Set Up Your First Site - Axis Audio Manager Pro User Manual

AXIS Audio Manager Pro
Get started
- AXIS C8110 Network Audio Bridge
- AXIS C1210-E Network Ceiling Speaker
- AXIS C1211-E Network Ceiling Speaker
- AXIS D3110 Connectivity Hub
Note
If you have other types of devices, then you will get an error message, since they use a different application. This is
not a problem. Just close the error message and continue.
The reason we recommend this solution, is that it is simply easier to select all devices than to select only those
that apply to the selected application file.
4.8 Click Next.
4.9 Click No and Finish.
5. Restart the devices:
5.1 Select all the devices you want to use.
5.2 Right-click the selection and click Restart.
5.3 Click Yes to confirm.
6. Configure the AXIS Audio Manager Pro application:
6.1 Select all the devices you want to use.
6.2 Right-click the selection and choose Configure Devices > Configure....
6.3 In the search field, type 'audiomanagerpro'.
6.4 In the Primary server ip address field, enter the IP address of the server that AXIS Audio Manager Pro is
running on.
6.5 Click Next and Finish.
To use a 2N SIP Mic, you need to upgrade to firmware version 1.17.0 or later.
For more information, see the 2N SIP Mic user manual.

Set up your first site

Once you have configured the network and prepared your devices, you are ready to set up a site.
Suggested workflow:
1. Add and organize devices on page 9
2. Set volumes on page 19
3. Set your opening hours on page 14
4. Schedule content on page 10
5. Set up paging on page 15
7
