www.aures.com
MOBILE PRINTER
MODEL : SLP 580
Wi-Fi & Bluetooth
All specifications are subject to change without notice
SLP 580 Rev. A 08/18

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SLP 580 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for AURES SLP 580

Summary of Contents for AURES SLP 580

  • Page 1 MOBILE PRINTER MODEL : SLP 580 Wi-Fi & Bluetooth All specifications are subject to change without notice SLP 580 Rev. A 08/18...
  • Page 2 Operation is subject to the following two conditions. 1) This device may not cause harmful interference, and 2) This device must accept any interference received, including interference that may cause undesired operation. Aures USA Jeff Burroughs 15042 Parkway Loop, Building D, Tustin, CA 92780 | USA +714.669.3111...

  • Page 3: Table Of Contents

    Table of Contents 1. Safety Precautions 7. Roll Media Specification 2. Unpacking 8. Label Specification 3. Product Overview 9. Printer Specification 4. Setting Up the Product 4-1. Display 4-2. Installing the Battery 4-3. Removing the Battery 4-4. Charging the Battery 4-5.

  • Page 4: Safety Precautions

    1. Safety Precautions For better safety and reliability, adhere to the following precautionary measures. WARNING Read and follow the instructions carefully before operation of the product. Failure to follow these instructions could result in fire, electric shock, other injuries, or property damage. Indication Prohibition Must follow...

  • Page 5: Unpacking

    2. Unpacking 3. Product Overview Standard Front PEELER WING PEELER BODY Battery Printer Belt Clip COVER OPEN DISPLAY BUTTON SERIAL Charger Serial Cable USB Cable Bottom BATTERY BELT CLIP CONNECTOR Paper Quick Manual SHOULDER STRAP RING CHARGER CONNECTOR...

  • Page 6: Setting Up The Product

    4. Setting Up the Product 4-2. Installing the Battery 4-1. Display Button Name function Advances the paper, clears error messages, and moves down through menu options. Paper Feed/ 1. Refer to “4-10” for Diagnostic Test information. Insert the battery as shown. Down button 2.

  • Page 7: Removing The Battery

    4-3. Removing the Battery 4-4. Charging the Battery ② ① 1. Be sure the printer is turned off. Remove the battery as shown. 2. After opening the DC JACK cover, insert DC JACK into the printer. 3. Plug the power cord into the electrical outlet. The charge indicator LED Status charging...

  • Page 8: Paper Roll Installation

    4-5. Belt clip Usage 4-6. Paper Roll Installation Insert the paper roll so it unrolls from Open the Paper cover by pressing the Insert screw into belt clip. the bottom. Remove the paper core Open button. You can set the width of when the roll is empty.

  • Page 9: Peel Mode

    4-7. Peel Mode When users operates the peeler like the image below that has Peel Mode slits on the label(1) and the perforated label(2) , there might be an error in the peeler function Paper (1) Label Paper Engraved Line Press the feed button for 2~3 seconds Slide the peel body towards the back of until a buzzer sounds.

  • Page 10: Diagnostic Test

    4-8. Diagnostic Test Self-Test Printout Sample Upon initial installation or for troubleshooting, you can run the diagnostic test to get information about: Firmware version, emulation, codepage, sensor settings, interface settings, etc. If no issues are found with diagnostic test, examine other devices and software. The diagnostic test is working independent of devices and software.

  • Page 11: Peripheral Connection

    5. Peripheral Connection 5-3. Interface Cable Connection This product can communicate with other devices via Bluetooth, Wi-Fi, or a communication cable. 5-1. Bluetooth Connection Optional Serial 1. The Printer can be connected to devices equipped with Bluetooth communication capabilities (PDAs, PCs, etc.). 2.

  • Page 12: Cleaning The Printer

    6. Cleaning the Printer If the interior of the printer is dusty, printing quality can be lowered. 6-2. Platen Roller Cleaning In this case, follow the instructions below to clean the printer. 1.Clean the platen roller with a clean soft cloth moistened with isopropyl 6-1.

  • Page 13: Roll Media Specification

    8. Label Specification 7. Roll Media Specification <-- a --> Media width (inch, liner) Maximum 54±0.5 mm Minimum 8.7±0.5 mm <-- b --> Label length Minimum 12.7~300 mm <-- c --> Label gap height Maximum 8.3 mm Minimum 1.8 mm Liner Core Opacity...

  • Page 14: Printer Specification

    9. Printer Specification Sensor Paper end, Gap, Black mark, Cover open, Printing Medhod Direct Thermal Peeler detect, Peeler S/W Speed 127mm/sec Drop Resistance 1.5M onto concrete Width 48mm, 384 Dots/line FSTN LCD 128 x 64 dots Resolution 203 DPI Paper Paper type Thermal Paper Dot Pitch...
