Product Manual
8 Channel Scanner
with USB Data Logger
and RS-485 Communication
MSU 1248U-M1
Multispan Control Instruments Pvt Ltd
72/B, Phase 1, GIDC Estate, Vatva, Ahmedabad-382445, Gujarat, India.
+91-79-40029250
+91-9978991471
marketing@multispanindia.com
www.multispanindia.com
MSU-1248U-M1
www.multispanindia.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MSU 1248U-M1 and is the answer not in the manual?

Questions and answers

Mahesh Sanghani
June 18, 2025

hOW T OCONNECT 3 WIRE SENSOR ?

0

Subscribe to Our Youtube Channel

Related Manuals for MULTISPAN MSU 1248U-M1

Summary of Contents for MULTISPAN MSU 1248U-M1

  • Page 1 Product Manual 8 Channel Scanner with USB Data Logger and RS-485 Communication MSU 1248U-M1 Multispan Control Instruments Pvt Ltd 72/B, Phase 1, GIDC Estate, Vatva, Ahmedabad-382445, Gujarat, India. +91-79-40029250 +91-9978991471 marketing@multispanindia.com www.multispanindia.com MSU-1248U-M1 www.multispanindia.com...
  • Page 2 Product Inception SCANNER MSU 1248U-M1 5 0 0 Upper Display USB Copy indication Lower Display 7Low GREEN SCROLL SCROLL USB Full Storage Indication 4 Relay Indication Alarm Indication every channel USB Port To go to To save changes Parameter in settings...
  • Page 3 Procedure 1) Do all connections as per the wiring diagram. To Configure: 1. Input Selection (J, K, PT-100, PT.1, 0 - 10V DC, 0 - 20mA DC & 4 - 20mA DC). 2. Relay mode - If 1 Relay per group - If 2 Relay per group LOW / HIGH HIGH...

  • Page 4: Input Selection

    Key Operation 1) Press key to enter in set value menu. Note :- Values can be changed 2) Press & Key to change the parameter setting. by pressing keys. 3) Press Key to enter in parameter menu (Input selection, skip-unskip selection) 4) Press Key to enter in group menu for relay mode selection.

  • Page 5: Set Point Selection

    Main Menu: To change set value & hystersis based on relay mode Note: Set value can be changed by key. MENU-3 Set point Selection Press key 2 Second. Low / High set point-1 L5-1 Press key. High / Trip set point for Group1, H5-1 (Repeat the same procedure for all 4 group).

  • Page 6: For Example

    Note :- Values can be changed by pressing keys. For Example: In Group No 1, If 1st channel, have a set point as a high alarm, 1 relay. In Group No 2 If 2nd channel, have a set point as a low alarm, 1 relay. For, 3rd, 4th, 5th, 6th, 7th, 8th channel have a set point as high &...
  • Page 7 MENU-4 Note:-Valuescanbechanged AnalogRangeselection bypressingorkeys. Press+key. Analog ANLg Presskey. DecimalPoint. 00.00 Presskey. Lowrangechannel1. 00.00 Lr-1 Presskey. 00.00 (Repeatthesameprocedureforall8channels). Lr 8 Presskey. Highrangechannel1. 20.00 Hr01 Presskey. 20.00 (Repeatthesameprocedureforall8channels). Hr 8 Presskey. Presskeytosave&exit. NOTE: DP(DecimalPoint)isCommonforallchannels. Positioncanbechangedbypressingorkeys. MSU-1248U-M1 Page-6 www.multispanindia.com...
  • Page 8 Note: Set value can be changed by key. MENU-5 Offset and Correction factor selection Press key to change offset. Ofst Offset Press key. Offset for channel 1. Of 1 Press key. (Repeat the same procedure for all 8 channels). Of 8 Press key.

  • Page 9: Communication Parameter

    Note :- Values can be changed MENU-6 by pressing keys. Communication Parameter Press & key to access Communication Parameter. (1- 127) Addr Device Address. Press key. 9600 ( 4800 / 9600 /19200 ). Baud Baud-rate. Press key. nOne ( None / Even / Odd ). prty Parity.

  • Page 10: Modbus Setting

    Modbus Setting 1) Device Address 1 to 127 2) Baud-rate 4800 , 9600 , 19200 (bps) 3) Parity None , Even , Odd 4) Data Type Sign Integer , Float, Long 5) Frame Delay 0 to 99 Data Type = Sign Integer Data Type = Long Read Function Read Function...
  • Page 11 30064 40064 30032 40032 High Range 5 30066 40066 30033 40033 High Range 6 30068 40068 30034 40034 High Range 7 High Range 8 30070 40070 30035 40035 30074 40074 30037 40037 Offset Channel 1 Offset Channel 2 30076 40076 30038 40038 Offset Channel 3...
  • Page 12 30222 40222 40111 PV Channel 1 30111 30224 PV Channel 2 40224 30112 40112 PV Channel 3 30226 40226 40113 30113 30228 PV Channel 4 40228 30114 40114 18000-chnnel skip PV Channel 5 30230 40230 40115 30115 15000-open 30232 PV Channel 6 40232 30116 40116...
  • Page 13 MSU-1248U-M1 Page-12 www.multispanindia.com...

  • Page 14: Mechanical Installation

    Mechanical Installation Right Side View Top View MODEL 96mm 96mm 94mm 94mm 53mm 56mm DIMENSIONS MSU-1248U-M1 Page-13 www.multispanindia.com...

  • Page 15: Safety Precautions

    Safety Precautions All safety related codifications, symbols and instructions that appear in this operating manual or on the equipment must be strictly followed to ensure the safety of the operating personnel as well as the instrument. If all the equipment is not handled in a manner specified by the manufacturer, it might impair the protection provided by the equipment .
  • Page 16 Note : Product improvement and upgrade is a constant procedure. So for more updated operating information and support, Please contact our helpline : +91-9081078681 /9081078683 or Email at : service@multispanindia.com ver :- 2102 MSU-1248U-M1 Page-15 www.multispanindia.com...
