Summary of Contents for Bowers & Wilkins 600 3 Series

  • Page 1 Manual 600 Series 3...
  • Page 2 Welcome and thank you for choosing Bowers & Wilkins. Bienvenue et merci d’avoir choisi Bowers & Wilkins. Notre Our founder, John Bowers, believed that imaginative design, fondateur, John Bowers, était persuadé qu’une conception innovative engineering and advanced technology were keys that imaginative, des innovations en terme d’ingénierie et des could unlock the enjoyment of audio in the home.

  • Page 3: Carton Contents

    1. Unpacking Grille Foam Rubber Foot Rubber Foot Spike Plinth Allen 45mm Plain Shakeproof Plug (self-adhesive) (screw-on) Foot Screw Washer Washer 603 S3 606 S3 607 S3 HTM6 S3 Carton Contents Environmental Information The table above illustrates the component parts that are packed This product complies with international directives, including but with the product.

  • Page 4: Speaker Installation

    2. Positioning 603 S3 <36mm <36mm <31mm <31mm <29mm <29mm <15mm <15mm Speaker Installation Important Safety Notice 603 S3 Sharp spikes, do not touch. 603 S3 is intended to be floor mounted only. For proper stability, always install the provided plinth, then ensure that the speakers stand firmly on the floor using the spike or rubber feet supplied.

  • Page 5: Speaker Positioning

    >0.5m >0.5m 1.5m - 3m 606 S3 / 607 S3 Speaker Positioning The 606 S3 and 607 S3 are primarily designed to be mounted In either stereo or home theatre installations, try to ensure that the on a dedicated floor stand (FS-600 S3), but may be placed on immediate surroundings of each speaker are similar in acoustic a shelf if preferred.
  • Page 6 5 Channels 7 Channels >0.5m 110° - 130° 0.5m - 1m 0.5m - 1m ~40° Home Theatre Systems Stray Magnetic Fields If the speakers are to be used for the front channels in a home The speaker drive units create stray magnetic fields that extend theatre system, they should be placed closer together than for beyond the boundaries of the cabinet.

  • Page 7: Conventional Connection

    3. Connections Conventional Connection Bi-Wired Connection - L F - L F - H F - H F + L F + L F Ask your dealer for advice when selecting speaker cable. Keep Important Safety Notice its total impedance below the maximum recommended in the All connections should be made with the audio speaker specification and use a low inductance cable to avoid equipment switched off.

  • Page 8: Fine Tuning

    4. Fine-Tuning Before fine-tuning, make sure that all the connections in the If no alternatives exist, you can adjust your loudspeakers’ low- installation are correct and secure. frequency performance using the supplied foam plugs. The plugs are a two-piece part, allowing for a degree of fine-tuning using Moving the speakers further from the walls will generally reduce either the outer, larger-diameter piece in isolation or the two parts the volume of bass.
  • Page 9 5. Running In 6. Aftercare The performance of the speaker will change subtly during the The cabinet surfaces will usually only require dusting. We initial listening period. If the speaker has been stored in a cold recommend you use a soft microfibre cloth. If you wish to use environment, the damping compounds and suspension materials an aerosol or other cleaner, apply the cleaner onto the cloth, not of the drive units will take some time to recover their correct...
  • Page 10 B&W Group Ltd Dale Road Worthing West Sussex BN11 2BH England EU Importer: Bowers & Wilkins Beemdstraat 11 5653 MA Eindhoven The Netherlands Copyright © B&W Group Ltd. E&OE...
  • Page 11 603 S3 Technical Information...

  • Page 12: Harmonic Distortion

    Technical features Decoupled Double Dome Titanium tweeter Continuum™ cone FST™ midrange Paper bass cones Flowport™ Description 3-way vented-box system Drive units 1x ø25mm (1 in) Titanium Dome high-frequency 1x ø150mm (6 in) Continuum cone FST midrange 2x ø165mm (6.5 in) Paper bass cone Frequency range -6dB 29Hz - 33kHz Frequency response...
