- Page 1 Conergy PH Series Modules Solar module user manual...
- Page 2 1.2.1 Subject of this manual The subject of this manual is the installation and electrical connection of the Conergy PH module in a photovoltaic system. This manual applies to the following modules: Conergy PH 175-200M, Conergy PH 220-255P, Conergy PH 230-260M BL.
-
Page 3: Basic Safety Instructions
(producing higher voltages), and in parallel (producing higher current). | Make allowance for the loads that the Conergy PH modules may generate for the entire structure. The modules have been evaluated by UL for a maximum positive design loading of 5400Pa/113lbs/ft | In order to prevent damage (e.g. - Page 4 Variable clamping range Fig. 3-1: Dimensions (mm) Conergy PH 175-200M 1580 mm 50 mm 300 mm Conergy PH 220-255P and Conergy PH 230-260M BL 1652 mm 50 mm 300 mm...
- Page 5 3.2 Securing the photovoltaic modules to the frame Prevent damage to the photovoltaic modules due to incorrect installation. | Work only in dry conditions. | Secure the modules against slipping and falling. | Do not drop the modules. | Do not hold the module by its socket or connection cables. | Always carry modules that are to be lifted by two opposite points on the frame.
-
Page 6: Electrical Values
Modules of the same type can be connected in parallel or in series. Modules or series strings of modules connected in parallel may require overcurrent protection in each series string. The maximum series fuse ratings for Conergy PH modules are as follows:... -
Page 7: Maintenance And Care
4 Maintenance and care Conergy PH modules are low-maintenance. However, Conergy recommends that you carry out a visual inspection and a check of the mechanical and electrical connections for damage once a year. Dirt on the modules reduces the output and the yield. -
Page 8: Technical Data
8.33A The electrical characteristics are within +/-10 percent of the indicated values of Isc, Voc and Pmax under standard test conditions (irradiance of100mW/cm2, AM 1.5 spectrum, and a cell temperature of 25°C (77°F). Conergy PH 230-260M BL Open Short Maximum... - Page 9 O U R W O R L D I S F U L L O F E N E R G Y . Conergy Global Headquarters Conergy US Headquarters Conergy Canada Headquarters Anckelmannsplatz 1 2460 West 26th Avenue, Suite 280C 17815 - 111 Ave.
