Single Ovens
Users Instruction & Installation Book
Note: Timer must be set to 'Time of Day' and 'Manual'
before the oven(s) can be used.
Note: Ensure that the oven is securely fixed to the
cabinet before use.
This appliance shall be installed in accordance with the
regulations in force and only used in a well ventilated space.
Read the instructions before installing or using the
appliance and retain them for future use
Advertisement
Table of Contents
Related Manuals for Creda Single Oven
Summary of Contents for Creda Single Oven
- Page 1 Users Instruction & Installation Book Note: Timer must be set to ‘Time of Day’ and ‘Manual’ before the oven(s) can be used. Note: Ensure that the oven is securely fixed to the cabinet before use. This appliance shall be installed in accordance with the regulations in force and only used in a well ventilated space.
- Page 2 For more information on our exciting product range ring Creda Answer Centre 0541 54 64 74 Our site invites you to make use of our browse our product range free to for help on our products and services General Domestic Appliances Ltd. Morley Way Peterborough PE2 9JB It may be necessary from time to time to change the specification outlined in this booklet without notice.
-
Page 3: Table Of Contents
CONTENTS Introduction For Your Safety – Always For Your Safety – Never Features Controls Oven Timer Operation Know Your Timer Electronic Clock & Automatic Timer Operation Grill Pan and Handle Using The Grill Using the Oven Care and Cleaning Installation... -
Page 4: Introduction
INTRODUCTION Your new cooker is guaranteed* and will give lasting service. This guarantee is only applicable if the appliance has been installed in accordance with the installation instructions detailed in this booklet. The cooker is designed specifically for domestic use and responsibility will not be accepted for use in any other installation. -
Page 5: For Your Safety - Always
Always make sure all controls are turned off when you have finished cooking and when not in use. Always stand back when opening an oven door to allow any build up of steam or heat to disperse. Always use dry, good quality oven gloves when removing items from the oven/grill. -
Page 6: For Your Safety - Never
Never allow anyone to sit or stand on any part of the appliance. Never store items above the appliance that children may attempt to reach. Never remove the oven shelves whilst the oven is hot. Never heat up unopened food containers as pressure can build up causing the container to burst. -
Page 7: Features
FEATURES Oven Temperature Control Oven Light Meat/Grill pan Data Badge Inner Door Glass Grill Control Grill Fan Oven/Grill select 24 Hour Digital Electronic Clock and Oven Timer Minute Cook Minder Time Manual Period Grill Burner Heatclean Liners 2 Oven Shelves... -
Page 8: Controls
The main oven has an “Slow Cook” setting. This can be used for slow Setting cooking, keeping food warm and warming plates for a short period. Note: It is advisable to check that all oven controls have been switched off when you GRILL CONTROL Description... -
Page 9: Oven Timer Operation
5. If cooking food that requires frying before placing in the oven for auto cooking, keep the delay start time to a minimum. 6. Never place hot or warm food in the oven for delay start cooking as it could cause the oven to be warm and produce harmful bacteria in the food. -
Page 10: Know Your Timer
For Example: If you set a “Cook Period” for 2 hours, and “End Time” of 11:00. The timer will switch the oven(s) on at 9:00 and turn the oven(s) off at 11:00. You will hear a audible tone at 11:00, to indicate that the Auto Cooking Programme has finished. -
Page 11: Electronic Clock & Automatic Timer Operation
“–” button until 0.00 appears in the display window. SETTING THE TIME OF DAY Step 1 Make sure all oven controls are turned Off. Step 2 Check the electricity supply to the cooker is turned on. Step 3 When switched on the display will show 0.00 and Auto symbol will be flashing intermittently. -
Page 12: Auto Cooking Programmes
Step 1 Check that the correct time of day is set, if not follow instructions for setting the time of day. Step 2 Place food onto the correct shelf position in the oven and close the oven door(s). Cooktop Symbol... - Page 13 Check that the correct time of day is set, if not follow instructions for setting the time of day. Step 2 Place food onto the correct shelf position in the oven and close the oven door(s). Step 3 Turn the oven control(s) to the required temperature, and if necessary select the appropriate oven function.
- Page 14 5. If at any time the display shows three flashing zero’s 0.00. It is likely that the electricity supply to the oven has been interrupted. Reset the timer to the correct time of day. Food in the oven may, therefore, not have been cooked, before serving check food is thoroughly heated and completely cooked.
-
Page 15: Grill Pan And Handle
GRILL PAN & HANDLE The grill pan handle is detachable from the pan, to facilitate cleaning and storage. The grill pan handle can be fixed as follows: Step 1 Remove screw & washers from the grill pan bracket. Step 2 Tilt the handle over the recess (A). Step 3 Slide it towards the centre of the pan (B). -
Page 16: Using The Grill
USING THE GRILL CAUTION - ACCESSIBLE PARTS MAY BECOME HOT WHEN THE GRILL IS USED. Step 1 Remove the heat shield from the rear of an oven shelf and place the shelf in the top position. Step 2 Push in and turn the control knob anti - clockwise to the large flame symbol. -
Page 17: Using The Oven
You may notice a slight smell of gas when you close the oven door. This is due to the short delay while the burner reignites and will soon disperse. - Page 18 1. If food is to be frozen or not served immediately, cool it in a clean container as quickly as possible. 2. Completely thaw frozen food in the refrigerator before re-heating. 3. Re-heat food thoroughly and quickly either on the hotplate or in a hot oven, Mk. 6, and then serve immediately. 4. Only re-heat food once.
- Page 19 11. Adjust seasonings and thickenings at the end of the cooking time. 12. Use the zones of heat in the oven, e.g. meringues and milk puddings can be cooked lower in the oven whilst other dishes requiring greater heat can be cooked above them.
-
Page 20: Main Oven Cooking Chart
If using aluminium foil: 1. Remember it is important to increase the cooking time by one third. 2. Do not allow the foil to touch the sides of the oven. 3. Do not cover the oven interior with foil. 4. Do not cover the oven shelves with foil. - Page 21 When baking with two trays or tins on two levels, the top tray is removed first and the lower tray moved up to the top position for a few minutes longer. Soft Margarine – Use the oven settings recommended by the margarine manufacturer and not those indicated on the cooking chart.
-
Page 22: Care And Cleaning
1. “CREDACLEAN” OVEN LINERS MAIN OVEN SIDE LINERS AND REAR PANEL DO NOT use biological washing powder, harsh abrasives or chemical oven cleaners of any kind as this could damage the “Credaclean” oven liners. 2. CLEANING MAIN OVEN AND GRILL... - Page 23 Warning: Before removing lamp lens, please ensure that the electricity supply to the appliance is switched off and the appliance is fully cold. Open the oven door and remove the oven shelves. Using a thick cloth, grip the lamp lens, unscrew anti- clockwise and remove the lens.
-
Page 24: Cleaning The Doors
NOTE: The inner door glass has a special reflective coating on one side. Replace the door inner glass so that the statement: “IMPORTANT THIS FACE TOWARDS THE OVEN” can be read from the inner side of the door. Turn the two securing brackets back to their original position to retain the glass and tighten the screws. -
Page 25: Installation
The adjustment conditions for this appliance are stated on the data badge which is fitted behind the bottom of the main oven door seal. This appliance is not designed to be connected to a combustion products evacuation device. -
Page 26: Installation Instructions
It is important that the installation instructions for the hob are strictly observed. Where a hob is fitted above the oven unit the electrical connection for the hob should be made with an 85˚ C high temperature flexible cord to table 15 of BS 6141. -
Page 27: Final Installation
Before the oven is fitted, the cabinet must be firmly secured to the backing wall for stability. d. The oven unit should now be lifted (this is a two person lift) into the cabinet and pushed fully home. e. Finally, the oven is secured to the cabinet by means of the four Pozi Wash Head screws - two through each side trim. - Page 28 Ventilation Slot 150 cm if cabinet doesn't fit to ceiling 30mm Fig. 1 Oven 30mm Tall Cabinet When fitting a hob above an oven always use these installation instructions in conjunction with the hob instructions. Fig. 3 Built Under Ventilation Slot...
- Page 29 The appliance can be installed into a cabi- net of minimum depth 550mm provid- ing a suitable means of connection to the gas supply can be made. Single Oven in tall Cabinet 580mm max 575mm if cooker trim is to...
- Page 30 INSTALLATION INSTRUCTIONS CONNECTING TO GAS SUPPLY The oven is designed to be connected with an approved appliance flexible connection to BS 669. A length of 0.9 to 1.25m is recommended. An adaptor backplate should be fitted in the area shown to allow the appliance to be pushed fully back into the cabinet.
-
Page 31: Electrical Connection
The mains lead should be routed such that it cannot touch hot parts of the appliance i.e. the back panel above a height of 350mm from the bottom of the oven recess. If the oven is to be wired into a... - Page 32 Check that, with the main oven set to mark 9, the burner ignites at low rate, and then increases to full rate within 60 seconds. Leave the oven full on with the door closed for 10 minutes, and check that when the control is turned to the ‘Slow...
-
Page 33: Something Wrong
Remember that " Cook period " is the actual length of time for which the timer will switch the oven(s) on as part of an "Auto cooking " programme. A gentle flow of air will be blown from beneath the control panel when the appliance is used. -
Page 36: Service
Republic of Ireland: (01) 842 6836 08701 546474 For further product information All Creda Services are offered as an extra benefit and do not affect your statutory rights. General Domestic Appliances Limited, Morley Way, Peterborough, PE2 9JB PRINTED BY SIMLEX . FOUR ASHES, WOLVERHAMPTON.
