3.2 Control Panel
AC POWER
Breaker
Projector Sync
input and GPIO
Automation
RS-232C
Automation
TTL Sync input
Ethernet
Automation
3D Port (Sync
and Automation)
MI-2100R Installation & Operations Manual
9
indicator
EMERGENCY Stop
Button
RUN/STOP Switch
PFD Position
Control Switch
Status LED
S/W version info
Current Time
Status
LCD Menu Control
Emulation/Monitoring
Log Message
Download, Program
upgrade
