sauder.com
Storage Cabinet
Soft Modern Collection | 415007
Need help? Visit Sauder.com to view video assembly tips or chat with a live rep.
Prefer the phone? Call 1-800-523-3987.
Share your journey!
Your holder for all
things awesome.
NOTE: THIS INSTRUCTION
BOOKLET CONTAINS IMPORTANT
SAFETY INFORMATION.
PLEASE READ AND KEEP FOR
FUTURE REFERENCE.
English pg 1-15
Français pg 16-17
Español pg 18-20
Lot # 355337
09/30/13
Purchased: __________________
Be sure to give us a ring before
making any returns. 1-800-523-3987
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Sauder Soft Modern 415007
Summary of Contents for Sauder Soft Modern 415007
- Page 1 Soft Modern Collection | 415007 NOTE: THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. Need help? Visit Sauder.com to view video assembly tips or chat with a live rep. PLEASE READ AND KEEP FOR Prefer the phone? Call 1-800-523-3987. FUTURE REFERENCE.
- Page 2 Table of Contents Assembly Tools Required Part Identifi cation No. 2 Phillips Screwdriver Tip Shown Actual Size Hardware Identifi cation Assembly Steps 5-15 Hammer Not actual size Français 16-17 Español 18-20 Safety 21-22 Warranty Page 2 415007 www.sauder.com/services...
- Page 3 RIGHT FRONT/LEFT REAR FOOT (2) TOP (1) LEFT FRONT/RIGHT REAR FOOT (2) BOTTOM (1) LEFT FRONT/RIGHT REAR SIDE FOOT (2) BACK (1) RIGHT FRONT/LEFT REAR SIDE FOOT (2) RIGHT DOOR (1) FRONT/BACK SKIRT (2) LEFT DOOR (1) SIDE SKIRT (2) www.sauder.com/services 415007 Page 3...
- Page 4 METAL BRACKET - 6 METAL PIN - 12 PULL - 2 NAIL - 28 RUBBER SLEEVE - 4 BLACK 9/16" LARGE HEAD SCREW - 36 BLACK 1/2" FLAT HEAD SCREW - 8 GOLD 1" MACHINE SCREW - 2 Page 4 415007 www.sauder.com/services...
- Page 5 Assemble your unit on a carpeted fl oor or on the empty å carton to avoid scratching your unit or the fl oor. To begin assembly, push a SAUDER TWIST-LOCK® å FASTENER (7F) into the large holes in the ENDS (A and B).
- Page 6 Push four HIDDEN CAMS (1F) into the BOTTOM (D). å Then, insert the metal end of a CAM DOWEL (2F) into each HIDDEN CAM. Arrow (4 used) (4 used) Arrow Insert the metal end of the CAM DOWEL into the HIDDEN CAM. Page 6 415007 www.sauder.com/services...
- Page 7 Tighten Risk of damage or Arrow injury. HIDDEN CAMS must be completely Arrow Maximum tightened. HIDDEN 210 degrees CAMS that are not completely tightened may loosen, and parts may separate. To Minimum completely tighten: 190 degrees www.sauder.com/services 415007 Page 7...
- Page 8 Step 4 Fasten the TOP (C) to the ENDS (A and B). Tighten å How to use the SAUDER TWIST-LOCK ® FASTENER four TWIST-LOCK® FASTENERS. 1. Insert the dowel end of the FASTENER into the hole of the adjoining part.
- Page 9 Make equal margins along all four edges of the BACK (E). å Push on opposite corners of your unit if needed to make it “square”. Fasten the BACK (E) to your unit using the NAILS (1N). å NAIL (28 used in this step) www.sauder.com/services 415007 Page 9...
- Page 10 Now, fasten the FEET (I and J) to the SIDE FEET (K and L). å Use eight BLACK 9/16” LARGE HEAD SCREWS (1S). BLACK 9/16" LARGE HEAD SCREW (22 used for the BRACKETS) Angled edge Angled edge Angled edge Page 10 415007 www.sauder.com/services...
- Page 11 SKIRTS. Fasten the SKIRTS (M and N) and FEET (I, J, K and L) å to the BOTTOM (D). Use fourteen BLACK 9/16” LARGE HEAD SCREWS (1S) through the BRACKETS and into the BOTTOM. (8 used) www.sauder.com/services 415007 Page 11...
- Page 12 Fasten two HINGES (13H) to each DOOR (F and G). å Use eight BLACK 1/2" FLAT HEAD SCREWS (11S). Mounting screw Adjusting screw BLACK 1/2” FLAT HEAD SCREW (8 used in this step) Adjusting screw Mounting screw Page 12 415007 www.sauder.com/services...
- Page 13 HINGES. See the next step for adjustments. Fasten a PULL (85K) to the LEFT DOOR (G). Use a GOLD å 1” MACHINE SCREW (50S). Repeat this step for the RIGHT DOOR (F). å GOLD 1" MACHINE SCREW (2 used in this step) www.sauder.com/services 415007 Page 13...
- Page 14 Tighten the screws after making adjustments. To adjust the DOORS in or out (depth), loosen the å mounting screw one turn and move the DOORS in or out, as needed. Tighten the mounting screw after making adjustments. Page 14 415007 www.sauder.com/services...
- Page 15 This completes assembly. To clean your unit, dampen a å cloth with tap water and wipe. And to celebrate, why not share your success story? 50 lbs. 25 lbs. 30 lbs. (4 used) www.sauder.com/services 415007 Page 15...
- Page 16 QUANTITÉ d’ a chat de cet élément et conserver le livret pour future référence. EXTRÉMITÉ DROITE ..........1 EXCENTRIQUE ESCAMOTABLE .....4 Pour contacter Sauder EXTRÉMITÉ GAUCHE ..........1 CHEVILLE D’EXCENTRIQUE.......4 en ce qui concerne cet DESSUS ................1 FIXATION TWIST-LOCK® ........4 élément, faire référence au numéro de lot et...
- Page 17 Pour commencer l’ a ssemblage, enfoncer une FIXATION TWIST-LOCK® DESSOUS (D) comme l’indique le schéma inférieur. SAUDER (7F) dans les gros trous des EXTRÉMITÉS (A et B). REMARQUE : S’ a ssurer de bien insérer les GOUPILLES EN MÉTAL situées ÉTAPE 2...
- Page 18 EXCÉNTRICO ESCONDIDO .......4 et conserver le livret pour future référence. EXTREMO IZQUIERDO ............1 PASADOR DE EXCÉNTRICO ......4 Pour contacter Sauder PANEL SUPERIOR ..............1 SUJETADOR TWIST-LOCK® ........4 en ce qui concerne cet FONDO .................... 1 15F PASADOR DE MADERA .........4 élément, faire référence...
- Page 19 Desdoble el DORSO (E) y colóquelo sobre la Para comenzar el ensamblaje, empuje un SUJETADOR TWIST- unidad. LOCK® SAUDER (7F) dentro de los agujeros grandes de los EXTREMOS (A y B). Los márgenes a lo largo de todos los bordes del DORSO (E) deben estar uniformes.
- Page 20 NOTA: Por favor, lea las páginas de atrás del folleto de instrucciones en cuanto a importante información de seguridad. Esto completa el ensamblaje. Para limpiar la unidad, humedezca un paño con agua de llave y limpie. Page 20 415007 www.sauder.com/services...
- Page 21 équipé • Blessure physique. Le mobilier peut • Ne pas pousser le mobilier, surtout sur la être très lourd. moquette. Se faire aider par une autre personne pour soulever l’élément et le mettre en place www.sauder.com/services 415007 Page 21...
- Page 22 • Lesión física. El mobiliario puede ser muy mobiliario. pesado. • No empuje la unidad, especialmente sobre un piso alfombrado. Pide la ayuda de otra persona para levantar la unidad y colocarla en lugar. Page 22 415007 www.sauder.com/services...
- Page 23 GARANTIE LIMITÉE DE 5 ANS 1. Sauder Woodworking Co. (Sauder®) off re une couverture de garantie limitée à l’ a cheteur 4. La présente garantie ne s’ a pplique qu’ a ux défauts garantis qui se produisent pour initial du présent produit pendant une période de cinq ans à...
- Page 24 Dear Valued Customer: So, how did it go? Thanks so much for choosing Sauder® furniture. I hope the Set a world record for speed? purchase and assembly process was a positive experience Feeling good about yourself? and you feel good about the furniture you just built. If you Nice.
