- Page 1 UPort™ 1400/1600-G2 Series Quick Installation Guide Version 1.0, October 2023 Technical Support Contact Information www.moxa.com/support 2023 Moxa Inc. All rights reserved. P/N: 1802014000110 *1802014000110*...
-
Page 2: Package Checklist
Overview Moxa’s USB-to-serial products provide a wide range of easy-to-use solutions for adding Windows COM ports, macOS, and Linux tty ports through the USB port of a computer. The UPort 1400/1600-G2 Series comprises the following models: 4-port Models UPort 1410-G2 RS-232 USB-to-serial converter 0 to 60°C (32 to 140°F) -
Page 3: Hardware Introduction
CBL-USB3-BA-G-120 for all models except for the UPort 1650-8-G2-Hub, 1.2 m, with hook and screw CBL-USB3-BA-G-028 for the UPort 1650-8-G2-Hub, 28 cm, with hook and screw • 100 to 240 VAC power adapter (only included for UPort 1650I-8-G2 and UPort 1650-8-G2-Hub models) •... - Page 4 Front View Back View USB Cable Usage Guide The new Moxa latch USB cable comes with a latch on each side of the Type-A connector and a screw on the Type-B connector. Plugging in the USB Cable Using Type A Connector To plug in the USB cable to the host computer and secure it, do the following: Step 1: Press both latches on the...
- Page 5 Removing the USB Cable Step 1: Press both latches on the Step 2: Unplug and pull out the USB cable connector hard cable 90 degrees horizontal to the so that they are pushed to the USB socket. maximum. ATTENTION Be cautious when plugging in or out the latch connector. 1.
-
Page 6: Led Indicators
Pulling out a USB cable from the host computer Step 1: Swivel the bolt about five rounds until it is loose. Step 2: Pulling out type B connector. LED Indicators The LED indicators on the front panel are used to display the status as follows: Function Color... -
Page 7: Adjustable Pull High/Low Resistors For The Rs-485 Port
Adjustable Pull High/low Resistors for the RS-485 Port The UPort uses DIP switches to set the pull high/low resistor values for each serial port. To set the pull high/low resistors to 150 KΩ, make sure both SW 1 and SW 2 switches are in the OFF position. This is the default setting. To set the pull high/low resistors to 1 KΩ, make sure both SW 1 and SW 2 switches are in the ON position. -
Page 8: Software Installation
Software Installation To install the UPort driver, please follow the installation procedure described in the Mounting the UPort 1400/1600-G2 section. UPort converters can be connected to any upstream type A USB port that is on the PC host or an upstream hub. UPort converters are hot- pluggable, and therefore there is no need to power down your computer prior to installation. -
Page 9: Installing The Linux Driver
3. Check Launch Windows Driver Manager to configure the UPort after the setup is completed. 4. If you have installed ViewCOM, you can mouse over the ViewCOM icon in the system tray to see COM port information. The right-click context menu has the shortcut to Windows Device Manager and Auto Startup utilities if needed. -
Page 10: Communication Testing
Installing the Linux Driver for Arm-based Platforms Please refer to the Tech Note: UPort Driver Arm-based Platform Porting Guide on the product page or the readme.txt that comes with the driver package. Installing the macOS Driver For macOS 10.12 and later, follow the steps below to install the driver: 1. -
Page 11: Screw Information
First, attach the brackets to the bottom of the UPort 1400-G2 with screws, where the circles show. The recommended screw tightening torque: 4.5 kgf-cm +/- 0.5, screw type: type F, PH2. Next, mount the unit to a wall with the screws. Screw information: Type Quantity... - Page 12 Next, mount the UPort 1400-G2 onto the mounting rail. STEP 1: Insert the upper lip of STEP 2: Press the UPort 1400-G2 the DIN-rail kit into the mounting towards the mounting rail until it rail. snaps into place. To remove the UPort 1400-G2 from the DIN rail, do the following: STEP 1: Pull down the latch on the DIN-rail kit with a screwdriver.
- Page 13 First, attach the brackets to the bottom of the UPort 1600-G2 with screws, where the circles show. The recommended screw tightening torque: 4.5 kgf-cm +/- 0.5, screw type: type F, PH2. Next, mount the unit to a wall with the screws. Screw information: Type Quantity...
-
Page 14: Product Specifications
Next, mount the UPort 1600-G2 onto the mounting rail. STEP 1: Insert the upper lip of STEP 2: Press the UPort 1600-G2 the DIN-rail kit into the mounting towards the mounting rail until it rail. snaps into place. To remove the UPort 1600-G2 from the DIN rail, do the following: STEP 1: Pull down the latch on the DIN-rail kit with a screwdriver. -
Page 15: Federal Communications Commission Statement
Power Requirements Most of the UPort G2 models can be powered up by USB bus power. Please refer to the table below to find out how your model can be powered on: USB 2.0 bus USB 3.2 bus Power adapter power (0.5A) power (0.9A) 12-48 VDC... - Page 16 FCC Warning This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
