- Page 1 Product Manual 8 Channel Scanner with USB Data Logger MSU 1248U Multispan Control Instruments Pvt Ltd 72/B, Phase 1, GIDC Estate, Vatva, Ahmedabad-382445, Gujarat, India. +91-79-40029250 +91-9978991471 marketing@multispanindia.com www.multispanindia.com MSU-1248U www.multispanindia.com...
-
Page 2: Technical Specifications
Product Inception SCANNER MSU 1248U 5 0 0 Upper Display USB Copy indication Lower Display 7Low GREEN SCROLL SCROLL USB Full Storage Indication 4 Relay Indication Alarm Indication every channel USB Port To go to To save changes Parameter in settings... -
Page 3: Terminal Diagram
Procedure 1) Do all connections as per the wiring diagram. To Configure: 1. Input Selection (J, K, PT-100, PT.1, 0 - 10V DC, 0 - 20mA DC & 4 - 20mA DC). 2. Relay mode - If 1 Relay per group - If 2 Relay per group LOW / HIGH HIGH... -
Page 4: Input Selection
Main Menu: To change set value & hystersis based on relay mode & grouping For Example: In Group No 1, If 1st channel, have a set point as a high alarm, 1 relay. In Group No 2 If 2nd channel, have a set point as a low alarm, 1 relay. For, 3rd, 4th, 5th, 6th, 7th, 8th channel have a set point as high &... -
Page 5: Key Operation
Key Operation Note :- Values can be changed by pressing keys. 1) Press key to enter in set value menu. 2) Press & Key to change the parameter setting. 3) Press Key to enter in parameter menu (Input selection, skip-unskip selection) 4) Press Key to enter in group menu for relay mode selection. -
Page 6: Set Point Selection
Note: Set value can be changed by key. MENU-3 Set point Selection Press key 2 Second. Low / High set point-1 L5-1 Press key. High / Trip set point for Group1, H5-1 (Repeat the same procedure for all 4 group). Press key. - Page 7 MENU-4 Note:-Valuescanbechanged AnalogRangeselection bypressingorkeys. Press+key. Analog ANLg Presskey. DecimalPoint. 00.00 Presskey. Lowrangechannel1. 00.00 Lr-1 Presskey. 00.00 (Repeatthesameprocedureforall8channels). Lr 8 Presskey. Highrangechannel1. 20.00 Hr01 Presskey. 20.00 (Repeatthesameprocedureforall8channels). Hr 8 Presskey. Presskeytosave&exit. NOTE: DP(DecimalPoint)isCommonforallchannels. Positioncanbechangedbypressingorkeys. MSU-1248U-M1 Page-6 www.multispanindia.com...
- Page 8 Note: Set value can be changed by key. MENU-5 Offset and Correction factor selection Press key to change offset. Ofst Offset Press key. Offset for channel 1. Of 1 Press key. (Repeat the same procedure for all 8 channels). Of 8 Press key.
-
Page 9: Communication Parameter
Note :- Values can be changed MENU-6 by pressing keys. Communication Parameter Press & key to access Communication Parameter. 1-999. UbtM USB Save Time (Minute) Press key. (Second/Minute) Press key. (0-59) UNIT (Unit) Second. Press key. PASS (0-59) Minute. If password If password is is not 25 Press... - Page 10 MSU-1248U Page-9 www.multispanindia.com...
-
Page 11: Mechanical Installation
Mechanical Installation SCANNER MSU 1248U 5 0 0 7Low SCROLL FRONT VIEW RIGHT SIDE VIEW Panel Cutout Page-10 www.multispanindia.com MSU-1248U... -
Page 12: Safety Precautions
Safety Precautions All safety related codifications, symbols and instructions that appear in this operating manual or on the equipment must be strictly followed to ensure the safety of the operating personnel as well as the instrument. If all the equipment is not handled in a manner specified by the manufacturer, it might impair the protection provided by the equipment .
