CLOCKstep:MULTI
Global Se ngs (con nued)
Brightness
Press this bu on to choose the brightness of the display lights. 16 selec ons
are available.
Audio Sync OUT Enable
You can turn the Audio Output of CS:M into a 24 PPQN audio clock source. This
can be useful for sending the signal into another CS:M's Audio Input to sync
them together, or you can use the signal with any device that will accept 24
PPQN audio pulses.
When using this feature, all Metronome func ons within CS:M will be disabled
and the Audio Output becomes dedicated to this task.
Green = ON, Red = OFF
Trigger Time
The CV signals that are sent from the 3.5mm TRS Patch Bay will stay "HIGH" for
specific number of milliseconds. Some devices that receive these impulses will
may require a very sepcific length of pulse. Use this se ng to set the length of
each pulse that CS:M sends between 1-16 milliseconds (default = 8ms).
Force External Clock
Normally, when CS:M's internal clock is not running, it will auto detect any valid
incoming clock signal and begin following it.
By turning this se ng on, you can instruct CS:M to only follow incoming clock
signals and completely disable CS:M's internal clock. Any func on that would
normally start or stop the internal clock will no longer do so.
A se ng like this can be an advantage if your workflow requires that you use a
certain combina on of Transport Mode and Transport Start/Stop commands
along with an External clock, completely preven ng CS:M from sending it's own
clock signals.
Green = ON, Red = OFF
