- Page 1 Z5330.001 Manual 1.4 en...
- Page 2 General information Z5330.001 Manual Version: 1.4 en, 07/2016, D2021.EN .01 Copyright © 2016 by d&b audiotechnik GmbH & Co. KG; all rights reserved. Keep this document with the product or in a safe place so that it is available for future reference.
-
Page 3: Table Of Contents
Contents Z5330.001 D80 Touring rack assembly CEE..... 4 1.1 Intended use................4 1.2 Scope of supply................4 Handling, cooling and placement......... 5 2.1 Handling..................5 2.2 Cooling and placement.............. 5 X5335 Mains power distributor - 32 A CEE....6 3.1 Intended use................6 3.2 Rear panel................... -
Page 4: Z5330.001 D80 Touring Rack Assembly Cee
Z5330.001 D80 Touring rack assembly CEE 1.1 Intended use The Z5330.001 D80 Touring rack assembly is designed as a closed system rack providing mains power distribution and connector interfaces for 3 x D80 amplifiers. For this purpose, the touring rack is equipped with a mains power distribution device (X5335), which also serves as a loudspeaker connector panel. -
Page 5: Handling, Cooling And Placement
▪ Do not stack D80 and D12 Touring racks or any other rack assemblies with opposing airflow. ▪ D80/D12 Touring rack assemblies can be positioned side by side. d&b Z5330.001 Manual 1.4 en... -
Page 6: X5335 Mains Power Distributor - 32 A Cee
▪ Do not connect or disconnect the CEE mains connector under load or live. Required mains supply network configuration 3-phase 230/400V - 50/60 Hz - 32 A max. d&b Z5330.001 Manual 1.4 en... -
Page 7: Mains Link - 32 A Cee
Ethernet switches. Each socket can be switched on and off by its dedicated switch. These switches also serve as circuit-breakers for the corresponding socket. Please refer to the switch assignment as shown in the graphic opposite. d&b Z5330.001 Manual 1.4 en... -
Page 8: Outputs - Nl8
Z5320.xxx cabling system to allow efficient system wiring using loudspeaker multicore cables. Each connector carries the output signal of six amplifier channels. Please refer to the corresponding channel assignment label above each connector as shown in the graphic opposite. d&b Z5330.001 Manual 1.4 en... -
Page 9: Nl8 F / Lks 19 F - Pin Assignments
CH A: 1+ CH A/B/C/D CH A: 1— CH B: 2 + CH B: 2 — AMP 3 CH A/B/C/D CH C: 3 + CH C: 3 — CH D: 4 + CH D: 4 — d&b Z5330.001 Manual 1.4 en... -
Page 10: Z5338 I/O Panel
A detailed description of remote control via Ethernet is given in the technical information TI 310 (d&b code D5310.EN) which can be downloaded from the d&b website at www.dbaudio.com. d&b Z5330.001 Manual 1.4 en... - Page 11 TERMINATE Note: A detailed description of remote control via the d&b Remote network (CAN-Bus) is given in the technical information TI 312 (d&b code D5312.EN) which can be downloaded from the d&b website at www.dbaudio.com. d&b Z5330.001 Manual 1.4 en...
-
Page 12: Z5333 Rack Link
Audio signal capability Analog Digital AES3 Network connector etherCON Network cable CAT 5E STP Length 2 m / 6.5 ft Rack link example: 4ch Digital audio and CAN-Bus Rack link example: 2ch Analog audio and CAN-Bus d&b Z5330.001 Manual 1.4 en... -
Page 13: Manufacturer's Declarations
Please dispose of this product according to the respective national regulations or contractual agreements. If there are any further questions concerning the disposal of this product, please contact d&b audiotechnik. WEEE-Reg.-Nr. DE: 13421928 d&b Z5330.001 Manual 1.4 en... - Page 14 www.dbaudio.com...
