- Page 1 User’s Manual 6-Port Fast Ethernet Switch with 4-Port PoE User’s Manual ZHEJIANG DAHUA VISION TECHNOLOGY CO., LTD. V1.0.1...
-
Page 2: Foreword
This manual introduces the features and structure of 6-Port Fast Ethernet Switch with 4-Port PoE (hereinafter referred to as "the Device"). Models DH-PFS3006-4ET-36 Safety Instructions The following categorized signal words with defined meaning might appear in the manual. Signal Words... - Page 3 User’s Manual electronic version shall prevail. All the designs and software are subject to change without prior written notice. The product updates might cause some differences between the actual product and the manual. Please contact the customer service for the latest program and supplementary documentation. There still might be deviation in technical data, functions and operations description, or errors ...
-
Page 4: Important Safeguards And Warnings
User’s Manual Important Safeguards and Warnings The manual helps you to use our product properly. To avoid danger and property damage, read the manual carefully before using the product, and we highly recommend you to keep it well for future reference. -
Page 5: Table Of Contents
User’s Manual Table of Contents Foreword ................................I Important Safeguards and Warnings ......................III 1 Product Overview ............................1 Introduction ....................................1 Features ......................................1 Typical Application ..................................1 2 Device Structure ............................2 Front Panel ....................................2 Rear Panel ..................................... 2 PoE Power Supply .................................. -
Page 6: Product Overview
User’s Manual Product Overview Introduction 6-Port Fast Ethernet Switch with 4-Port PoE is a type of layer 2 commercial switch, which supports Ethernet power supply. It provides four 10/100 Mbps Ethernet ports and two 100 Mbps uplink ports. Features Layer 2 commercial switch. ... -
Page 7: Device Structure
User’s Manual Device Structure Front Panel Front panel Table 2-1 Description of front panel Name Description Uplink1–Uplink2 10/100 Base-T, two 10/100 Mbps self-adaptive uplink ports. 10/100 Base-T, four 10/100 Mbps self-adaptive PoE power supply PoE1–PoE4 ports. PD Alive When PD Alive is on, IPC can be kept alive. In extend mode, data can be transmitted up to 250 m in CAT6 cable Extend Mode with a bandwidth of 10 M. -
Page 8: Poe Power Supply
User’s Manual PoE Power Supply Four 100M RJ45 ports support IEEE802.3af and IEEE802.3at standard power supply. -
Page 9: Cybersecurity Recommendations
User’s Manual Cybersecurity Recommendations Cybersecurity is more than just a buzzword: it’s something that pertains to every device that is connected to the internet. IP video surveillance is not immune to cyber risks, but taking basic steps toward protecting and strengthening networks and networked appliances will make them less susceptible to attacks. - Page 10 User’s Manual between 1024–65535, reducing the risk of outsiders being able to guess which ports you are using. Enable HTTPS We suggest you to enable HTTPS, so that you visit Web service through a secure communication channel. MAC Address Binding We recommend you to bind the IP and MAC address of the gateway to the device, thus reducing the risk of ARP spoofing.
- Page 11 User’s Manual Enable IP/MAC address filtering function to limit the range of hosts allowed to access the device. More information Please visit Dahua official website security emergency response center for security announcements and the latest security recommendations.
- Page 12 User’s Manual...
