415137
Queen Footboard with Rails
Carson Forge Collection
PLEASE CONTACT US
BEFORE RETURNING
YOUR UNIT TO THE STORE
1-800-523-3987
www.sauder.com
NOTE: THIS INSTRUCTION BOOKLET CONTAINS
IMPORTANT SAFETY INFORMATION.
PLEASE READ AND KEEP FOR FUTURE REFERENCE.
English .................... Page 1-14
Français ...............Pages 15-16
Made in the USA
Espanol .............Páginas 17-18
Archbold, OH
Lot #: 354959
Date Purchased: ____________________
08 / 30 / 13
