Product Manual
4 Channel Scanner
with USB Data Logger
and RS-485 Communication
MSU 1244U-M1
Multispan Control Instruments Pvt Ltd
72/B, Phase 1, GIDC Estate, Vatva, Ahmedabad-382445, Gujarat, India.
+91-79-40029250
+91-9978991471
marketing@multispanindia.com
www.multispanindia.com
MSU-1244U-M1
www.multispanindia.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MSU 1244U-M1 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for MULTISPAN MSU 1244U-M1

Summary of Contents for MULTISPAN MSU 1244U-M1

  • Page 1 Product Manual 4 Channel Scanner with USB Data Logger and RS-485 Communication MSU 1244U-M1 Multispan Control Instruments Pvt Ltd 72/B, Phase 1, GIDC Estate, Vatva, Ahmedabad-382445, Gujarat, India. +91-79-40029250 +91-9978991471 marketing@multispanindia.com www.multispanindia.com MSU-1244U-M1 www.multispanindia.com...

  • Page 2: Technical Specifications

    Product Inception SCANNER MSU 1244U-M1 5 0 0 Upper Display 3Low Lower Display SCROLL GREEN SCROLL USBStorageFull 4 Relay Indication Indication CH 1 Alarm Indication every channel USBPort To go to To save changes Parameter in settings Setting To change the value...

  • Page 3: Terminal Diagram

    Procedure 1) Do all connections as per the wiring diagram. To Configure: 1. Input Selection (J, K, PT-100, PT.1, 0 - 10V DC, 0 - 20mA DC & 4 - 20mA DC). 2. Relay mode - If 1 Relay per group - If 2 Relay per group LOW / HIGH HIGH...

  • Page 4: Key Operation

    Note :- Values can be changed Key Operation by pressing keys. 1) Press key to enter in set value menu. 2) Press & Key to change the parameter setting. 3) Press Key to enter in parameter menu (Input selection, skip-unskip selection) 4) Press Key to enter in group menu for relay mode selection.

  • Page 5: Set Point Selection

    Note: Set value can be changed by key. Main Menu: To change set value & hystersis based on relay mode & grouping MENU-2 Set point Selection Press key 2 Second. Low / High set point-1 L5-1 Press key. High / Trip set point for Group1, H5-1 (Repeat the same procedure for all 4 group).

  • Page 6: For Example

    For Example: In Group No 1, If 1st channel, have a set point as a high alarm, 1 relay. In Group No 2 If 2nd channel, have a set point as a low alarm, 1 relay. For, 3rd, 4th channel have a set point as high & low alarm, 2 relay. Note :- Values can be changed by pressing keys.
  • Page 7 MENU-4 Note:-Valuescanbechanged AnalogRangeselection bypressingorkeys. Press+key. Analog ANLg Presskey. DecimalPoint. 00.00 Presskey. Lowrangechannel1. 00.00 Lr-1 Presskey. 00.00 (Repeatthesameprocedureforall4channels). Lr 4 Presskey. Highrangechannel1. 20.00 Hr01 Presskey. 20.00 (Repeatthesameprocedureforall4channels). Hr 4 Presskey. Presskeytosave&exit. NOTE: DP(DecimalPoint)isCommonforallchannels. Positioncanbechangedbypressingorkeys. MSU-1244U-M1 Page-6 www.multispanindia.com...
  • Page 8 Note: Set value can be changed by key. MENU-5 Offset and Correction factor selection Press key to change offset. Ofst Offset Press key. Offset for channel 1. Of 1 Press key. (Repeat the same procedure for all 4 channels). Of 4 Press key.
  • Page 9 Note :- Values can be changed MENU-6 by pressing keys. Communication Parameter Press & key to access Communication Parameter. (1- 127) Addr Device Address. Press key. 9600 ( 4800 / 9600 /19200 ). Baud Baud-rate. Press key. nOne ( None / Even / Odd ). prty Parity.

  • Page 10: Modbus Setting

    Modbus Setting 1) Device Address 1 to 127 2) Baud-rate 4800 , 9600 , 19200 (bps) 3) Parity None , Even , Odd 4) Data Type Sign Integer , Float, Long 5) Frame Delay 0 to 99 Data Type = Sign Integer Data Type = Long Read Function Read Function...
  • Page 11 30132 40132 Group1 Low Setpoint 30066 40066 Group1 High Setpoint 30134 40134 30067 40067 30136 40136 Group2 Low Setpoint 30068 40068 Group2 High Setpoint 30138 40138 30069 40069 Group3 Low Setpoint 30140 40140 30070 40070 Group3 High Setpoint 30142 40142 30071 40071 30144...
  • Page 12 Page-8 MSU-1244U-M1 www.multispanindia.com...

  • Page 13: Mechanical Installation

    Mechanical Installation Right Side View Top View MODEL 96mm 96mm 92mm 92mm 66mm 69mm DIMENSIONS Page-9 MSU-1244U-M1 www.multispanindia.com...

  • Page 14: Safety Precautions

    Safety Precautions All safety related codifications, symbols and instructions that appear in this operating manual or on the equipment must be strictly followed to ensure the safety of the operating personnel as well as the instrument. If all the equipment is not handled in a manner specified by the manufacturer, it might impair the protection provided by the equipment .
  • Page 15 Note : Page-11 www.multispanindia.com MSU-1244U-M1...
  • Page 16 Note : Product improvement and upgrade is a constant procedure. So for more updated operating information and support, Please contact our helpline : +91-9081078681 /9081078683 or Email at : service@multispanindia.com ver :- 2211 Page-11 www.multispanindia.com MSU-1244U-M1...
