 25. When folding or moving the treadmill, make Adjust the speed in small increments to sure that the storage latch is holding the avoid sudden jumps in speed. frame securely in the storage position. Do not operate the treadmill while it is folded.

  • Page 5: Before You Begin

    BEFORE YOU BEGIN Thank you for selecting the revolutionary reading this manual, please see the front cover of this PROFORM POWER 1295 I treadmill. The POWER manual. To help us assist you, please note the product ® 1295 I treadmill offers an impressive selection of fea- model number and serial number before contacting us.

  • Page 6: Part Identification Chart

    PART IDENTIFICATION CHART Use the drawings below to identify small parts used for assembly. The number in parentheses below each draw- ing is the key number of the part, from the PART LIST near the end of this manual. The number following the key number is the quantity used for assembly.

  • Page 7: Assembly

    ASSEMBLY • Assembly requires two persons. • Left parts are marked “L” or “Left” and right parts are marked “R” or “Right.” • Place all parts in a cleared area and remove the packing materials. Do not dispose of the packing •...
  • Page 8 2. Make sure that the power cord is unplugged. Remove the tie securing the Upright Wire (81) to the front of the Base (94). Next, identify the Right Upright (90). Have a sec- ond person hold the Right Upright near the Base (94).
  • Page 9 4. Hold the Right Upright (90) against the Base (94). Make sure not to pinch the Upright Wire (81). Attach the Right Upright (90) and a Wheel (97) with two 3/8" x 2 1/4" Screws (7), a 3/8" x 1 1/4" Screw (63), a 3/8"...
  • Page 10 6. Hold the Right Handrail (87) near the Right Upright (90). Insert the Upright Wire (81) through the hole in the bottom of the Right Handrail as shown, and then remove the wire tie (A) from the Upright Wire. Next, attach the Right Handrail (87) to the Right Upright (90) with two 5/16"...
  • Page 11 8. Set the console assembly (F) face down on a soft surface to avoid scratching the console assembly. Remove and save the four 5/16" x 1/2" Screws (4). 9. Set the console assembly (F) on the Left and Right Handrails (86, 87). Make sure not to pinch any wires (G, 81).
  • Page 12 10. Attach the console assembly (F) to the Left and Right Handrails (86, 87) with four #10 x 3/4" Screws (9) and four #10 Star Washers (5) as shown; start all four Screws, and then tighten them. 11. See the inset drawing. Connect the Upright Wire (81) to the console wire (G).
  • Page 13 12. Attach the Right Handrail Cover (92) to the Right Handrail (87) with three #8 x 1/2" Screws (1); do not overtighten the Screws. Attach the Left Handrail Cover (79) to the Left Handrail (86) in the same way. 13. Slide the Left Bottom Handrail Cover (85) up against the Left Handrail Cover (79), and attach the Left Bottom Handrail Cover with two #8 x 1/2"...
  • Page 14 14. Note: If the treadmill is assembled on a smooth surface, it may roll forward during this step. Raise the Frame (56) to the upright position. IMPORTANT: Do not raise the Frame past the vertical position. Have a second person hold the Frame until step 16 is completed.
  • Page 15 16. Remove the 5/16" Nut (12) and the 5/16" x 2 1/4" Bolt (3) from the bracket on the Latch Crossbar (38). Align the upper end of the Storage Latch (53) with the bracket on the Latch Crossbar (38), and insert the 5/16" x 2 1/4" Bolt (3) through the bracket and the Storage Latch.
  • Page 16 18. Press the two tabs on the Tablet Holder (110) into the slots (L) in the console assembly (F). Attach the Tablet Holder (110) with four #8 x 5/8" Machine Screws (115). Note: Start the two top Start First Machine Screws first, and then start the two bottom Machine Screws.

  • Page 17: How To Use The Treadmill

    HOW TO USE THE TREADMILL HOW TO PLUG IN THE POWER CORD Follow the steps below to plug in the power cord. This product must be earthed. If it should malfunc- 1. Plug the indicated end of the power cord into the tion or break down, earthing provides a path of least socket on the treadmill.
  • Page 18 CONSOLE DIAGRAM MAKE YOUR FITNESS GOALS A REALITY WITH FEATURES OF THE CONSOLE IFIT.COM The advanced treadmill console offers a selection of With your new iFit-enabled fitness equipment, you can features designed to make your workouts more effec- use an array of features on iFit.com to make your fit- tive and enjoyable.
  • Page 19 HOW TO TURN ON THE POWER HOW TO USE THE TOUCH SCREEN IMPORTANT: If the treadmill has been exposed to The console features a tablet with a full-color touch cold temperatures, allow it to warm to room tem- screen. The following information will help you become perature before you turn on the power.
  • Page 20 HOW TO SET UP THE CONSOLE To use the sound system, see page 26. To use the internet browser, see page 26. To use the equip- Before using the treadmill for the first time, set up the ment settings mode, see page 27. To use the maintenance mode, see page 28.
  • Page 21 If you press one of the numbered speed buttons, As you walk or run on the treadmill, the screen can the walking belt will gradually change speed until it show the following workout information: reaches the selected speed setting. • The incline level of the treadmill To stop the walking belt, press the Stop button.
  • Page 22 6. Measure your heart rate if desired. When you are finished using the treadmill, press the power switch into the off position and unplug Note: If you use the handgrip heart rate moni- the power cord. IMPORTANT: If you do not do tor and the chest heart rate monitor at the same this, the treadmill’s electrical components may time, the console will not display your heart...
  • Page 23 5. Measure your heart rate if desired. At the end of the first segment of the workout, the treadmill will automatically adjust to the speed and/ or incline settings for the next segment. See step 6 on page 22. 6. Turn on the fan if desired. The workout will continue in this way until the last segment ends.
  • Page 24 4. Start the workout. HOW TO USE A PULSE WORKOUT Touch the Start button to start the workout. A Pulse workouts automatically control the speed and moment after you touch the button, the walking belt incline of the treadmill to keep your heart rate near a will begin to move.
  • Page 25 6. Monitor your progress with the displays. To compete in a race that you have previously scheduled, touch the Compete button. To view your See step 5 on page 21. Workout History, touch the Track button. To use a set-a-goal workout, touch the Set A Goal button 7.
  • Page 26 8. Turn on the fan if desired. HOW TO USE THE SOUND SYSTEM See step 7 on page 22. To play music or audio books through the console sound system while you exercise, plug a 3.5 mm male 9. When you are finished exercising, remove the to 3.5 mm male audio cable (not included) into the key from the console.
  • Page 27 HOW TO USE THE EQUIPMENT SETTINGS MODE IMPORTANT: You must still unplug the power cord after using the treadmill. Set the update 1. Select the settings main menu. time for a time when you normally use the treadmill and will be available to unplug the power cord after an update.
  • Page 28 11. Enable or disable a passcode. HOW TO USE THE MAINTENANCE MODE The console features a child-safety passcode, 1. Select the settings main menu. designed to prevent unauthorized users from using the treadmill. See step 1 on page 27. Touch the Passcode button. To enable a pass- 2.
  • Page 29 4. Calibrate the incline system of the treadmill. HOW TO USE THE WIRELESS NETWORK MODE Touch the Calibrate Incline button. Then, touch the The console features a wireless network mode that Begin button to calibrate the incline system. The allows you to set up a wireless network connection. treadmill will automatically rise to the maximum incline level, lower to the minimum incline level, 1.
  • Page 30 HOW TO USE THE TABLET HOLDER When a list of networks appears, touch the desired network. Note: You will need to know your network name (SSID). If your network has a password, you IMPORTANT: The tablet holder is designed for use with most full-size tablets.

  • Page 31: How To Fold And Move The Treadmill

    HOW TO FOLD AND MOVE THE TREADMILL HOW TO FOLD THE TREADMILL HOW TO MOVE THE TREADMILL To avoid damaging the treadmill, adjust the incline Before moving the treadmill, fold it as described at the to zero before you fold the treadmill. Then, remove left.

  • Page 32: Maintenance And Troubleshooting

    MAINTENANCE AND TROUBLESHOOTING MAINTENANCE c. Check the power switch located on the treadmill frame near the power cord. If the switch protrudes Regular maintenance is important for optimal perfor- as shown, the switch has tripped. To reset the mance and to reduce wear. Inspect and properly tighten power switch, wait for five minutes and then press all parts each time the treadmill is used.
  • Page 33 SYMPTOM: The displays of the console do not SYMPTOM: The walking belt slows when walked on function properly a. If an extension cord is needed, use only a 3-con- a. Remove the key from the console and UNPLUG ductor, 14-gauge (1 mm ) cord that is no longer THE POWER CORD.
  • Page 34 SYMPTOM: The walking belt is not centered SYMPTOM: The tablet holder does not stay in place between the foot rails a. Rotate the tablet holder backwards. Then, tighten a. IMPORTANT: If the walking belt rubs against the the indicated screw slightly until the tablet holder foot rails, the walking belt may become dam- stays in place when it is rotated to the desired aged.First, remove the key and UNPLUG THE...

  • Page 35: Exercise Guidelines

    EXERCISE GUIDELINES Burning Fat—To burn fat effectively, you must exer- WARNING: cise at a low intensity level for a sustained period of Before beginning this time. During the first few minutes of exercise, your or any exercise program, consult your physi- body uses carbohydrate calories for energy.
  • Page 36 SUGGESTED STRETCHES The correct form for several basic stretches is shown at the right. Move slowly as you stretch —never bounce. 1. Toe Touch Stretch Stand with your knees bent slightly and slowly bend forward from your hips. Allow your back and shoulders to relax as you reach down toward your toes as far as possible.
  • Page 37 NOTES...

  • Page 38: Part List

    PART LIST Model No. PETL15717.0 R0317A Key No. Qty. Description Key No. Qty. Description #8 x 1/2" Screw 3/8" Plastic Bushing #8 x 3/4" Screw 3/8" Washer 5/16" x 2 1/4" Bolt Storage Latch 5/16" x 1/2" Screw Drive Motor...
  • Page 39 Key No. Qty. Description Key No. Qty. Description #8 Star Washer #8 x 3/4" Truss Head Screw #8 x 1/2" Machine Screw Left Rear Cap #8 Nut Right Rear Cap Motor Bushing 1/4" Nut Motor Washer Console Clamp Filter Bracket #8 x 1 3/4"...

  • Page 40: Exploded Drawing

    EXPLODED DRAWING A Model No. PETL15717.0 R0317A...
  • Page 41 EXPLODED DRAWING B Model No. PETL15717.0 R0317A...
  • Page 42 EXPLODED DRAWING C Model No. PETL15717.0 R0317A...
  • Page 43 EXPLODED DRAWING D Model No. PETL15717.0 R0317A...

  • Page 44: Ordering Replacement Parts

    ORDERING REPLACEMENT PARTS To order replacement parts, please see the front cover of this manual. To help us assist you, be prepared to provide the following information when contacting us: • the model number and serial number of the product (see the front cover of this manual) •...
