- Page 1 Solar Module | Installation Manual | North American Version Conergy PE 245P - 265P...
- Page 2 Make allowance for the loads that these modules may generate for the entire manual. Conergy shall not be held liable for damages arising from a failure to structure. observe and follow the installation manual, particularly the safety instructions To avoid damage (e.g.
- Page 3 (NEC) in the US and in accordance with CSA C22.1, Safety Standard for Electrical Installations, Canadian Electrical Code, Part I (CEC) in Canada. Only use mounting systems recommended by Conergy that can withstand the expected loads for snow, wind, etc. The recommended minimum stand- off height is 54 mm.
- Page 4 Clamping on the short side permitted? Yes fuse rating of the solar modules. − Number of clamps to be used in each case on the short sides: 2 (+1 long side) − Positioning of the clamps on the short sides: N1+N2+N3+N4+L1+L2 Installation Manual Conergy PE 245-265P...
- Page 5 4. Remove the photovoltaic system in the same way as it was in- stalled; (North America). observe the safety instructions. Disposal Do not dispose of old or defective solar modules with normal house hold waste. Please ask your installer, dealer or Conergy about disposal. Installation Manual Conergy PE 245-265P...
- Page 6 Fig. 7-1: Figure 7-1 above displays one method for grounding using Tyco lug 1954381-1 – (UL Certificate No. E69905) Fig. 7-2: Figure 7-2 above displays one method for grounding using an appropriate ground lug that has been tested and listed by NRTL to comply with UL-467 standards (such as the Burndy CL50-1TN) Installation Manual Conergy PE 245-265P...
- Page 7 Maximum Power Open Circut Short Circut Maximum System Maximum Series Power (P Voltage (V Current (I Voltage (Voc) Current (Isc) Voltage (V) Fuse Rating (A) PE 245P 245Wp 29.59V 8.28A 37.50V 8.86A 1000V PE 250P 250Wp 29.94V 8.35A 37.66V 8.92A...
- Page 8 The figures and drawings in these assembly instructions are for illustration only and may differ from reality Conergy reserves the right to make changes to this installation manual without prior notice. O U R W O R L D I S F U L L O F E N E R G Y.
