- Page 1 Page 1 HORN AIR 500 SERIES INSTALLATION MANUAL WARNING: To ensure the longevity of your system, reading and following these instructions is necessary. Make sure to follow the routine maintenance interval found on the bottom of page 3.
-
Page 2: Kit Contents
Page 2 HORNBLASTERS HORN AIR 5-GALLON INSTALLATION GUIDE KIT CONTENTS: • Air Compressor (model varies) • Air Filter Relocation Kit (in compressor box) • HornBlasters 5-Gallon Air Tank • Air line Cutter • HornBlasters Tank Fitting Kit • HornBlasters Universal Wiring Kit... -
Page 3: Important Safety Instructions
These two steps are essential to keeping your kit up and running for years to come! If you don't drain the tank or change the filters on the compressor, these components will not last as long as they are rated for! www.hornblasters.com support@hornblasters.com... - Page 4 Page 4 Recommended Air Source Install Locations Recommended Install Locations for a car/sedan • The trunk of your car/sedan/suv is a great spot for this air source kit. The trunk keeps the compressor out of the weather and is one of the best install locations for the compressor/tank. The air tank is rather bulky and won't fit in your engine bay (unless you have a huge engine bay).
- Page 5 If the air filter is not relocated, the compressor will pull in water/dirt and will stop working properly. 99.9% of compressors we receive for inspection have pulled in water through the filter housing. WE DO NOT WARRANTY COMPRESSORS THAT HAVE FAILED DUE TO WATER/ DEBRIS BEING PULLED INTO THE INTAKE/FILTER www.hornblasters.com support@hornblasters.com...
- Page 6 Page 6 Recommended Tank Assembly Always make sure the drain cock is facing DOWN. Regardless of how Option 1 you decide to assemble the tank, the drain fitting needs to point down to allow water to drain. Gravity will pull water to the bottom of the tank. Option 2 (Upside down)
- Page 7 The tire inflation kit is an add-on that we recently started to include with Horn Air kits. This kit can be used to inflate tires or run other air tools such as an impact wrench directly from your HornBlasters air tank. The Tire Inflation kit includes a variety of fittings and components such as a blowgun, quick connect studs, and couplers.
- Page 8 Page 8 Wiring the Compressor Compressor Wiring A = 10 GAUGE TAN RING TERMINAL B = PRESSURE SWITCH C = 18 GAUGE RED MALE SPADE CONNECTOR D = 10 GAUGE YELLOW/GREEN FEMALE SPADE CONNECTOR E = AIR COMPRESSOR An ignition/key power source can be any circuit that is hot when the vehicle is on. Good examples of these are the radio, daytime running lights, power seats,cigarette lighter, or even an accessory fuse.
-
Page 9: Troubleshooting
Make sure the compressor's check valve wasn't overtightened If the check valve is overtightened, it will leak back to the compressor and the air will escape from the filter. This may also lead to a blown fuse. www.hornblasters.com support@hornblasters.com... - Page 10 These are made to sound like a real train horn and are backed with a lifetime guarantee by HornBlasters. Part #: AH-S4 Price: $459.99 Outlaw Train Horn The Outlaw Train Horn is great if you have a truck with extra space under the bed.
- Page 11 Page 11 Air Horn Recommendations Safety Air Horn The safety air horn is one of the loudest air horns HornBlasters offers. This horn emulates the sound of air horns heard of emergency vehicles, but with a HornBlasters twist added. The...
- Page 12 Page 12...
