NOKTON 50mm F1.2
X-mount
INSTRUCTION MANUAL
COSINA CO., LTD.
Sep 2023, Ver 1.0

Advertisement

loading
Need help?

Need help?

Do you have a question about the X-mount Series and is the answer not in the manual?

Questions and answers

Summary of Contents for VOIGTLANDER X-mount Series

  • Page 1 NOKTON 50mm F1.2 X-mount INSTRUCTION MANUAL COSINA CO., LTD. Sep 2023, Ver 1.0...
  • Page 2 Thank you for purchasing a Voigtlander product. The Voigtlander X-mount series is an interchangeable lens, designed exclusively for X-mount which covers the APS-C frame size. The optical system is optimized to meet the specifications of the Fuji-X digital image sensor camera.
  • Page 3 Tips for lens care and safety These tips are to protect the user from injury or damaging the lens. If the user ignores this warning and uses the equipment incorrectly, serious injuries and even death may be the result. WARNING If the user ignores this caution sign it might result in injuries and damage the equipment.
  • Page 4: Precautions For Use

    Never touch the lens surface. In case it is dirty or dusty use commercially available lens cleaners or an appropriate lens cleaning cloth. Please check here for electronic communication compatible camera information. www.cosina.co.jp/voigtlander/en/...
  • Page 5 Description of Parts ① Lens Hood ② Filter Ring ① ③ Aperture Ring ⑨ ④ Focus Ring ② ⑤ Distance Scale ⑩ ③ ⑥ Depth of Field Scale ⑦ Mount Index ④ ⑧ Mount ⑨ Aperture Index ⑤ ⑩ Aperture Scale ⑥...
  • Page 6 ● How to attach/detach the lens Please refer to the instruction manual for your camera for how to attach/detach the lens. * Please make sure to set the power of the camera to “OFF”. Please hold the Depth of Field Scale ⑪ to attach/detach the lens. If you attach/ detach the lens while holding other parts of the lens barrel it may damage the lens.
  • Page 7 Preparation (camera body settings) By setting the camera body as below, you can shoot using the functions of the lens and body. For details on the camera body settings, refer to the instruction manual of the camera you are using. 1.
  • Page 8 2. Models that do not support electronic communications When using with a model that does not support electronic communications, set [Release without lens] to "ON" in the camera settings.
  • Page 9: Focus Check

    How CPU/Contact works 1. Exif Data Image file can store the Exif data of lens. (For example, if you use Voigtländer 50mm F1.2) Lens VOIGTLANDER NOKTON 50mm F1.2 Focal length 50mm Maximum Aperture F1.2 Aperture The aperture value used to take the picture 2. Focus check...
  • Page 10: Image Stabilization

    4. Image stabilization This lens supports the "camera shake" correction function. *The "camera shake" correction function can be switched "ON / OFF" by the appropriate setting on the camera body. For more details, please refer to the instruction manual of your camera.
  • Page 11 ● Specifications Product Name NOKTON 50mm F1.2 Focal Length 50mm Maximum Aperture F1.2 Minimum Aperture Lens Construction 8 groups 9 elements Angle of View 32.5° Aperture Blades Minimum Focus 0.39m Macro Ratio 1:6.0 Filter Size Ø58mm Maximum Diameter Approx. Ø63.9mm Length Approx.
  • Page 12 ● Specifications In-body camera shake correction possible function * only on camera bodies with Image Stabilization Supplied Accessories Front Cap, Rear Cap, Lens Hood, Corresponding shooting mode A [Aperture priority] M [Manual] * Specifications and information is subject to change without notice.
