Model No. PFTL39619.0
Serial No.
Write the serial number in the space
above for reference.
Serial
Number
Decal
REGISTER YOUR
PRODUCT
To register your product and
activate your warranty today,
go to my.proform.com.
CUSTOMER CARE
For service at any time, go to
support.proform.com.
Or call 1-888-533-1333
Mon.–Fri. 6 a.m.–6 p.m. MT
Sat. 8 a.m.–12 p.m. MT
Please do not contact the store.
CAUTION
Read all precautions and
instructions in this manual before
using this equipment. Save this
manual for future reference.
USER'S MANUAL
Advertisement
Table of Contents
Related Manuals for ICON Health & Fitness Pro-Form Cadence LT2.5
Summary of Contents for ICON Health & Fitness Pro-Form Cadence LT2.5
- Page 1 proform.com Model No. PFTL39619.0 USER’S MANUAL Serial No. Write the serial number in the space above for reference. Serial Number Decal REGISTER YOUR PRODUCT To register your product and activate your warranty today, go to my.proform.com. CUSTOMER CARE For service at any time, go to support.proform.com.
-
Page 2: Table Of Contents
TABLE OF CONTENTS WARNING DECAL PLACEMENT ............. . .2 IMPORTANT PRECAUTIONS . -
Page 3: Important Precautions
IMPORTANT PRECAUTIONS WARNING: To reduce the risk of burns, fire, electric shock, or injury to persons, read all important precautions and instructions in this manual and all warnings on your treadmill before using your treadmill. ICON assumes no responsibility for personal injury or property damage sus- tained by or through the use of this product. - Page 4 19. Always stand on the foot rails when starting able to safely lift 45 lbs. (20 kg) to move the or stopping the walking belt. Always hold the treadmill. handrails while using the treadmill. 26. When folding or moving the treadmill, make 20.
- Page 5 STANDARD SERVICE PLANS...
-
Page 6: Before You Begin
BEFORE YOU BEGIN Thank you for selecting the new PROFORM using the treadmill. If you have questions after read- ® CADENCE LT 2.5 treadmill. The CADENCE LT 2.5 ing this manual, please see the front cover of this treadmill offers a selection of features designed to manual. -
Page 7: Part Identification Chart
PART IDENTIFICATION CHART Use the drawings below to identify small parts used for assembly. The number in parentheses below each drawing is the key number of the part, from the PART LIST near the end of this manual. The number following the key number is the quantity used for assembly. -
Page 8: Assembly
ASSEMBLY 1. To use the assembly steps in this manual, first see the helpful tips below. • To hire an authorized service technician to • Left parts are marked “L” or “Left” and right parts assemble the treadmill, call 1-800-445-2480. are marked “R”... - Page 9 3. Identify the Left and Right Handrail Bottoms (60, 62) and slide them onto the Uprights (69, 70) as shown. 4. With the help of a second person, set the Handrail (63) on the Uprights (69, 70). Attach the Handrail with four M8 x 50mm Screws (4) and two M8 Star Washers (30);...
- Page 10 6. Carefully set the console assembly (A) onto the Handrail (63). Attach the console assembly (A) with four #8 x 3/4" Screws (3); start all four Screws, and then tighten them. Make sure that the console wire (B) is not pinched. 7.
- Page 11 8. Connect the Upright Wire (67) to the con- sole wire (B). The connectors should slide together easily and snap into place. If they do not, turn one connector and try again. Insert any excess wire into the console assembly (A). 9.
- Page 12 10. Orient the Storage Latch (68) as shown. Attach the Storage Latch to the left Upright (69) with two #8 x 3/4" Screws (3); start both Screws, and then tighten them. 11. IMPORTANT: You must activate your Console (79) to begin using its exclusive features. First, plug in the power cord (see page 13) and turn on the power (see page 15).
-
Page 13: How To Use The Treadmill
HOW TO USE THE TREADMILL HOW TO CONNECT THE POWER CORD capable of carrying 15 or more amps. To avoid overloading the circuit, do not plug other electrical Use a Surge Suppressor devices, except for low-power devices such as cell phone chargers, into the surge suppressor or into Your treadmill, like other electronic equipment, can be an outlet on the same circuit. - Page 14 CONSOLE DIAGRAM FEATURES OF THE CONSOLE To turn on the power, see page 15. To use the man- ual mode, see page 15. To use an onboard workout, IMPORTANT: To activate your console and begin see page 17. To connect your tablet to the console, using its exclusive features, see assembly step 11 see page 18.
- Page 15 HOW TO TURN ON THE POWER HOW TO USE THE MANUAL MODE IMPORTANT: If the treadmill has been exposed to 1. Insert the key into the console. cold temperatures, allow it to warm to room tem- perature before you turn on the power. If you do See HOW TO TURN ON THE POWER at the left.
- Page 16 4. Change the incline of the treadmill as desired. 6. Measure your heart rate if desired. To change the incline of the treadmill, press the You can measure your heart rate using either the Incline increase or decrease button or one of the handgrip heart rate monitor or a compatible heart numbered incline buttons.
- Page 17 HOW TO USE AN ONBOARD WORKOUT The workout will continue in this way until the last segment of the profile flashes in the display and the 1. Insert the key into the console. last segment ends. The walking belt will then slow to a stop, and the deck will return to its minumum See HOW TO TURN ON THE POWER on page 15.
- Page 18 HOW TO CONNECT YOUR TABLET TO THE 5. Disconnect your tablet from the console if CONSOLE desired. The console supports Bluetooth connections to tab- To disconnect your tablet from the console, first lets via the iFit–Smart Cardio Equipment app and to select the disconnect option in the iFit–Smart compatible heart rate monitors.
- Page 19 THE INFORMATION MODE 3. Change settings as desired. The console features an information mode that keeps Incline System Calibration—The letters INC will track of treadmill usage information and allows you to appear in the upper display, and the letters UP and view and change the console settings.
- Page 20 HOW TO USE THE SOUND SYSTEM THE OPTIONAL CHEST HEART RATE MONITOR To play music or audio books through the console Whether your sound system while you exercise, plug a 3.5 mm male goal is to to 3.5 mm male audio cable (not included) into the burn fat or to jack on the console and into a jack on your personal strengthen your...
-
Page 21: Fcc Information
FCC INFORMATION This console has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. -
Page 22: How To Fold And Move The Treadmill
HOW TO FOLD AND MOVE THE TREADMILL HOW TO FOLD THE TREADMILL HOW TO MOVE THE TREADMILL Before folding the treadmill, remove the key and Before moving the treadmill, fold it as described at the unplug the power cord. CAUTION: You must be left. -
Page 23: Maintenance And Troubleshooting
MAINTENANCE AND TROUBLESHOOTING MAINTENANCE c. Check the power switch located on the treadmill frame near the power cord. If the switch protrudes Regular maintenance is important for optimal per- as shown (A), the switch has tripped. To reset the formance and to reduce wear. Inspect and properly power switch, wait for five minutes and then press tighten all parts each time the treadmill is used. - Page 24 SYMPTOM: The walking belt slows when walked on SYMPTOM: The walking belt is off-center or slips when walked on a. Use only a surge suppressor that meets all of the specifications described on page 13. a. If the walking belt is off-center, first remove the key and UNPLUG THE POWER CORD.
-
Page 25: Exercise Guidelines
EXERCISE GUIDELINES Burning Fat—To burn fat effectively, you must exer- cise at a low intensity level for a sustained period of WARNING: Before beginning this time. During the first few minutes of exercise, your or any exercise program, consult your physi- body uses carbohydrate calories for energy. - Page 26 SUGGESTED STRETCHES The correct form for several basic stretches is shown at the right. Move slowly as you stretch —never bounce. 1. Toe Touch Stretch Stand with your knees bent slightly and slowly bend forward from your hips. Allow your back and shoulders to relax as you reach down toward your toes as far as possible.
-
Page 27: Part List
PART LIST Model No. PFTL39619.0 R1220A Key No. Qty. Description Key No. Qty. Description M10 x 58mm Screw Left Foot Cover M10 x 25mm Screw Idler Roller #8 x 3/4" Screw Hood Cover M8 x 50mm Screw Hood #10 x 3/4" Screw Frame Spacer 1/4"... -
Page 28: Exploded Drawing
EXPLODED DRAWING A Model No. PFTL39619.0 R1220A... - Page 29 EXPLODED DRAWING B Model No. PFTL39619.0 R1220A...
- Page 30 EXPLODED DRAWING C Model No. PFTL39619.0 R1220A...
- Page 31 EXPLODED DRAWING D Model No. PFTL39619.0 R1220A...
-
Page 32: Ordering Replacement Parts
ORDERING REPLACEMENT PARTS To order replacement parts, please see the front cover of this manual. To help us assist you, be prepared to provide the following information when contacting us: • the model number and serial number of the product (see the front cover of this manual) •...
