- Page 1 SCT-1SX Series Firmware version 01.21.01 Webserver Manual January 4, 2024 PN 221633 Rev A...
- Page 2 All information contained within this publication is, to the best of our knowledge, complete and accurate at the time of publication. Rice Lake Weighing Systems reserves the right to make changes to the technology, features, specifications and design of the equipment without notice.
-
Page 3: Table Of Contents
Network parameters Web page login Main screen Operating Mode Network Configuration Backup Restore Change Password Sign Out Instrument Information Zero Tare A/D Converter Points Calibration Parameters Calibration Theoretical Calibration Commands Setpoint © Rice Lake Weighing Systems • All Rights Reserved... -
Page 4: Network Connection
It is recommended that you carefully follow the instructions for programming the weight transmitter; performing actions not indicated in this manual could compromise the functionality of the scale. Manuals are available from Rice Lake Weighing Systems at www.ricelake.com/manuals Warranty information is available at www.ricelake.com/warranties... -
Page 5: Network Parameters
Only one PC is allowed to access the instrument's web page at a time, if you login from a second PC, the first one will automatically disconnect. Logging into the instrument web page interrupts the communication with the PLC if the Read only check box is disabled. © Rice Lake Weighing Systems • All Rights Reserved... -
Page 6: Main Screen
Main screen Home Operative Mode Network Backup Restore Change password Sign out Release 6.1 Fieldbus Pro net 22625 Fw release 1.06 GROSS TARE UNIT STATUS ZERO >0< UL TARE IN1 IN2 OUT1 OUT2 123456 PARAMETERS CALIBRATION COMMANDS Cal. points Check stability Unit KEYB. -
Page 7: Operating Mode
Backup By clicking on the "Backup" button the browser starts receiving the instrument configuration. When reception is complete, the "setup.mot" file is automatically downloaded. This file is compatible with the Rice Lake Tools program. Restore By clicking on the "Restore" button you can select a configuration file to load on the instrument. -
Page 8: Change Password
Change Password You can change your login password from this page: Profinet module SN 22625 Password New Password Confirm Password Change password Sign Out Logout from the instrument web page. Instrument Information Shows the weight and status information of the scale: Scale identification number. -
Page 9: Zero
Second range value (not used in single range applications) Division 1 First range division (1, 2, 5, 10, 20, 50) Division 2 Second range division (1, 2, 5, 10, 20, 50) © Rice Lake Weighing Systems • All Rights Reserved... -
Page 10: Calibration
CALIBRATION Calibration Cal. points Check stability Weight mV/V Select the number of calibration points from the drop-down menu. Zero Enter the weight values of the calibration points in the text boxes on the left. Point 1 2000 647484 0.22491 For each point, load the sample weight on the scale and click the corresponding button. The value of ADC points is automatically Point 2 acquired in the text box on the right. -
Page 11: Commands
ZERO CALIB. Zero calibration. Setpoint Set the output function to Gross or Net. (Ref. Quick Start Guide) Enter the output on/off values in the text boxes. WRITE SETPOINTS Save setpoints by clicking © Rice Lake Weighing Systems • All Rights Reserved... - Page 12 NOTES Visit our website www.RiceLake.com...
- Page 14 © Rice Lake Weighing Systems Content subject to change without notice. 230 W. Coleman St. • Rice Lake, WI 54868 • USA USA: 800-472-6703 • International: +1-715-234-9171 www.ricelake.com January 4, 2024 PN 221633 Rev A...
