KERN 572-30 Operating Instructions Manual

Precision/ compact balances and platform scales
Hide thumbs Also See for 572-30:
Table of Contents

Advertisement

Quick Links

Operating instructions

Precision/ compact balances and
platform scales
KERN 572/573/KB/DS/FKB/FCB
Version 5.7
12/2009
GB
KERN & Sohn GmbH
Ziegelei 1
D-72336 Balingen
E-Mail: info@kern-sohn.com
572/573/KB/DS/FKB/FCB-BA-e-0957
Tel: +49-[0]7433- 9933-0
Fax: +49-[0]7433-9933-149
Internet: www.kern-sohn.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 572-30 and is the answer not in the manual?

Questions and answers

Related Manuals for KERN 572-30

Summary of Contents for KERN 572-30

  • Page 1: Operating Instructions

    KERN & Sohn GmbH Ziegelei 1 Tel: +49-[0]7433- 9933-0 D-72336 Balingen Fax: +49-[0]7433-9933-149 E-Mail: info@kern-sohn.com Internet: www.kern-sohn.com Operating instructions Precision/ compact balances and platform scales KERN 572/573/KB/DS/FKB/FCB Version 5.7 12/2009 572/573/KB/DS/FKB/FCB-BA-e-0957...

  • Page 2: Table Of Contents

    Connecting peripheral equipment ....................24 Initial start-up ............................ 24 Adjustment ............................25 Adjusting (go to 7.2.6)........................25 6.8.1 Adjusting for verification (KERN 573; FKB-M; KB-NM; FCB-M; DS-M) ..........25 Verification ............................26 Operation .......................27 Display control panel ........................27 Operation............................28 Display background illumination ....................

  • Page 3: Mode - Menue

    MODE - MENUE Manufacture Setting: Important! The modified settings - as well as the adjustment - must be stored when switching-off, via the ON/OFF button. 572/573/KB/DS/FKB/FCB-BA-e-0957...

  • Page 4: Technical Data

    Technical data 2.1 KERN 572 KERN 572-30 572-31 572-32 572-33 Readability (d) 0.001 g 0.001 g 0.001 g 0.01 g Weighing range (max) 241 g 301 g 421 g 1610 g Taring range (subtractive) 241 g 301 g 421 g...
  • Page 5 KERN 572-35 572-37 572-39 572-43 Readability (d) 0.01 g 0.01 g 0.01 g 0.1 g Weighing range (max) 2410 g 3010 g 4210 g 10100 g Taring range (subtractive) 2410 g 3010 g 4210 g 10100 g Reproducibility 0.01 g 0.01 g...
  • Page 6 KERN 572-45 572-49 572-55 572-57 Readability (d) 0.05 g 0.1 g 0.05 g 0.1 g Weighing range (max) 12100 g 16100 g 20100 g 24100 g Taring range (subtractive) 12100 g 16100 g 20100 g 24100 g Reproducibility 0.05 g 0.1 g...

  • Page 7: Kern 573

    KERN 573 KERN 573-34NM 573-36NM 573-46NM 573-56NM Accuracy class Readability (d) 0.01 g 0.01 g 0.1 g 0.1 g Verification value (e) 0.1 g 0.1 g Weighing range (max) 650 g 2000 g 6500 g 20000 g Minimum load (Min) 0.5 g...

  • Page 8: Kern Kb

    KERN KB KERN KB 120-3N KB 200-3N KB 240-3N KB 360-3N Readability (d) 0.001 g 0.001 g 0.001 g 0.001 g Weighing range (max) 121 g 201 g 241 g 361 g Taring range (subtractive) 121 g 201 g 241 g...
  • Page 9 KERN KB 1200-2N KB 2000-2N KB 2400-2N KB 3600-2N Readability (d) 0.01 g 0.01 g 0.01 g 0.01 g Weighing range (max) 1 210 g 2 010 g 2 410 g 3 610 g Taring range (subtractive) 1 210 g...
  • Page 10 KERN 10000-1N 10k0.05N Accuracy class Readability (d) 0.1 g 0.05 g Weighing range (max) 10 100 g 10 100 g 10 100 g 10 100 g Taring range (subtractive) 0.1 g 0.05 g Reproducibility 0.3 g 0.15 g Linearity 0.1 g 0.05 g...
  • Page 11 KERN 650-2NM 6500-1NM 2000-2NM 10000-1NM Accuracy class Readability (d) 0.01 g 0.1 g 0.01 g 0.1 g Verification value (e) 0.1 g 0.1 g Weighing range (max) 650 g 6 500 g 2 000 g 10 000 g Minimum load (Min) 0.5 g...

  • Page 12: Kern Ds

    KERN DS KERN 3K0.01S 5K0.05S 8K0.05 10K0.1S Readability (d) 0.01 g 0.05 g 0.05 g 0,1 g Weighing range (max) 3 100 g 5 100 g 8 100 g 10.100 g Taring range (subtractive) 3 100 g 5 100 g 8 100 g 10.100 g...
  • Page 13 KERN 16K0.1 20K0.1 30K0.1 Accuracy class Readability (d) 0.1 g 0.1 g 0.1 g Verification value (e) Weighing range (max) 16 100 g 20 100 g 30 100 g Minimum load (Min) Taring range (subtractive) 16 100 g 20 100 g...
  • Page 14 KERN 36K0.2 30K0.1L 36K0.2L 60K0,2 Accuracy class Readability (d) 0.2 g 0.1 g 0.2 g 0.2 g Verification value (e) Weighing range (max) 36 100 g 30 100 g 36 100 g 60 100 g Minimum load (Min) Taring range (subtractive)
  • Page 15 KERN 65K0.5 100K0.5 150K1 Readability (d) 0,5 g 0,5 g Weighing range (max) 65 100 g 101 000 g 151 000 g Taring range (subtractive) 65 100 g 101 000 g 151 000 g Reproducibility 0,5 g 0,5 g Linearity ±...
  • Page 16 KERN 15K0.1M 65K1M 150K1M 50K1TM 100K2TM Accuracy class Readability (d) 0.1 g 1 g / 2 g / 5 g 2 g / 5 g /10 Verification value (e) 10 g 10 g 1 g / 2 g / 5 g...

  • Page 17: Kern Fcb

    KERN FCB KERN 6K0.02B 12K0.05B 12K0.1B 24K0.1B 24K0.2B Readability (d) 0.02 g 0.05 g 0.1 g 0.1 g 0.2 g Weighing range (max) 6 100 g 12 100 g 12 100 g 24 100 g 24 100 g Taring range (subtrac-...
  • Page 18 KERN 8K0.1BM 15K0.1BM 15K1BDM Accuracy class Readability (d) 0.1 g 0.1 g Verification value (e) 1 g / 2 g Weighing range (max) 8 000 g 15 000 g 7.5 kg / 15 kg Minimum load (Min) 50 g Taring range (subtractive)

  • Page 19: Kern Fkb

    KERN FKB KERN 6K0.02 8K0.05 16K0.05 16K0.1 Readability (d) 0.02 g 0.05 g 0.05 g 0.1 g Weighing range (max) 6 100 g 8 100 g 16 100 g 16 100 g Taring range (subtractive) 6 100 g 8 100 g...
  • Page 20 KERN 36K0.1 36K0.2 65K0.2 65K0.5 Readability (d) 0.1 g 0.2 g 0.2 g 0.5 g Verification value (e) Weighing range (max) 36 100 g 36 100 g 65 100 g 65 100 g Minimum load (Min) Taring range (subtractive) 36 100 g...
  • Page 21 KERN 8K0.1M 15K0.1M 65K1M 50K1TM Accuracy class Readability (d) 0.1 g 0.1 g 1 g/2 g/5 g Verification value (e) 1.0 g 1.0 g 10 g 1 g/2 g/5 g Weighing range (max) 8 000 g 15 000 g 65 000 g...

  • Page 22: Fundamental Information (General)

    For this purpose, the answerable user must define a suit- able interval as well as the nature and scope of this check. Information is available on KERN’s home page (www.kern-sohn.com) with regard to the monitoring of balance test substances and the test weights required for this.

  • Page 23: Fundamental Safety Information

    Observe the information in the operating instructions Please read the operating instructions carefully before erecting and commissioning, even if you already have experience with KERN balances. Staff training The device may only be operated and looked after by trained members of staff.

  • Page 24: Unpacking

    Electric power supply is by means of the external mains supply circuit. The printed voltage level must comply with the local voltage. Only use original KERN mains supply circuits. The use of other makes is subject to approval by Kern. 6.4 Battery operation FKB To insert the batteries (6 x 1.5 V) remove the battery compartment cover.

  • Page 25: Adjustment

    Check that the surrounding conditions are stable. A short warm-up time of about 15 minutes is recommended for stabilisation. 6.8.1 Adjusting for verification (KERN 573; FKB-M; KB-NM; FCB-M; DS-M) General Information: Prior to the procedure of verification the balance has to be adjusted.

  • Page 26: Verification

    Verification General: According to the EU guideline 90/384/EEC balances must be verified officially if they are to be used as fol- lows (legally regulated area): a) For commercial transactions if the price of goods is determined by weighing b) For the production of medicines in pharmacies as well as for analyses in the medical and pharma- ceutical laboratory c) For official purposes d) For the production of finished packages...

  • Page 27: Operation

    Operation 7.1 Display control panel Keyboard ON / OFF Print weighing result in MODE: No / descending in % and counting mode: Form reference in MODE: Yes / ascending MODE configuration (see mode structure diagram page 2) Formula weighing in MODE: to left Change g-pieces Unit changeover in MODE: to right...

  • Page 28: Operation

    7.2 Operation 572/573/KB/DS/FKB/FCB/PCB-BA-e-0957...
  • Page 29 572/573/KB/DS/FKB/FCB-BA-e-0957...
  • Page 30 572/573/KB/DS/FKB/FCB/PCB-BA-e-0957...
  • Page 31 572/573/KB/DS/FKB/FCB-BA-e-0957...

  • Page 32: Display Background Illumination

    Baud rate adjustable to 2400, 4800 and 9600 baud (default), 19200 baud Sup-D- 9 pol. is necessary . When working with an interface correct operation is secured only if the corresponding KERN-interface- cable (max. 2m) is used. Description of the jack Sup-D- 9 pol.

  • Page 33: Rs 232 C Data Output Via Interface Rs 232 C

    The printer format is stored in the printer, i.e. in case of a failure the printer cannot be changed with a new one from factory, previously it is necessary that KERN installs the respective software. The Zebra printer and the balance must be connected to the delivered interface cable when they are switched off.

  • Page 34: Numerator

    7.5.3 Numerator The Numerator is found under the menu point “Printer” and can be activated and deactivated. When editing data with the use of the print option, the range of the numerator will increase by one place. 7.6 Printer With the serial data output RS 232 a printer can be connected. The printout shows the weight in grams.

  • Page 35: Maintenance, Upkeep, Disposal

    Loose sample residue/powder can be removed carefully using a brush or hand vacuum cleaner. Remove any spilt material to be weighed immediately. 8.2 Maintenance, upkeep The device may only be opened by trained service engineers authorised by KERN. Disconnect from the mains supply before opening. 8.3 Disposal The operating company shall dispose of the packaging and the device in compliance with the valid national or regional law of the operating location.

  • Page 36: Declaration Of Conformity

    Заявление о Мы заявляем, что продукт, к которому относится данная декларация, соответствии соответствует перечисленным ниже нормам. Electronic Balance: KERN 572 / 573 / FCB / FKB / KB..N / DS Mark applied EU Directive Standards 2004/108/EC EN 61000-6-3:2001...
  • Page 37 TCM 128/08 - 4632 FKBxxKxxM 90/384/EEC EN 45501 TCM 128/08 - 4636 FCBxxKxxM 90/384/EEC EN 45501 TCM 128/08 - 4637 DSxxKxxM Date: 18.12.2009 Signature: Gottl. KERN & Sohn GmbH Management Gottl. KERN & Sohn GmbH, Ziegelei 1, D-72336 Balingen, Tel. +49-[0]7433/9933-0,Fax +49-[0]7433/9933-149 572/573/KB/DS/FKB/FCB-BA-e-0957...
