Summary of Contents for Bowers & Wilkins ASW608

  • Page 1 600 Series ASW608 ASW610 Owner’s Manual...
  • Page 4 Figure 7 Integrated Amplifier Line Level Outputs Speaker Outputs SPEAKERS Right Subwoofer Left Subwoofer Figure 8 Integrated Amplifier Outputs SPEAKERS Right Subwoofer Left Subwoofer Figure 9 Pre-Amplifier Line Out Subwoofer Power Amplifier Line In Speaker Outputs SPEAKERS...
  • Page 5 Figure 10 Pre-Amplifier Line Out Subwoofer Power Amplifier Line In Speaker Outputs SPEAKERS Figure 11 Left Subwoofer Pre-Amplifier Line Out Power Amplifier Line In Speaker Outputs Right Subwoofer SPEAKERS Figure 12 Left Subwoofer Pre-Amplifier Line Out Power Amplifier Line In Speaker Outputs Right Subwoofer SPEAKERS...
  • Page 6: Important Safety Instructions

    English 11. Only use attachments/accessories specified by the manufacturer. Owner’s manual 12. Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with the apparatus. When a IMPORTANT SAFETY cart is used, use caution when moving the cart/apparatus combination to avoid injury from INSTRUCTIONS...
  • Page 7: Environmental Information

    tube images beyond this distance. LCD and 2-channel audio systems. All audio installations require Plasma screens are not affected. some thought in installation if they are to reach their full performance potential and this manual will guide 22. Mounting – Do not place this product on an you through the process.
  • Page 8: Electrical Connections

    the overall system balance can be corrected by connections are made or broken. The subwoofer can adjusting the volume level of the subwoofer. The more accept both line level signals via the RCA Phono boost gained from the room, the lower the volume can sockets (Item 11 in Figure 1) and speaker level signals be set and the less hard the subwoofer has to work;...
  • Page 9 Auto: With the switch set to Auto, the subwoofer will channel level controls in the THX ® controller should be initially become fully active and the indicator will glow used. In all cases the levels should be set to obtain green.
  • Page 10: All Applications

    2-channel Audio either the processor output levels or the VOLUME control on the subwoofer amplifier as appropriate), but Set the system up in the preferred position and play only after setting the phase correctly. some programme with a steady bass content. Aftercare The optimum settings of the PHASE switch and the LOW-PASS FREQ control are inter-related and also...
  • Page 11: Explication Des Symboles Graphiques

    e. for products whose serial number has been Français altered, deleted, removed or made illegible, Manuel d’utilisation if repairs or modifications have been executed by an unauthorised person. This guarantee complements any national/regional IMPORTANTES law obligations of dealers or national distributors and does not affect your statutory rights as a INSTRUCTIONS customer.
  • Page 12 ASW610 Description Active closed-box subwoofer system Drive unit 1x ø250mm (10 in) paper/Kevlar ® cone long-throw Frequency range -6dB at 20Hz and 25/140Hz adjustable (EQ at A) Frequency response ±3dB 27Hz - 40/140Hz adjustable (EQ at A) Bass extension -6dB at 20Hz (position A) -6dB at 25Hz (position B) -6dB at 30Hz (position C) Amplifier...
  • Page 13 B&W Group Ltd B&W Group (UK Sales) Kevlar is a registered trademark of DuPont. Dale Road T +44 1903 221 500 Nautilus is a trademark of B&W Group Ltd. E uksales@bwgroup.com Copyright © B&W Group Ltd. E&OE Worthing West Sussex BN11 2BH England Printed in China.
