RB39P
USER'S MANUAL

Advertisement

loading

Related Manuals for Retevis RB39P

Summary of Contents for Retevis RB39P

  • Page 1 RB39P USER’S MANUAL...

  • Page 2: Table Of Contents

    Optional Functions ------------------------------------------------------------------02 Specifications ------------------------------------------------------------------------05 Default Setting -----------------------------------------------------------------------05 WARNING ----------------------------------------------------------------------------06 For downloading further resources: Brochures, Software/Firmware, Manual etc, Pls contact your direct reseller first OR go to website retevis.com and check “support” in the each product link to download it.

  • Page 3: Warranty

    Warranty Before using the radio, please read the manual carefully. ·Don’t charge the radio in inflammable, explosive and radio-communication-banned areas (such as gas station, petrol station and airport, etc). ·Don’t operate the radio without license in the areas that government bans. ·Ensure the radio to avoid being placed under the sun and near any heat equipment.

  • Page 4: Led Indicators

    LED Indicator LED indicator Radio Working Status Green indicator flashes slowly Standby state (ON: 20ms/OFF: 5sec) Green indicator flashes slowly Scan state (ON: 200ms / OFF: 200ms) Transmitting Red indicator is on Receiving Green indicator is on Read data from the radio through operating the programming Red indicator flashes quickly software Write data to the radio through operating the programming...
  • Page 5 6. High/Low Power Setting The user can set the power level of each channel to high or low. High power achieves the communication with the radios over long distance and low power achieves the communication with radios in the short distance. 6.1 Power level of the channel can be set as high or low through CPS.
  • Page 6 12. Channel Lock 12.1 Press + and - key simultaneously and the speaker makes two beeps. The channel lock is turned on and the channel is not adjusted. 12.2 Press + and - key simultaneously and the speaker makes a beep. The channel lock is turned off and the channel is adjusted.

  • Page 7: Specifications

    Current Standby 70mA, working 220mA Reference Frequency 26.000MHz Inter-modulation ≥60dB Conducted Emissions ≤-20dBm Audio response -17～+11.5dB Audio distortion <5% Audio power 500mW Default Setting (FCC-RB39P) CH NO. Frequency（MHz） Code(Hz) Power 462.5625 67.0 High 462.5875 118.8 High 462.6125 127.3 High 462.6375 131.8...
  • Page 8 RF energy, which when used improperly, can cause biological damage. All Retevis two-way radios are designed, manufactured, and tested to ensure they meet government-established RF exposure levels. In addition, manufacturers also recommend specific operating instructions to users of two-way radios.
  • Page 9 CE Requirements: •(Simple EU declaration of conformity) Shenzhen Retevis Technology Co., Ltd. declares that the radio equipment type is in compliance with the essential requirements and other relevant provisions of RED Directive 2014/53/EU and the ROHS Directive 2011/65/EU and the WEEE Directive 2012/19/EU; the full text of the EU declaration of conformity is available at the following internet address: www.retevis.com.
  • Page 10 RF Exposure Compliance and Control Guidelines and Operating Instructions Transmit no more than the rated duty factor of 50% of the time. To Transmit (Talk), push the Push to Talk (PTT) button. To receive calls (listen), release the PTT button. Transmitting necessary information or less, is important because the radio generates measurable RF energy exposure only when transmitting in terms of measuring for standards compliance.

  • Page 11: Warning

    •The adapter shall be installed near the equipment and shall be easily accessible Approved Accessories •This radio meets the RF exposure guidelines when used with the Retevis accessories supplied or designated for the product. Use of other accessories may not ensure compliance with the RF exposure guidelines and may violate regulations.
  • Page 12 1.This guarantee card should be kept by the user, no replacement if lost. 2.Most new products carry a two-year manufacturer’s warranty from the date of purchase. Further details, pls read http://www.retevis.com/after-sale/ 3.The user can get warranty and after-sales service as below: ・Contact the seller where you buy.
  • Page 13 Web:www.retevis.com E-mail:kam@retevis.com Facebook:facebook.com/retevis MADE IN CHINA...
