Instructions for Installation and Use
Single Oven
Note: Timer must be set to 'Time of Day' and 'Manual'
before the oven can be used.
Note: Ensure that the oven is securely fixed to the
cabinet before use.
To the Installer
Before installation fill in the product details on the back cover of this
booklet. The information can be found on the rating plate.
To the User
You must read the instructions prior to installing and using the
appliance and then retain them for future reference.
Advertisement
Table of Contents
Related Manuals for Creda REFLECTION
Summary of Contents for Creda REFLECTION
-
Page 1: Single Oven
Single Oven Note: Timer must be set to ‘Time of Day’ and ‘Manual’ before the oven can be used. Note: Ensure that the oven is securely fixed to the cabinet before use. To the Installer Before installation fill in the product details on the back cover of this booklet. - Page 2 For more information on our exciting product range ring Creda Answer Centre 0541 54 64 74 Visit us on the NET at http://www.creda.co.uk interactive cookbook product selector. Our site invites you to make use of our Feel browse our product range...
-
Page 3: Table Of Contents
For Your Safety – Never Know Your Oven Control Panel Oven Timer Operation Know Your Timer Electronic Clock & Automatic Oven Timer Operation Grill Pan and Handle Grilling Procedure Using the Oven as a Fan Oven Using the Oven for Other Functions... -
Page 4: Introduction
To help remove the 'new' smell, heat up the empty oven(s) to maximum for a minimum of two to three hours keeping the oven doors closed. Ensure that the room is well ventilated (e.g. open a window or use an extractor fan) and that persons who may be sensitive to the odour avoid any fumes. -
Page 5: Safety Advice
Always make sure all controls are turned off when you have finished cooking and when not in use. Always stand back when opening an oven door to allow any build up of steam or heat to disperse. Always use dry, good quality oven gloves when removing items from the oven/grill. -
Page 6: For Your Safety - Never
Never allow anyone to sit or stand on any part of the appliance. Never store items above the appliance that children may attempt to reach. Never remove the oven shelves whilst the oven is hot. Never heat up unopened food containers as pressure can build up causing the container to burst. -
Page 7: Know Your Oven
KNOW YOUR OVEN Oven Control and Selector Oven Light Meat/Grill pan with anti-splash tray Oven Fan Rating plate Inner Door Glass Grill Oven Control Indicator Light 24 Hour Digital Electronic Clock and Oven Timer Solar Plus Grill Element Stayclean Liners... -
Page 8: Control Panel
& Grill Control A & B Note: Resistance will be felt when turning from fan oven operation to full grill / half grill positions Cooling Fan A gentle flow of air will be blown below the control panel when the oven or grill is switched on. -
Page 9: Oven Timer Operation
If cooking food that requires frying before placing in the oven for automatic cooking, keep the delay time to a minimum. Never place hot or warm food in the oven for delay start cooking as it could cause the oven to be warm and produce harmful bacteria in the food. -
Page 10: Know Your Timer
“Manual” button twice – The “Auto” symbol will go out). Note: If at any time the display shows a ‘KEY’ symbol, it is likely that the timer has been set incorrectly. OVEN COOKING IS NOT POSSIBLE. The ‘KEY’ symbol can be deleted and the cooker returned to manual operation by: Simultaneously pressing the Minute Minder and the Cook Period buttons for a period of approximately 8 seconds. -
Page 11: Setting Minute Minder
TIMER OPERATION SETTING THE TIME OF DAY Step 1 Make sure all oven controls are turned Off. Step 2 Check the electricity supply to the cooker is turned on. Step 3 When switched on the display will show 0.00 and Auto symbol will be Step 4 Press &... -
Page 12: Timer Operation
(b) To set timer to switch on immediately and OFF automatically after a set cook period. a) TO SET THE TIMER TO SWITCH THE OVEN(S) ON AND OFF AUTOMATICALLY This allows you to cook at a specified time for a chosen period before the oven switches off Automatically. - Page 13 Check that the correct time of day is set, if not follow instructions for setting the time of day. Step 2 Place food onto the correct shelf position in the oven and close the oven door(s). Step 3 Turn the oven control(s) to the required temperature, and if necessary select the appropriate oven function.
- Page 14 (d) Press & release the “Manual” button. (e) Start the sequence again. 5. If at any time the display shows three flashing zero’s 0.00. It is likely that the electricity supply to the oven has been interrupted. Reset the timer to the correct time of day.
-
Page 15: Grill Pan And Handle
If a detachable handle is required, do not replace screw & washers. Note: If a fixed handle is required, the grill pan is unable to be stored in the oven with the door closed and cannot be used as a meat pan. -
Page 16: Grilling Procedure
Step 4 After use, turn both controls A & B to their off (0) position and close the oven door. Your cooker is not fitted with a conventional type of grill. Creda have developed a Solar Plus high speed grill which is designed to reduce your grilling times. It is quicker because it takes less time to warm up from cold. -
Page 17: Guide To Grilling Successfully
No. 1 = Very Gentle Heat Shelf Position Setting required from base for cooking of oven 5 or 6 5 or 6 6 for 5 - 10 mins reduced to 4 or 5 6 reduced to 4 or 5 after 8 - 10 mins... -
Page 18: Using The Oven For Fan Cooking
Food or utensils should never be placed directly on the floor of the oven for cooking as air circulation is restricted. DO NOT allow young children near to the appliance when the oven is in use as the surfaces get extremely hot. - Page 19 Place food centrally on the shelf ensuring the oven door is fully closed. Step 2 Turn knob (A) clockwise and select the required cooking temperature . The pilot light ( ) will immediately come on, and remain on until the oven reaches the required temperature. The light will then automatically go off and on during cooking as the oven thermostat maintains the correct temperature.
-
Page 20: Using The Oven For Other Functions
Extra care should be taken when warming bone china, as it may be damaged in a hot oven. DO NOT place food or plates directly on the oven floor as this could damage both the oven lining and the plates which are being warmed. -
Page 21: Temperature Conversion Scale
TEMPERATURE CONVERSION SCALE ˚F Mark Main Convection Oven – – Main Oven... -
Page 22: Oven Temperature Charts
Beef Rare 60˚C Medium 70˚C Fan Oven Cooking Note: Up to three shelves may be used in this oven. The position of these is not important providing they are evenly spaced. Pre- Temperature heat ˚C... -
Page 23: Oven Temperature Charts - Baking
OVEN TEMPERATURE CHARTS – BAKING Baking Note: Up to three shelves may be used in this oven. The position of these is not important providing they are evenly spaced. Pre- Food heat Scones Small Cakes Victoria Sandwich Sponge Sandwich (Fatless) -
Page 24: Cooking Results Not Satisfactory
Ensure that the grill setting is not too high. Remember to use the anti - splash tray. Ensure that the oven shelves are level. The following may cause cakes to sink: 1. Pre-heating of fan ovens – not always necessary. -
Page 25: Care & Cleaning
If the user feels it is desirable to do so, wipe them over with a clean, soapy cloth, followed by a wipe with a clean damp cloth. DO NOT use biological washing powder, harsh abrasives or chemical oven cleaners of any kind as this could damage the “Credaclean” oven liners. -
Page 26: Cleaning The Oven
BASE (a) Base of Main Oven. Wipe out the oven with a damp soapy cloth. For more stubborn stains on the base of the oven use a well soaped fine steel wool soap pad. (b) Grill/Meat Pan & Oven Shelves. -
Page 27: Care And Cleaning
Warning: Before removing lamp lens, please ensure that the electricity supply to the appliance is switched off and the appliance is fully cold. Open the oven door and remove the oven shelves. Using a thick cloth, grip the lamp lens, unscrew anti- clockwise and remove the lens. -
Page 28: Care & Cleaning
NOTE: The inner door glass has a special reflective coating on one side. Replace the door inner glass so that the statement: “IMPORTANT THIS FACE TOWARDS THE OVEN” can be read from the inner side of the door. Turn the two securing brackets back to their original position to retain the glass and tighten the screws. -
Page 29: Installation Instructions
INSTALLATION INSTRUCTIONS IMPORTANT This equipment is designed specifically for domestic purposes and Creda Limited cannot accept responsibility if used in any other type of installation. All Creda oven units are suitable for installation under Creda hob units. This appliance must not be installed over any appliance that generates heat. -
Page 30: Electrical Installation
Fig. 1. (e) If an oven unit is installed adjacent to a tall cabinet, steam escaping from the oven when the door is opened could condense on, and perhaps stain the adjacent surface. -
Page 31: Final Installation
Where a hob is fitted adjacent to or above an oven a 30 amp or 45 amp double pole switch with a minimum contact clearance of 3mm should be used to feed both units via separate suitably rated cables. -
Page 32: Installation Instructions
51 x 457mm min area 50mm Fig. 1 Oven 50mm Tall Cabinet When fitting a hob above an oven always use these installation instructions in conjunction with the hob instructions. Use 2.5mm High Temp Cable. Refer to Electrical Installation. Fig. 3... - Page 33 INSTALLATION INSTRUCTIONS Fig. 4 Double Pole Control Switch Cable if Hotplate fitted Conduit Box Cable if hob fitted adjacent to oven Cable to Oven Refer to Electrical Installation Fig. 5 Single Oven in tall Cabinet 585mm max 575mm if cooker...
-
Page 34: Something Wrong
(a) Check If you find :- Display is blank. Then it is likely that there is no electricity supply to your oven. Check: (i) That the main cooker wall switch is turned on. (ii) Check other appliances to see if you have a power cut. -
Page 36: Repair Service
Republic of Ireland: (01) 842 6836 08701 546474 For further product information All Creda Services are offered as an extra benefit and do not affect your statutory rights. General Domestic Appliances Limited, Morley Way, Peterborough, PE2 9JB PRINTED BY SIMLEX . FOUR ASHES, WOLVERHAMPTON.
