Iecube for 78k0/fx1+, target device: 78k0/fc1+, 78k0/fe1+, 78k0/ff1+
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
CUSTOMER NOTIFICATION
U17534EJ1V0UM00
Apr 27th, 2005
Tadayoshi Mori, Manager
Automotive Systems Division
4th Systems Operations Unit
NEC Electronics Corporation
(Created by Takashi Fuchigami)
CP(K), O
QB-78K0FX1
(IECUBE for 78K0/Fx1+)
User's Manual
Target Device:
78K0/FC1+
78K0/FE1+
78K0/FF1+

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the QB-78K0FX1 and is the answer not in the manual?

Questions and answers

Related Manuals for Renesas QB-78K0FX1

Summary of Contents for Renesas QB-78K0FX1

  • Page 1 CUSTOMER NOTIFICATION U17534EJ1V0UM00 Apr 27th, 2005 Tadayoshi Mori, Manager Automotive Systems Division 4th Systems Operations Unit NEC Electronics Corporation (Created by Takashi Fuchigami) CP(K), O QB-78K0FX1 (IECUBE for 78K0/Fx1+) User’s Manual Target Device: 78K0/FC1+ 78K0/FE1+ 78K0/FF1+...
  • Page 2 [MEMO] User’s Manual U17534EJ1V0UM00...
  • Page 3 PC/AT is a trademark of International Business Machines Corporation. • The information in this document is current as of March, 2004. The information is subject to change without notice. For actual design-in, refer to the latest publications of NEC Electronics data sheets or data books, etc., for the most up-to-date specifications of NEC Electronics products.
  • Page 4 Regional Information Some information contained in this document may vary from country to country. Before using any NEC Electronics product in your application, pIease contact the NEC Electronics office in your country to obtain a list of authorized representatives and distributors. They will verify: •...
  • Page 5 INTRODUCTION This manual is intended for users who wish to perform debugging using Readers the QB-78K0FX1. The readers of this manual are assumed to be familiar with the device functions and usage, and to have knowledge of debuggers. This manual is intended to give users an understanding of the basic Purpose specifications and correct usage of the QB-78K0FX1.
  • Page 6 The related documents listed below may include preliminary versions. However, preliminary versions are not marked as such. Documents Related to Development Tools (User’s Manuals) Document Name Document Number QB-78K0FX1 In-Circuit Emulator This manual RA78K0 Assembler Package Ver. 3.70 Operation U17015E...
  • Page 7 General Precautions for Handling This Product 1. Circumstances not covered by product guarantee ・ If the product was disassembled, altered, or repaired by the customer ・ If it was dropped, broken, or given another strong shock ・ Use at overvoltage, use outside guaranteed temperature range, storing outside guaranteed temperature range ・...

  • Page 8: Table Of Contents

    Precautions for handling NQ, YQ, YS ....................30 2.5.5 Precautions on mounting NQ and IC....................31 Connection of QB-78K0FX1 to Target System................... 31 Power Supply and GND Pin Connection Precautions ................ 35 Connection of USB Interface Cable and AC Adapter ................. 35 Switching Power On and Off ......................
  • Page 9 Target Connectors..........................48 Exchange Adapters ..........................53 YQ Connectors........................... 55 Mount Adapters ..........................57 Check Pin Adapter ..........................59 Spacer Adapters ..........................60 Emulation Probe..........................62 Clock Board............................63 User’s Manual U17534EJ1V0UM00...

  • Page 10: Chapter 1 General

    CHAPTER 1 GENERAL The QB-78K0FX1 is an in-circuit emulator for emulating the 78K0/Fx1+. Hardware and software can be debugged efficiently in the development of systems in which the 78K0/Fx1+ is used. This manual descries basic setup procedures, hardware specifications, system specifications, and how to set switches.

  • Page 11: Hardware Specifications

    Hardware Specifications Table 1-1. QB-78K0FX1 Hardware Specifications Parameter Specification Target device 78K0/FC1+, 78K0/FE1+, 78K0/FF1+ Operating voltage 3.7 to 5.5 V Operating frequency Main system clock = 4.0 to 5.5 V: 16 MHz = 3.7 to 4.0 V: 12 MHz Subsystem clock 32.768 kHz...

  • Page 12: System Specifications

    System Specifications This section shows the QB-78K0FX1 system specifications.   Table 1-2. QB-78K0FX1 System Specifications Parameter Specification Emulation memory capacity 64 KB Program execution Real-time execution function Go, Start from Here, Go & Go, Come Here, Restart, Return Out, functions...

  • Page 13: System Configuration

    1.3  System Configuration This section shows the system configuration when using the QB-78K0FX1 connected to a PC (PC-9821 series, PC/AT compatible). Connection is possible even without optional products.   Table 1-3. Devices Subject to Emulation by 78K0Fx1  Series Name Package...
  • Page 14 PC-9821 series, PC/AT compatible can be used <2> ID78K0-QB Disk/Accessory Disk: Debugger, USB drivers, manual, etc. <3> USB interface cable: Cable connecting QB-78K0FX1 to host machine <4> AC adapter: Can support 100 to 240 V by replacing AC plug <5> QB-78K0FX1: This product <6>...
  • Page 15 Table 1-5. Check Pin Adapters Package Check Pin Adapter Common QB-144-CA-01 Table 1-6. Exchange Adapters Package Exchange Adapter 80GC QB-80GC-EA-01T 80GK QB-80GK-EA-01T 64GB QB-64GB-EA-03T 64GK QB-64GK-EA-03T 48GA QB-48GA-EA-01T 44GB QB-44GB-EA-02T Table 1-7. Emulation Probes Package Emulation Probe Common QB-80-EP-01T Table 1-8. YQ Connectors Package YQ Connector 80GC...

  • Page 16: Ac Adapter

    Table 1-10. Target Connectors Package Target Connector 80GC QB-80GC-NQ-01T 80GK QB-80GK-NQ-01T 64GB QB-64GB-NQ-01T 64GK QB-64GK-NQ-01T 48GA QB-48GA-NQ-01T 44GB QB-44GB-NQ-01T Table 1-11. Mount Adapters Package Target Connector 80GC QB-80GC-HQ-01T 80GK QB-80GK-HQ-01T 64GB QB-64GB-HQ-01T 64GK QB-64GK-HQ-01T 48GA QB-48GA-HQ-01T 44GB QB-44GB-HQ-01T     1.3.1 ...

  • Page 17: Package Contents

    1.4  Package Contents The following items have been placed in the QB-78K0FX1 packing box. Please check the contents. Products supplied with QB-78K0FX1-ZZZ QB-78K0FX1 AC adapter USB interface cable Clock board set • Main Clock Type I • Main Clock Type II •...
  • Page 18 Products supplied with QB-78K0FX1-T48GA 1 to 9 Emulation probe QB-80-EP-01T Exchange adapter QB-48GA-EA-01T YQ connector QB-48GA-YQ-01T Target connector QB-48GA-NQ-01T Products supplied with QB-78K0FX1-T44GB 1 to 9 Emulation probe QB-80-EP-01T Exchange adapter QB-44GB-EA-02T YQ connector QB-44GB-YQ-01T Target connector QB-44GB-NQ-01T The following products are sold as single items.

  • Page 19: Chapter 2 Setup Procedure

    Mounting and connecting connectors See 2.5 Mounting and Connecting Connectors. Connection of QB-78K0FX1 to target system See 2.6 Connection of QB-78K0FX1 to Target System. Connection of USB interface cable and AC adapter See 2.8 Connection of USB Interface Cable and AC adapter.

  • Page 20: Names And Functions Of Hardware

    Names and Functions of Hardware Figure 2-1. Names of Parts of QB-78K0FX1   Top View Bottom View   Power switch POWER TARGET TCN2 TCN1 Side View Power supply connector USB connector  User’s Manual U17534EJ1V0UM00...
  • Page 21 CN5 (Subclock board connector) is the connector for mounting the subclock board. Sub Clock Type II is mounted at shipment.   (4) POWER (Red LED) This is an LED that shows whether or not the power supply of the QB-78K0FX1 is switched on. LED State QB-78K0FX1 State Power switch ON...

  • Page 22: Removal Of Acrylic Board

    Removal of Acrylic Board To modify the clock setup, the acrylic board on the bottom of the QB-78K0FX1 must be removed. The acrylic board can be removed by lifting it up. Figure 2-3. Acrylic Board Removal Method      ...

  • Page 23: Clock Setting Methods

    2.3.2 Clock setting methods This section shows the hardware settings when setting the clock.   Table 2-1. Hardware Settings When Setting Main System Clock Type of Clock to Use Remarks Mount clock board in CN4 and use Mount Main Clock Type III in CN4. Mounted in CN4 at internally generated clock shipment...
  • Page 24 <Procedure> <1> Prepare the QB-78K0FX1 and Main Clock Type I. Remove the clock board that is mounted in the CN4 socket on the QB-78K0FX1. When removing the clock board, do so carefully, since the pins of the CN4 socket bend easily.
  • Page 25 <Procedure> <1> Prepare the QB-78K0FX1 and Main Clock Type II. Remove the clock board that is mounted in the CN4 socket on the QB-78K0FX1. When removing the clock board, do so carefully, since the pins of the CN4 socket bend easily.
  • Page 26 Figure 2-8. Resonator (Main System Clock: 2-Pin) <Procedure> <1> Prepare the QB-78K0FX1 and Main Clock Type II. Remove the clock board that is mounted in the CN4 socket on the QB-78K0FX1. When removing the clock board, do so carefully, since the pins of the CN4 socket bend easily.

  • Page 27: Subsystem Clock

    Note  The resonator used is assumed to be NC-206 (by Kyushu Dentsu Co., Ltd.). <Procedure> <1> Prepare the QB-78K0FX1 and Sub Clock Type I. Remove the clock board that is mounted in the CN5 socket on the QB-78K0FX1. When removing the clock board, do so carefully, since the pins of the CN5 socket bend easily.

  • Page 28: Software Settings

    Figure 2-10. Connection to Subclock Type I (Subsystem Clock) Sub Clock Type I Pin Number Connection C1, C1’ Capacitor C1 C2, C2’ Capacitor C2 OSC1, OSC1’ Ceramic resonator or crystal resonator For through-hole type For pad type Circuit Diagram 470 kΩ C1(C1') NC-206 SN74LVC2G04DCK...

  • Page 29: Mounting And Connecting Connectors

    Mounting and Connecting Connectors This section describes the methods of connecting the QB-78K0FX1 and target system. Make connections with both the QB-78K0FX1 and target system powered OFF. The following abbreviations are used in this section. • NQ: Target connector • YQ: YQ connector •...

  • Page 30: Plugging Ea Into Yq

    2.5.3  Plugging EA into YQ Match the No. 1 pin position of the YQ or YS (C cuts match in both) to the No. 1 pin position of the EA and plug in. • When plugging or unplugging, press on the NQ, YQ, and YS with a finger so that there is no force on the NQ. •...

  • Page 31: Precautions On Mounting Nq And Ic

    (8) After soldering the NQ, do not perform washing by flux immersion or vapor. Connection of QB-78K0FX1 to Target System If connecting the emulation probe (QB-80-EP-01T), connect it to the QB-78K0FX1 and the target system by the following procedure. (a) Connection of emulation probe Connect the emulation probe to the QB-78K0FX1.
  • Page 32 There are 2 GND wires in the emulation probe. Connect them to the QB-78K0FX1 and target system. <1> Fasten the GND wire on the QB-78K0FX1 side of the emulation probe to the nut on the bottom of the QB-78K0FX1 using a #0 or #1 (+) precision driver (connection of B to A in Figure 2-12).
  • Page 33 <5> Since the length of the GND wire below the head (insulated part) is approximately 60 mm, there must be a GND to which it can be connected in the range of an approximately 60 mm radius of the section of the target system for connecting the emulation probe, as shown in Figure 2-13.
  • Page 34 <2> Be sure to connect the GND wire of the emulation probe to the QB-78K0FX1 and the target system. If it cannot be connected, the impedance of the cable is unstable and could bring about lowering of signal transmission characteristics or distortion of the output waveform for an input waveform.

  • Page 35: Power Supply And Gnd Pin Connection Precautions

    Plug the USB interface cable supplied with the QB-78K0FX1 into the USB connector of the host machine and also plug it into the USB connector on the rear of the QB-78K0FX1. Plug the AC adapter supplied with the QB-78K0FX1 into a receptacle and plug it into the power supply connector on the rear of the QB-78K0FX1.

  • Page 36: Chapter 3 Settings At Product Shipment

    CHAPTER 3 SETTINGS AT PRODUCT SHIPMENT Table 3-1. Settings at Shipment Item Setting Remarks Main Clock Type III is mounted Sub Clock Type II is mounted Power switch Set to OFF at shipment.   User’s Manual U17534EJ1V0UM00...

  • Page 37: Chapter 4 Differences Between Target Interface Circuit And Target

    CHAPTER 4 DIFFERENCES BETWEEN TARGET INTERFACE CIRCUIT AND TARGET DEVICE This chapter explains the differences between the signal lines of a target interface circuit of the QB-78K0FX1 and the signal lines of a target device Although the target device is a CMOS circuit, the target interface circuit of the QB-78K0FX1 consists of an emulation circuit that depends on the emulation CPU, TTL, CMOS-IC, or other.

  • Page 38: For 78K0Fc1+ Emulation

    For 78K0FC1+ Emulation For the signals in (1) to (3) below, see Figure 4-1 Emulation Circuit Equivalent Circuit 1. µ (1) Signals input and output by emulation CPU ( PD78F0876) ・P01-P00 ・P17-P10 ・P33-P30 ・P73-P70 ・P87-P80 ・P120 ・P130 , EV ・AV (2) Signals input and output by emulation CPU (FPGA) ・P41-P40 ・P62-P60...
  • Page 39 Figure 4-1. Emulation Circuit Equivalent Circuit 1 (2/2) ●QB-78K0FX1side FPGA   Emulation CPU μPD7885 Pull-up control IC 30 kΩ Level shifter    P41-P40   μPD7885   P62-P60 RD13SB    74LS26DNV       10 kΩ Input Signal    μPC393G2 10 kΩ   X2, XT2,NC OPEN  ...

  • Page 40: For 78K0/Fe1+ Emulation

    For 78K0/FE1+ Emulation For the signals in (1) to (3) below, see Figure 4-2 Emulation Circuit Equivalent Circuit 2. µ (1) Signals input and output by emulation CPU ( PD78F0876) ・P01-P00 ・P06-P05 ・P17-P10 ・P33-P30 ・P76-P70 ・P87-P80 ・P93-P90 ・P120 ・P130-P132 , EV ・AV (2) Signals input and output by emulation CPU (FPGA) ・P43-P40...
  • Page 41 Figure 4-2. Emulation Circuit Equivalent Circuit 2 (2/2) ●QB-78K0FX1side FPGA   Emulation CPU μPD7885 Pull-up control IC 30 kΩ Level shifter  P43-P40     μPD7885 P53-P50   P63-P60 RD13SB    74LS26DNV       10 kΩ Input Signal    μPC393G2 10 kΩ  ...

  • Page 42: For 78K0/Ff1+ Emulation

    For 78K0/FF1+ Emulation For the signals in (1) to (3) below, see Figure 4-3 Emulation Circuit Equivalent Circuit 3. µ (1) Signals input and output by emulation CPU ( PD78F0876) ・P01-P00 ・P06-P05 ・P17-P10 ・P33-P30 ・P76-P70 ・P87-P80 ・P97-P90 ・P120 ・P130-P132 , EV ・AV (2) Signals input and output by emulation CPU (FPGA) ・P47-P40...
  • Page 43 Figure 4-3. Emulation Circuit Equivalent Circuit 3 (2/2) ●QB-78K0FX1side FPGA   Emulation CPU μPD7885 Pull-up control IC 30 kΩ P47-P40 Level shifter    P57-P50   μPD7885 P67-P64   P63-P60 RD13SB    74LS26DNV       10 kΩ Input Signal    μPC393G2 10 kΩ  ...

  • Page 44: Chapter 5 Cautions

      If the product is used without connecting the emulation probe and exchange adapter, a warning window is displayed but use is possible. CHAPTER 6 RESTRICTIONS About a restriction matter ,Please refer to QB-78K0FX1 Operating Precautions.  User’s Manual U17534EJ1V0UM00...

  • Page 45: Appendix Anotes On Target System Design

    APPENDIX A NOTES ON TARGET SYSTEM DESIGN  This section shows areas on the target system where component mounting is prohibited and areas where there are component mounting height restrictions. (1) For 78K0FC1+ (a)For 44-pin GB package Figure A-1. For 78K0/FC1+(44-Pin GB Package) 13.375 17.375 Note...
  • Page 46 (2) For 78K0/FE1+ (a)For 64-pin GB package Figure A-3. For 78K0/FE1+ (64-Pin GB Package) 13.375 17.375 Note : Exchange adapter area: Components up to 17.45 mm in height can be mounted Note : Emulation probe tip area: Components up to 24.45 mm in height can be mounted Height can be regulated by using spacer adapters (each adds 2.4 mm) Note (b)For 64-pin GK package...
  • Page 47 (5)  For 78K0/FF1+ (a) For 80-pin GK package Figure A-5. For 78K0/FF1+ (80-Pin GK Package) 13.375 17.375 Note : Exchange adapter area: Components up to 17.45 mm in height can be mounted Note : Emulation probe tip area: Components up to 24.45 mm in height can be mounted Height can be regulated by using spacer adapters (each adds 2.4 mm) Note For 80-pin GC package...

  • Page 48: Target Connectors

    APPENDIX B PACKAGE DRAWINGS B.1  Target Connectors Figure B-1. Target Connector for 78K0/FC1+ (QB-44GB-NQ-01T) (a) Package drawing 17.7 13.1 0.8x10=8.0 1.85 C1.5 3-ł1.5 (a slit width) φ 2- 1.0 044SA 0.23 φ 2- 1.5 (A projection height :1.8) 6.95 13.35 9.45 (b) Foot pattern 0.8x10=8...
  • Page 49 Figure B-2. Target Connector for 78K0/FC1+ (QB-48GA-NQ-01T) (a) Package drawing 9.45 0.5x11=5.5 1.85 C1.5 3-R1.5 0.25 048SD 2-φ0.8 2-φ1.3 6.95 (A projection height : 1.8mm) (b) Foot pattern 0.5x11=5.5 0.25 No.1 Pin 2-φ0.8 φ1.6 ( SL-type ) User’s Manual U17534EJ1V0UM00...
  • Page 50 Figure B-3. Target Connector for 78K0/FE1+ (QB-64GB-NQ-01T) (a) Package drawing 9.45 0.5x15=7.5 1.85 3-R1.5 C1.5 064SD φ 2- 1.0 φ 2- 1.5 (A projection height : 1.8mm) 6.95 (b) Foot pattern 0.5x15=7.5 0.25 φ No.1 pin (SL-type) φ 2- 1.0  ...
  • Page 51 Figure B-4. Target Connector for 78K0/FE1+ (QB-64GK-NQ-01T) (a) Package drawing 20.1 12.6 15.5 0.65x15=9.75 1.86 3-R1.5 0.65 C1.5 064SB φ 3- 1.0 0.23 φ 4- 2.0 (A projection height : 1.8mm) 6.95 (b) Foot pattern 0.65x15=9.75 0.65 No.1 pin φ (-SL type) φ...
  • Page 52 Figure B-5. Target Connector for and 78K0/FF1+ (QB-80GK-NQ-01T) (a) Package drawing 9.45 1.85 0.5x19=9.5 C1.5 3-R1.5 φ 3- 1.0 080SD φ 4- 2.0 (A projection height : 1.8mm) 6.95 (b) Foot pattern 0.5x19=9.5 0.25 No.1 Pin φ (SL-type) φ 3- 1.0 User’s Manual U17534EJ1V0UM00...
  • Page 53 Figure B-6. Target Connector for 78K0/FF1+ (QB-80GC-NQ-01T) (a) Package drawing 9.45 22.1 1.85 17.5 0.65x19=12.35 0.65 3-R1.5 C1.5 080SB φ 4- 2.0 (A projection height : 1.8mm) 3- 1.0 φ 0.23 6.95 (b) Foot pattern 0.65x19=12.35 0.35 0.65 No.1 Pin φ...

  • Page 54: Exchange Adapters

    B.2  Exchange Adapters Figure B-7. Exchange Adapter for 78K0/FC1+ (QB-44GB-EA-02T) Figure B-8. Exchange Adapter for 78K0/FC1+ (QB-48GA-EA-01T) Figure B-9. Exchange Adapter for 78K0/FE1+ (QB-64GB-EA-03T) Figure B-10. Exchange Adapter for 78K0/FE1+ (QB-64GK-EA-03T) User’s Manual U17534EJ1V0UM00...
  • Page 55 Figure B-11. Exchange Adapter for 78K0/FF1+ (QB-80GK-EA-01T) JAPAN MADE IN 80GK-01T Figure B-12. Exchange Adapter for 78K0/FF1+ (QB-80GC-EA-01T) 24.1 0.65 JAPAN MADE IN 80GK-01T User’s Manual U17534EJ1V0UM00...

  • Page 56: Yq Connectors

    B.3 YQ Connectors Figure B-13. YQ Connector for 78K0/FC1+ (QB-44GB-YQ-01T) 19.7 0.8x10=8.0 C1.5 3-R2.5 C2.0 0.25 044SA φ 2- 1.0 φ 4- 2.2 Figure B-14. YQ Connector for 78K0/FC1+ (QB-48GA-YQ-01T) 0.5x11=5.5 3-R2.5 C2.0 C1.5 048SD 4-φ2.2 φ Figure B-15. YQ Connector for 78K0/FE1+ (QB-64GB-YQ-01T) 0.5x15=7.5 12.04 C2.0...
  • Page 57 Figure B-16. YQ Connector for 78K0/FE1+ (QB-64GK-YQ-01T) 22.1 15.75 0.65x15=9.75 0.65 12.15 C1.5 3-R2.5 C2.0 064SB φ φ 4- 2.2 3- 1.0 Figure B-17. YQ Connector for 78K0/FF1+ (QB-80GK-YQ-01T) 2.2 3.1 11.8 0.5x19=9.5 3-R2.5 C2.0 C1.5 080SD φ φ 4- 2.2 3- 1.0 Figure B-18.

  • Page 58: Mount Adapters

    B.4 Mount Adapters Figure B-19. Mount Adapter for 78K0/FC1+ (QB-44GB-HQ-01T) 19.7 0.8x10=8.0 0.25 C1.5 C2.0 3-R2.5 2.75 044SA φ 2- 1.0 φ 4- 2.2 Figure B-20. Mount Adapter for 78K0/FC1+ (QB-48GA-HQ-01T) 2.75 0.5x11=5.5 C2.0 3-R2.5 C1.5 048SD φ φ Figure B-21. Mount Adapter for 78K0/FE1+ (QB-64GB-HQ-01T) 0.5x15=7.5 2.75 12.04...
  • Page 59 Figure B-22. Mount Adapter for 78K0/FE1+ (QB-64GK-HQ-01T) 22.1 15.75 0.65x15=9.75 12.15 2.15 C2.0 3-R2.5 C1.5 0.65 064SB φ 3- 1.0 φ 4- 2.2 Figure B-23. Mount Adapter for 78K0/FF1+ (QB-80GK-HQ-01T) 11.8 0.5x19=9.5 2.75 C2.0 3-R2.5 C1.5 080SD φ φ 4- 2.2 3- 1.0 Figure B-24.

  • Page 60: Check Pin Adapter

    B.5 Check Pin Adapter Figure B-25. Check Pin Adapter (QB-144-CA-01) User’s Manual U17534EJ1V0UM00...

  • Page 61: Spacer Adapters

    B.6 Spacer Adapters Figure B-26. Spacer Adapter for 78K0/FC1+ (QB-44GB-YS-01T) 19.7 0.8x10=8 C2.0 φ φ φ 4- 1.0 4- 2.2 Figure B-27. Spacer Adapter for 78K0/FC1+ (QB-48GA-YS-01T) 0.5x11=5.5 C2.0 4-φ1.0 4-φ2.2 Figure B-28. Spacer Adapter for 78K0/FE1+ (QB-64GB-YS-01T) 0.5x15=7.5 C2.0 φ...
  • Page 62 Figure B-29. Spacer Adapter for 78K0/FE1+ (QB-64GK-YS-01T) 22.1 0.65x15=9.75 C2.0 0.65 φ 4- 2.2 φ 4- 1.0 Figure B-30. Spacer Adapter for 78K0/FF1+ (QB-80GK-YS-01T) 0.5x19=9.5 C2.0 φ φ 4- 2.2 Figure B-31. Spacer Adapter for 78K0/FF1+ (QB-80GC-YS-01T) 24.1 0.65x19=12.35 0.65 C2.0 φ...

  • Page 63: Emulation Probe

    B.7 Emulation Probe Figure B-32. Emulatio Probe (QB-80-EP-01T) QB-78K0FX1  side User’s Manual U17534EJ1V0UM00...

  • Page 64: Clock Board

    B.8 Clock Board Figure B-33. Clock Board (1/2) (a) Main clock board 2.54 φ 5.81 5.81 7.62 15.43 15.43 15.43 Main Clock Type I Main Clock Type II Main Clock Type II Figure B-34. Clock Board (2/2) (b) Subc ck board 4.54 2.54 15.43...
