1. Z5560 D20 Touring rack assembly CEE 1.1. Intended use The Z5560 D20 Touring rack assembly is designed as a closed system rack providing mains power distribution and connector interfaces for 3 x D20 amplifiers. For this purpose, the touring rack is equipped with a mains power distribution device (X5565), which also serves as a loudspeaker connector panel. -
Page 5: Handling, Cooling And Placement
3. push the door to the rear into its park position. 2.2. Cooling and placement When using the d&b Z5560 D20 Touring rack assembly, make sure to provide sufficient space of 0.5 m (1.6 ft) at the front and rear of the touring rack to ensure sufficient cooling airflow. -
Page 6: X5565 Mains Power Distributor - 32 A Cee
– Do not connect or disconnect the CEE mains connector under load or live. Required mains supply network configuration 3-phase 230/400V - 50/60 Hz - 32 A max. d&b Z5560 Manual 1.1 en... -
Page 7: Mains Link - 32 A Cee
They are intended for the connection of low current devices such as notebooks or additional Ethernet switches. Each socket is equipped with a dedicated circuit-breaker. Please refer to the assignment as shown in the graphic opposite. d&b Z5560 Manual 1.1 en... -
Page 8: Amplifier Mains Supplies 16A
CHANNEL OUTPUT of the respective D20 amplifier. Each connector carries the output signals of all four channels of the amplifier with the following pin assignment. Please refer to the corresponding channel assignment label above each connector as shown in the graphic opposite. d&b Z5560 Manual 1.1 en... -
Page 9: Z5338 I/O Panel
A detailed description of remote control via Ethernet is given in the technical information TI 310 (d&b code D5310.EN) which can be downloaded from the d&b website at www.dbaudio.com. d&b Z5560 Manual 1.1 en... - Page 10 TERMINATE Note: A detailed description of remote control via the d&b Remote network (CAN-Bus) is given in the technical information TI 312 (d&b code D5312.EN) which can be downloaded from the d&b website at www.dbaudio.com. d&b Z5560 Manual 1.1 en...
-
Page 11: Z5333 Rack Link
Audio signal capability Analog Digital AES3 Network connector etherCON Network cable CAT 5E STP Length 2 m / 6.5 ft Rack link example: 4ch Digital audio and CAN-Bus Rack link example: 2ch Analog audio and CAN-Bus d&b Z5560 Manual 1.1 en... - Page 12 www.dbaudio.com...
