- Page 1 CONFIGURATION MANUAL Rev. A 0418 (Configuration Tool) AURES TECHNOLOGIES The manual and product are protected by copyright. MOBILE PRINTER MODEL : SMP 58, SLP 580...
-
Page 2: Table Of Contents
Table of Contents 1. Instruction 2. Emulation Setting 3. Code Page Setting (ESC/POS Only) 4. Density Setting (ESC/POS Only) 5. Power Save Mode Setting 6. Label Media Setting(CPCL, ZPL, EPL Only) 7. Bluetooth Setting 7-1. Numeric Comparison Setting 8. NFC Setting 9. -
Page 3: Instruction
To configure the printer with Configuration Tool Utility. 1. Make sure that you have a PC running Windows XP or later. 2. Download Configuration Tool utility from the AURES Technical website (www.aures-support.com) 3. Connect your printer to your PC using USB cable (Recommended). -
Page 4: Emulation Setting
3. Click Emulation you want to use and wait for the beep and power off to finish. 4. Turn on the printer to use. Use the following table to Printer’s Emulation setting. Model Compatible Emulation SLP 580 ESC/POS, CPCL, ZPL SMP 58 ESC/POS, CPCL, ZPL For more information, Please contact your supplier. -
Page 5: Code Page Setting(Esc/Pos Only)
3. Code Page Setting(ESC/POS Only) To configure Code Page settings with Configuration Tool Utility. (Code page can be set by command in CPCL, ZPL) 1. Update or check the Code Page in the Code Page Setting. 2. Click Save Code Page to finish. 3. -
Page 6: Density Setting(Esc/Pos Only)
4. Density Setting(ESC/POS Only) To configure Density setting with Configuration Tool Utility. 1. Update or check the Density in the Density Settings. 2. Click Save Density to finish. -
Page 7: Power Save Mode Setting
5. Power Save Mode Setting To configure Power Save Mode setting with Configuration Tool Utility. 1. Update or check the Power Save Mode in the Power Save Mode. 2. Click Save Power Save Mode to finish. Use the following table to Printer’s Emulation setting Mode Description None Power Save... -
Page 8: Label Media Setting(Cpcl, Zpl, Epl Only)
6. Label Media Setting(CPCL, ZPL, EPL Only) To configure Label Media Type setting with Configuration Tool Utility. 1. Update or check the Label Media Settings in the Label Media Setting. 2. Select Sensor position and Click Media type (Gap or Black Mark or Continuous) to finish. Use the following table to Label Media setting. -
Page 9: Bluetooth Setting
7. Bluetooth Setting To configure Bluetooth setting with Configuration Tool Utility. (Bluetooth is Optional Interface. For more information, Please contact your supplier) 1. Click Get Bluetooth Information. 2. Update or check your settings 3. Click button you need to set to finish. - Page 10 7. Bluetooth Setting Use the following table to Bluetooth setting Name Description BT Address The MAC address for Bluetooth Module. Bluetooth device The Name of Bluetooth Printer to pair. name (Bluetooth ID) PIN Code Pin code to pair (Default : 0000 or 1234) iOS auto connection Allowing iOS devices to automatically reconnect the printer.
-
Page 11: Numeric Comparison Setting
7-1. Numeric Comparison Setting NOTE Printers with only BT 4.2 support this function. 1. Click the ‘Enable’ tab on the Numeric Comparison Settings. 2. Reboot a printer. 3. Click the Bluetooth device name on the PC or mobile Bluetooth setting screen. 4. -
Page 12: Nfc Setting
8. NFC Setting 1. Turn on the NFC function on your mobile devices. (Choose either NFC P2P mode or standard mode / Connection is not available with NFC card mode.) NOTE A display type can be slightly different depending on device models. 2. -
Page 13: Wi-Fi Setting
9. Wi-Fi Setting To configure Wireless LAN settings with Configuration Tool Utility. (Wi-Fi is Optional Interface. For more information, Please contact your supplier.) 1. Click Start Wi-Fi Settings. 2. Select the connection in the Port Information. 3. Click Open port. 4. - Page 14 9. Wi-Fi Setting Use the following table to Wireless LAN setting. Number Name Description SSID The Network name to connect. Wi-Fi Mode Set the mode of the device to adhoc, infrastructure or SoftAP. Wi-Fi Channel Set the channel to use. Wi-Fi Encryption Set the type of Encryption to none, WEP-64, WEP-128 or WPA.
- Page 15 9. Wi-Fi Setting 7. To Set Wi-Fi printer correctly, you need to check the AP’s or Router’s setting in advance. Ex) D-Link Router (Model: DIR-820L)
-
Page 16: True Type Font Downloading & Printing
10. True Type Font Downloading & Printing True Type Font Download 1. Execute Configuration Tool.exe file. 2. After changing Port to ‘USB’, press Open Port. - When True-Type Font Download appears, press Open File. - Page 17 10. True Type Font Downloading & Printing True Type Font Download 3. Choose a font and click ‘Select to download’. -Font ID: If you want more than 1 font type, please save a font and increase Font ID each time. Change the Font ID if you save more than one 4.
- Page 18 10. True Type Font Downloading & Printing 5. If you would like to save a converted font(.tfd), please enter a file name and click Save button. - Purpose: To use the same font on different devices - If you do not want to save, press Cancel button. 6.
- Page 19 10. True Type Font Downloading & Printing True Type Font Printing 1. ZPL Printing Format Example: Font Name Printing Data ^FT10,10^A@N,24,24,entsani^FDABCDabcd1234?^FS ^FT10,50^A@N,24,48,entsani^FDABCDabcd1234?^FS ^FT10,120^A@N,48,24,entsani^FDABCDabcd1234?^FS ^PQ1 2. CPCL Printing Format Example Font Name Printing Data ! 0 200 200 400 1 SCALE-TEXT entsani.tfd 24 24 0 6 ABCDabcd1234? SCALE-TEXT entsani.tfd 48 24 0 31 ABCDabcd1234? SCALE-TEXT entsani.tfd 24 48 0 64 ABCDabcd1234? PRINT...
- Page 20 W W W . A U R E S . C O M...
