1 How to insert Nano-SIM card and connect battery

How to insert Nano-SIM card and connect battery

Open the top cover of the device. The cover is opened by unclipping it at the recessed corner.

Insert Nano-SIM card as shown with PIN request disabled' or read our Wiki how to enter it

later in Teltonika Configurator. Make sure that the Nano-SIM card is fitted properly into the

holder.

Connect the battery as shown in the figure.

After configuration, see "PC Connection (Windows)", attach device cover back.

The device is ready to be mounted.

Nano-SIM card insertion/removal must be performed when device is powered off –

external voltage and battery are disconnected. Otherwise Nano-SIM card might be

damaged or device will not detect it.

FMB003

> FMB003 First Start

Table of Contents

Do you have a question about the FMB003 and is the answer not in the manual?

Page 1 Open the top cover of the device. The cover is opened by unclipping it at the recessed corner. Insert Nano-SIM card as shown with PIN request disabled' or read our Wiki how to enter it later in Teltonika Configurator. Make sure that the Nano-SIM card is fitted properly into the holder.
Page 2 Setup will continue installing the driver and eventually the confirmation window will appear. Click Finish to complete the setup. Configuration (Windows) At first FMB003 device will have default factory settings set. These settings should be changed according to the user's needs. Main configuration can be performed via Teltonika Configurator software.
Page 3 Maintenance and etc. FMB003 has one user editable profile, which can be loaded and saved to the device. After any modification of configuration the changes need to be saved to device using Save to device button. Main buttons offer following functionality: Load from device –...
Page 4 If device has made a record it is sent to the server every 120 seconds After successful SMS configuration, FMB003 device will synchronize time and update records to configured server. Time intervals and default I/O elements can be changed by using Teltonika Configurator parameters.
Page 5 Teltonika is not responsible for any harm caused by wrong cables used for connection between PC and FMB003. WARNING! Do not use FMB003 device if it distracts driver or causes inconvenience due to OBD II placement. Device must not interfere with driver.
