3 Product description
Information Meaning
on the identi-
fication plate
Type: Xx3(x) Approved flue gas connec-
tions
PMS Maximum water pressure in
heating mode
Maximum water pressure in
PMW
hot water handling mode
V/Hz Electric connection
W Max. electrical power con-
sumption
IP Level of protection
Heating mode
Hot water generation
Nominal heat output range
Pn
in heating mode
Nominal heat output range
Pnc
in heating mode (condensing
technology)
P Nominal heat output range
in hot water handling mode
Nominal heating load range
Qn
in heating mode
Nominal heating load range
Qnw
in hot water handling mode
T Max. flow temperature
max.
NOx NOx class for the product
Code (DSN) Specific product code
GC no. Gas council number
3.5 Overview of the operator
control elements
5
4
1 Display
2
button
3
button
8
1
2
3
4
button
5
button

3.6 Description of the display

3
1 Operating in-
formation
2 Active operating
mode, selecting
and confirming
the operating
mode
Symbol Meaning
Burner operating correctly
– Burner on
Heating installation filling
pressure
– Permanently on: Filling
– Flashing display: Filling
DHW mode
– Permanently on: Hot wa-
– Flashing: Burner on when
Hot water saving mode
– Hot water temperature <
– Normal operating temper-
Operating instructions EASICOM 0020238425_01
3 Display showing
the current heat-
ing flow temper-
ature, the filling
pressure in the
heating install-
ation, the oper-
ating mode or a
fault code
pressure in the permitted
range.
pressure is outside of the
permissible range or the
purging function has been
activated.
ter activated
the domestic hot water
cylinder is in reheating
mode
50 °C
ature
