Technical Specifications - MULTISPAN MSU 1244U-M1 Product Manual

Product Inception
SCROLL
USB
Storage
Full

Indication


USB
Port

To go to
Parameter
Setting

Technical Specifications

Model
Display
Size (mm)
Panel Cutout
Inputs and
Range
Output
Power Supply
Operating
Temperature
Relative
Humidity
MSU-1244U-M1
SCANNER
5 0 0
3Low
SCROLL
!
R1
T/H
T/H
CH 1 2
CH
H/L
H/L
SET
To change the value
or select option
UPPER: 4 Digit 7 seg 0.70",
LOWER: 4 Digit 7 seg 0.50",
Thermocouple
J 0 to 600°C
K 0 to 1200°C
4 Relay (NO-C-NC) 1C/O 5A@230V AC, 5A for resistive load
with RS-485 RTU MODBUS & USB Data Logger Facility
100 to 270V AC,50/60 Hz, Approx7VA
Up to 95% RH Non Condensing
Page
-
1
MSU 1244U-M1
R2 R3 R4
3 4
CUT
ENT
MSU 1244U-M1
RED LED Display
GREEN
96 (H) X 96 (W) X 50 (D) mm
92 X 92 mm
Analog input Range
}
0 - 10V DC
-999 To 9999
0 - 20mA DC
4 - 20mA DC
0°C To 55°C
Upper Display
( RED )
Lower Display
( GREEN
4 Relay Indication
Alarm Indication
every channel
To save changes
in settings
LED Display
RTD
PT-100/3W -99 to 400°C
PT.1/3W -99.0 to 400.0°C
