Danfoss AKS 4100 Installation Manual page 5

Note:
The signal converter can be programmed with or without mechanical process connector assembled.
When used in NH
3
• Connect the device to the power supply
(see the section "Electrical installation/
connection").
• Press 3 times.
AKS 4100
QUICK SETUP ?
YES NO
• Press
AKS 4100
PROBE TYPE
SINGLE CABLE
• Press or to select between SINGLE,
COAXIAL D14 and COAXIAL D22. Choose
COAXIAL D22 and press
AKS 4100
LIQUID CO2 ?
YES
• Press (NO) to con rm
AKS 4100
PROBE LENGTH
280 mm
05000 mm
Default screen
AKS 4100
DISTANCE
5000 mm 250 mm
• Press
AKS 4100
1.0.0
QUICK SETUP ? QUICK START
• Press
AKS 4100
2.0.0
SUPERVISOR
• Press
AKS 4100
2.0.0
__________
Enter password:
AKS 4100
2.1.0
INFORMATION
© Danfoss | DCS (MWA) | 2016.01
Quick Setup (all values below are only examples)
• Press
Press
cursor.
Press
increase the value.
Press
SCALE 4 mA
• Press
Press
Press
increase the value.
Press
SCALE 20 mA
to con rm.
• Press
NO
Press
Press
increase the value.
Press
How to force mA output (all values below are only examples)
• Press
• Press
• Press
• Press
increase the value.
Press
to change the PROBE LENGTH.
to change the position of the
to decrease the value or
to con rm.
AKS 4100
04946 mm 230 mm
to change of SCALE 4 mA.
to change the cursor position.
to decrease the value or
to con rm.
AKS 4100
60 mm
00070 mm
to change of SCALE 20 mA.
to change the cursor position.
to decrease the value or
to con rm.
AKS 4100
2.2.0
TESTS
AKS 4100
2.2.1
SET OUTPUT
AKS 4100
SET OUTPUT
3.5 mA
to decrease the value or
to con rm.
AKS 4100
SET OUTPUT
8 mA
AKS 4100
QUICK SETUP
COMPLETED IN 8
to
• Wait for QUICK SETUP to complete.
Count down from 8 sec.
AKS 4100
1.0.0
QUICK START QUICK SETUP ?
• Press to con rm.
AKS 4100
to
1.0.0
STORE NO
• Press or to select between
STORE NO or STORE YES.
Press to con rm.
Default screen appears:
AKS 4100
DISTANCE
to
5000 mm 250mm
Quick Setup completed
• Press 4 times to return to default
screen.
Default screen appears:
AKS 4100
DISTANCE
250 mm
5000 mm
Force mA completed and disabled
to
DKRCI.PI.SC0.H1.02 | 520H10544 | 5
