- Page 1 KERN & Sohn GmbH Ziegelei 1 Phone: +49-[0]7433- 9933-0 D-72336 Balingen Fax: +49-[0]7433-9933-149 E-Mail: info@kern-sohn.com Internet: www.kern-sohn.com Installation Instructions Platform KERN KBP V20 Type TKBP-V20-A Version 1.0 2023-09 TKBP-V20-A-IA-e-2310...
-
Page 2: Table Of Contents
KERN KBP V20 Platform Version 1.0 2023-09 Installation Instructions Contents General hints ....................3 Technical data ....................3 Technical data of the weighing cell ..................4 Basic Information (General) ................5 Documentation ......................... 5 Proper use ..........................5 Improper Use ..........................5 Warranty ............................ -
Page 3: General Hints
1 General hints These installation instructions contain all data necessary for placing and commissioning the following platforms: KERN TKBP 6V20LM-A KERN TKBP 15V20M-A, TKBP 15V20LM-A KERN TKBP 30V20M-A KERN TKBP 60V20M-A, TKBP 60V20LM-A KERN TKBP 150V20M-A, TKBP 150V20LM-A KERN TKBP 300V20M-A... -
Page 4: Technical Data Of The Weighing Cell
2.1 Technical data of the weighing cell Sensitivity 2 mV/V 406 Ω ± 6 Ω Input resistance (all TKBP models*) 409 Ω ± 6 Ω *excepted TKBP 6V20LM-A TKBP 15V20M-A TKBP 15V20LM-A 350 Ω ± 3 Ω Output resistance 5 – 12 V AC/DC Power supply Accuracy class TKBP-V20-A-IA-e-2310... -
Page 5: Basic Information (General)
• The weighing system unit may only be operated in accordance with the described default settings. Other areas of use must be released by KERN in writing. 3.4 Warranty Warranty claims shall be voided in case: •... -
Page 6: Basic Safety Precautions
In KERN's accredited DKD calibration laboratory test weights and weighing systems may be calibrated (return to the national standard) fast and at moderate cost. -
Page 7: Unpacking, Installation And Commissioning
6 Unpacking, Installation and Commissioning 6.1 Installation Site, Location of Use The platforms are designed in a way that reliable weighing results are achieved in common conditions of use. You will work accurately and fast if you select the right location for your weighing system. -
Page 8: Unpacking, Scope Of Delivery
6.2 Unpacking, Scope of delivery Remove the underconstruction and the weighing plate from the package, remove packaging material and place the devices at the planned workplace. Check if all parts of the scope of delivery are present and free of damage. Scope of delivery: •... -
Page 9: Transport Securing
6.3.1 Transport Securing General hints for transport securing • Please consult the Technical Data whether your balance is equipped with a transport securing, chap. 2. • Do not remove the off-centre load attachments (1) as otherwise the balance could be damaged. The off-centre load attachments are located between the upper and the lower part of the platform. -
Page 10: Levelling
Put the connecting cable to the display unit in a manner that it is protected against damage. Connect the platform to the display unit according to the following table. Output load cell Connection of platform KERN KBP EXC+ (5V) see labelling of load cell EXC- (0) -
Page 11: Operation Limits
8 Operation limits The platform is designed so robust that a casual excess of the maximum weighing load will not cause any damage. The static carrying capacity, i.e. the maximum admitted load depends on the type of load carrier (Position A – C). The maximum static carrying capacity must not be exceeded. -
Page 12: Servicing, Maintenance, Disposal
Keep IP protection. 9.2 Servicing, maintenance The appliance may only be opened by trained service technicians who are authorized by KERN. Ensure that the weighing system is regularly calibrated, see chap. 3.5 Testing instruments monitoring. 9.3 Disposal ... -
Page 13: Instant Help For Troubleshooting
10 Instant help for troubleshooting In case of an error in the program process, briefly turn off the balance and disconnect from power supply. The weighing process must then be restarted from the beginning. Help: Fault Possible cause • Draught/air movement The displayed weight is permanently changing •... -
Page 14: Preload, Deadload And Overload Settings
11 Preload, Deadload and Overload settings Deadload** (kg) Centric overload Off-centre overload Minimum capactiy of the Maximum capacity of Item no./ Type **= already applied protection (kg) protection (kg) load cell E (kg) the load cell E (kg) preload TKBP 6V20LM-A 3,06 TKBP 15V20M-A 2,36... - Page 15 Item no./ Type Dimensions of Load cell type Test certificte no. Accur Ratio of min. Maximum admitted Allowable Ratio of min. Error the platform load cell number of interval temperature dead load output percentage (mm) class verification sizes range return interval ( °C) ( °C)
-
Page 16: Enclosure
12 Enclosure TKBP-V20-A-IA-e-2310... - Page 17 4 3 1 6 1 6 3 4 3 3 7 4 1 6 53 5 4 1 3 % " % ' ( ) * % % 4 3 4 5 6 ÿ...
- Page 18 ! ÿ # ÿ 3 1 6 2 9 3 5 1 1 O P Q 6 P Q 1 3 1 5 6 1 6 %L 2 6 ! 6 5 6 4...
- Page 19 4 3 1 6 1 6 3 4 3 3 7 4 1 6 53 5 4 1 3 4 3 4 5 6 ÿ 4 1 ÿ M 4 3 5 N O N O 9 5 6 $ G ? % ...
- Page 20 ! 6 5 2 $H @ % ! 6 4 2 3 ÿ...
- Page 21 9 9 8 9 8 9 4 2 3 ! " H @ % 43 # ÿ...
- Page 22 ! " ÿ...
- Page 23 4 3 1 6 1 6 3 4 3 3 7 4 1 6 53 5 4 1 3 4 3 4 5 6 ÿ 4 1 ÿ ! I 4 3 5 J K K 9 5 6 "...
- Page 24 ! ÿ ÿ 2 7 9 5 1 2 6 7 8 J H K 7 2 K 7 2 7 6 9 5 H $I @ % ! 9 1 H 3...
- Page 25 4 3 1 6 1 6 3 4 3 3 7 4 1 6 53 5 4 1 3 4 3 4 5 6 ÿ 4 1 ÿ ! J 4 3 5 ! K K 9 5 6 ! "...
- Page 26 ! ÿ # ÿ 2 7 9 8 2 6 6 2 I J K 7 2 K 7 2 7 6 9 8 8 %7 8 &...
