- Page 1 ED150A active point source loudspeaker USER MANUAL revision 2023-09-01...
- Page 2 IMPORTANT SAFETY INSTRUCTIONS Watch for these symbols: The lightning flash with arrowhead symbol within an equilateral triangle is intended to alert the user to the presence of uninsulated “dangerous voltage” within the product’s enclosure, that may be of sufficient magnitude to constitute a risk of electric shock to persons.
- Page 3 FEDERAL COMMUNICATIONS COMMISSION (FCC) STATEMENT This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications.
-
Page 4: Table Of Contents
PROEL CORE digital signal processing and the integrated Class D amplifier module. The ED150A consists of an 15” LF drive unit and a 1.4” HF compression driver loaded by an asymmetric HF horn in a compact enclosure, designed for many multi-purpose sound reinforcement activities. The asymmetric HF h60°... -
Page 5: Mechanical Drawing
MECHANICAL DRAWING INSTRUCTION FOR ROTATING THE HORN 1) Remove the speaker grid unscrewing the twelve screws indicated below. 40 cm 45 cm M8 Aiming Point 15.8" 17.7" Pole Adapter M10 Flying Point M10 Flying Point M10 Flying Point turn 90° M10 Flying Point 2) Unscrew the 4 screws fixing the horn and rotate the horn by 90°. -
Page 6: I/O And Control Operations
I/O AND CONTROL OPERATIONS MAINS IN Powercon® NAC3FCA power input connector (blue). To switch the amplifier on, insert the Powercon® connector and turn it clockwise into the ON position. To switch the amplifier off, pull back the switch on the connector and turn it counter-clockwise into the POWER OFF position. MAINS OUT Powercon®... -
Page 7: Preset Button
STANDARD. If you want to modify it, you have to connect the unit to a PC, edit the parameters with PRONET AX software and save the PRESET into USER MEMORY no. 1. Note: see also the PRONET example further on this manual. ED150A - PRESET RESPONSE STANDARD MONITOR... -
Page 8: Pronet Ax
Download the PRONET AX app registering on MY AXIOM at the website at https://www.axiomproaudio.com/. The AXIOM active loudspeaker devices can be connected in a network and controlled by the PRONET AX software, for the network connection the USB2CAND converter optional accessory is needed. - Page 9 Assign the ID number To work properly in a PRONET AX network each connected device must have a unique identifier number, called ID. By default the USB2CAN-D PC controller has ID=0 and there can be only one PC controller. Every other device connected must have its own unique ID equal or greater than 1: in the network cannot exist two devices with the same ID.
-
Page 10: Horn Orientation
HORN ORIENTATION ED150A features an asymmetrical horn that can be rotated in a few minutes for obtaingn the best coverage according to the speaker configuration. VERTICAL POSITION FOH CONFIGURATION HORIZONTAL POSITION HORIZONTAL POSITION FOH CONFIGURATION STAGE MONITOR CONFIGURATION Tight dispersion... -
Page 11: Kpted150B Wall Or Truss Mounting
KPTED150B WALL or TRUSS MOUNTING Using the “C” shape bracket the ED150A loudspeaker can be installed to walls or mounted to trusses in combination combining with two PLH300. It allows to aim the speaker in one direction (vertical or horizontal) in 21 steps (0°, ±5°, ±10°, ±15°, ±25°, ±30°, ±40°, ±45°, ±55°, ±70°, ±85°). - Page 12 PROEL S.p.A. (World Headquarters) - Via alla Ruenia 37/43 - 64027 Sant’Omero (Te) - ITALY Tel: +39 0861 81241 Fax: +39 0861 887862 www.axiomproaudio.com...
