https://wiki.teltonika-gps.com/view/FMB150_First_Start
FMB150 First Start
Main Page
>
CAN Trackers & Adapters
GNSS/GSM/Bluetooth tracker with integrated CAN chip, internal GNSS/GSM antennas and
internal battery
Contents
1 How to insert Micro-SIM card
2 Battery placement after complete device disassembling
How to insert Micro-SIM card
1.
Gently remove FMB150 cover using plastic pry tool from both sides.
2.
Insert Micro-SIM card as shown with PIN request disabled or read
enter it later in Configurator. Make sure that Micro-SIM card cut-off corner is pointing
forward to slot.
Attach device cover back.
3.
4.
Device is ready to be connected.
Micro-SIM card insertion/removal must be performed when device is powered off -
external voltage and internal battery disconnected. Otherwise Micro-SIM card might be
damaged or device will not detect it.
Battery placement after complete device disassembling
>
FMB150
> FMB150 First Start
Security info
how to
Advertisement
Table of Contents
Related Manuals for Teltonika FMB150
Summary of Contents for Teltonika FMB150
-
Page 1: Table Of Contents
5 Mounting recommendations 6 Safety information 6.1 Precautions How to insert Micro-SIM card Gently remove FMB150 cover using plastic pry tool from both sides. Insert Micro-SIM card as shown with PIN request disabled or read Security info how to enter it later in Configurator. Make sure that Micro-SIM card cut-off corner is pointing forward to slot. -
Page 2: 2X6 Socket Pinout
CAN2H CAN2 High CAN1H CAN1 High PC Connection (Windows) Power-up FMB150 with DC voltage 10-30 V power supply using supplied power cable. “FMB150 LED status”. LED’s should start blinking, see Connect device to computer using Micro-USB cable or Bluetooth connection: Using Micro-USB cable "How to install USB drivers... -
Page 3: How To Install Usb Drivers (Windows)
Configuration process begins by pressing on connected device: After connection to Configurator Status window will be displayed: Status window tabs display information about GNSS, GSM, I/O, Maintenance Various and etc. FMB150 has one user editable profile, which can be loaded and saved to the device. After any... -
Page 4: Quick Sms Configuration
Data Acquisition – where data acquiring parameters can be configured. More details about FMB150 configuration using Configurator can be found here. Quick SMS configuration Default configuration has optimal parameters present to ensure best performance of track quality and data usage. -
Page 5: Fmb150 Configuration Upload
FMB150 CAN configuration can be uploaded Over The Air by using FOTA WEB. In order to download your vehicles CAN configuration please follow a quick and simple step- by-step guide below. FMB150 device, must be registered in FOTA WEB – device‘s model, firmware version, serial number, and other information must be shown. - Page 6 FMB150 CAN Chip firmware can be updated Over The Air by using FOTA WEB. In order to update FMB150 CAN Chip firmware please follow a quick and simple step-by-step guide below. FMB150 device, must be registered in FOTA WEB – device‘s model, firmware...
-
Page 7: Mounting Recommendations
Please note, that the CAN Chip firmware update will start after the next scheduled connection to FOTA WEB (or instant connection, initiated by an SMS command "web_connect") Mounting recommendations Connecting wires Wires should be connected while the module is not plugged in. Wires should be fastened to stable wires or other non-moving parts. -
Page 8: Safety Information
GND vehicle computer. Connecting the GND at an arbitrary point to the mass of the car is unacceptable, as static and dynamic potentials on the line GND will be unpredictable, which can lead to unstable FMB150 operation and even its failure. - Page 9 The device must be firmly fastened in a predefined location. The programming must be performed using a PC with autonomic power supply. The device is susceptible to water and humidity. Installation and/or handling during a lightning storm is prohibited. https://teltonika-gps.com/product/fmb150/...
