Sauder Beginnings 415544 Assembly Instructions Manual
  1. Manuals
  2. Brands
  3. Sauder Manuals
  4. Indoor Furnishing
  5. Beginnings 415544
  6. Assembly instructions manual

Sauder Beginnings 415544 Assembly Instructions Manual

Night stand
Hide thumbs

Advertisement

Quick Links

Download this manual
sauder.com
Night Stand
Beginnings Collection | Model 415544
Need help? Visit Sauder.com to view video assembly tips or chat with a live rep.
Prefer the phone? Call 1-800-523-3987.
Share your journey!
Sweet stand.
Sweet dreams.
NOTE: THIS INSTRUCTION
BOOKLET CONTAINS IMPORTANT
SAFETY INFORMATION.
PLEASE READ AND KEEP FOR
FUTURE REFERENCE.
English pg 1-15
Français pg 16-18
Español pg 19-21
Lot # 389977
04/14/16
Purchased: __________________
Be sure to give us a ring before
making any returns. 1-800-523-3987
