OUTLAW
INSTALLATION MANUAL
2MC/228H
WARNING: To ensure the longevity of
your system, reading and following these
instructions are recommended. Make sure
to change filters and to drain the moisture
from your tank on a regular basis.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 228H and is the answer not in the manual?

Questions and answers

Related Manuals for HornBlasters 228H

Summary of Contents for HornBlasters 228H

  • Page 1 OUTLAW INSTALLATION MANUAL 2MC/228H WARNING: To ensure the longevity of your system, reading and following these instructions are recommended. Make sure to change filters and to drain the moisture from your tank on a regular basis.
  • Page 2 Page 2 HORNBLASTERS OUTLAW 2MC TRAIN HORN KIT CONTENTS • Ear Plugs • Air Source Kit (2MC/228H) • Air line Cutter • HornBlasters Outlaw Train Horn • Mounting Hardware • 20’ 1/2” Airline • HornBlasters Universal Wiring Kit 20 Feet 1/2"...
  • Page 3 • Use eye protection when operating drills or other power tools during the install. • Ensure the parking brake is engaged before you get underneath the vehicle. • Do not wire the system without the fuse holder. • Do not allow the compressor to run when the vehicle is off. www.hornblasters.com support@hornblasters.com...

  • Page 4: Recommended Tools

    • 7/8” Wrench (4-Way Splitter on Valve) • 12mm Wrench / Socket • Wire Cutter / Stripper / Crimp Tool • Drill (8mm Bit) Compatible Add-on Kits (available @ www.HornBlasters.com) Description Part # Name Adds a quick disconnect to your system which allows...
  • Page 5 If and the inner part of the bed. This tire crank mechanism. This not, the placement shown above is cavity offers the best protection from offers great protection from acceptable. moisture/dirt. dirt/moisture. www.hornblasters.com support@hornblasters.com...

  • Page 6: Plumbing Diagram

    Plumbing Diagram Plumbing the air line to the tank and horn Ensure each air line is fully seated over the compression fitting Bad Cut Good Cut before tightening the nut down over it. If the line is not fully seated over the barb, it can slip off the fitting even with the nut in place.
  • Page 7 Preparing For the Install (continued) Recommended Install Locations for Trucks (Compressor) • The toolbox is a great location for the compressor. Do not use the toolbox as a grounding point. • Mounting the compressor/tank in the bed (if covered) is a great option. There's plenty of room available and mounting the compressor will help it run cooler and save space in your toolbox.
  • Page 8 Page 7 6511 N 54th St +1 (813) 783-8058 Tampa, FL 33610 Fax: +1 (813) 783-2407 OUTLAW 2MC AIR SOURCE WIRING DIAGRAM www.hornblasters.com support@hornblasters.com...

  • Page 9: Wiring Instructions

    When you flip the switch on, the relay will switch on and allow the compressor run. Wiring your kit this way means that you MUST turn the switch off with the vehicle, otherwise the compressor could run overnight and drain your battery. www.hornblasters.com sales@hornblasters.com...
  • Page 10 Connecting the Train Horns to the Steering Wheel Page 9 A = 18 Gauge Butt Connector (use to connect two wires together) B = T-Tap / Scotchlok Connector (use to tap off factory horn wire) Connecting the Train Horns to a Push Button...
  • Page 11 If you're not sure which fittings are 1/2", 3/8", or 1/4", measure the thread on each fitting and match it up with the values below. 1/2" NPT 3/8" NPT 1/4" NPT 1/8" NPT 0.84" 0.675" 0.54" 0.405" www.hornblasters.com support@hornblasters.com...

  • Page 12: Troubleshooting

     If the valve is open, the air from the compressor is escaping through it constantly. If the valve is backward, air will escape through it constantly. o Check the compressor's air inlet (only applies if you have a 228H)  If the plug from the inlet was not removed, the compressor cannot suck in air. Remove the filter and remove the plug.
  • Page 13  Check and ensure each air line is secure in the elbow fittings. If one line is loose or disconnected, the other horns will sound muffled due to the loss of air pressure. Can't find your issue listed above? Give our team a call @ (877)-209-8179 or shoot us an email to sales@hornblasters.com www.hornblasters.com support@hornblasters.com...
