Quick Setup

The Quick Setup menu gives the user access to the most frequent settings (see figure 12).
Quick EDID
Next
Setup 720p @60Hz
Figure 12.
EDID
Allows the user to assign an EDID to the HDMI input.
• EDID is available for assignment via the LCD menu or SIS.
Both are pre-defined and custom EDID settings are available.
•
Aspect Ratio
Allows the user to set the aspect ratio of the output to fill the entire output (Fill) or to
display the input in its native aspect ratio (Follow) on the output.
Default: Fill
•
Available modes: Fill/Follow
•
Output Rate
Allows the user to set the scaler output resolution using the left ADJUST knob ( [ ) and the
refresh rate for the HDMI outputs using the right ADJUST knob ( { ).
Test Pattern
Allows the user to immediately send video out of the scaler without having an HDMI input
applied (see
Calibrate Panels
Allows the user to enter calibration mode to calibrate the connected USB touchpanels (see
Calibrate Panels

Picture Controls

The Picture Controls menu includes horizontal and vertical image size and position
adjustments (see figure 13). When the aspect ratio changes due to fill/follow commands, the
horizontal size and position variables are updated accordingly.
Controls
Figure 13.
Image Reset
Quickly sizes and centers the incoming signal to the output setting based on the input fill or
follow setting. When executed, the user is prompted to push the NEXT button a second time
to confirm.
Aspect Ratio
Next Next
Fill 1024x1024 @60Hz
Quick Setup Menu
Test Patterns on page 20 for more details).
on page 20 for more details).
Next
Image Reset
<No> Yes
Picture Controls Menu
Output Rate Test Pattern
Next
Color Bars
Next
H Center V
-00001 +00002
Annotator 401 • Operation
Calibrate Panels
Next
<No> Yes
Next
H Size V
01024 00768
