Summary of Contents for Axiom ED60P
- Page 1 ED60P passive point source loudspeaker USER MANUAL revision 2023-08-31...
- Page 2 IMPORTANT SAFETY INSTRUCTIONS Watch for these symbols: The lightning flash with arrowhead symbol within an equilateral triangle is intended to alert the user to the presence of uninsulated “dangerous voltage” within the product’s enclosure, that may be of sufficient magnitude to constitute a risk of electric shock to persons.
- Page 3 DECLARATION OF CONFORMITY The product is in compliance with: RoHS Directive 2011/65/EU and 2015/863/EU, WEEE Directive 2012/19/EU. The product is in compliance with: S.I. 2012/3032 The Restriction of the Use of Certain Hazardous Substances in Electrical and Electronic Equipment Regulations 2012 LIMITED WARRANTY Proel warrants all materials, workmanship and proper operation of this product for a period of two years from the original date of purchase.
-
Page 4: Table Of Contents
Passive ED series loudspeaker systems are easy to set up and simple to operate. The ED60P consists of an 6.5” LF drive unit and a 1” HF compression driver loaded by an asymmetric HF horn in a compact enclosure, designed for many multi-purpose sound h70°... -
Page 5: Mechanical Drawing
Also available with black finish. NL4FX Neutrik Speakon® PLUG see http://www.axiomproaudio.com for detailed description and other available accessories. SPARE PARTS NL4MP 98AXM6W16 Neutrik Speakon® panel socket 6.5’’ woofer - 1.5” VC 91CR0070 ED60P Crossover PCBA 98DRICDX1-1070 1’’ - 1” vc compression driver... -
Page 6: Input
The number of ED60P cabinets that can be connected in parallel depends on the amplifier load capacity. HORN ORIENTATION ED60P features an asymmetrical horn that can be rotated in a few minutes for obtaingn the best coverage according to the speaker configuration. VERTICAL POSITION FOH CONFIGURATION �ght dispersion... -
Page 7: Kpted60B Wall Or Truss Mounting
KPTED60B WALL or TRUSS MOUNTING Using the “C” shape bracket the ED60P loudspeaker can be installed to walls or mounted to trusses in combination combining with a PLH295. It allows to aim the speaker in one direction (vertical or horizontal) in 7 steps (-22.5°,-15°,-7.5°,0°,+7.5°,+15°,+22.5°). - Page 8 PROEL S.p.A. (World Headquarters) - Via alla Ruenia 37/43 - 64027 Sant’Omero (Te) - ITALY Tel: +39 0861 81241 Fax: +39 0861 887862 www.axiomproaudio.com...
