Arjo AtmosAir Velaris - Plus Flex Quick Reference Manual-Use

QUICK REFERENCE GUIDE - USE

AtmosAir Velaris - Plus Flex

For use with Citadel Plus bed frame

2, 3

1. Left side bolster

2. Mattress connector

3. Mattress connector cavity

4. Foot bolster

5. Mattress

6. Buckles (four on each side)

7. Right side bolster

8. Cover attachment zip with zip flap

9. Non-Slip strips

10. Cable management loops

11. Handles (two on each bolster)

12. Buckles (four on each bolster)

13. Side bolster retaining straps (two at the head end,

two at the foot end)

08.AAV.03EN_01 • 2023-11 • Page 1/5
