IKA RC 5 control Operating Instructions Manual page 19

3� Temperature sensor:
1) Calibration:
The internal and external temperature measurement can be calibrated and adjusted�
You can select 2-point calibration or 3-point calibration for internal and external measurement�
Calibration proceeding (example: 2-point calibration):
> Tempering
Temperature Sensor
Calibration
Reset Calibration
> Calibration > Internal
2 Point Calibration
Step: 1 / 2
Temperature sensor calibration
at
30�00
OC
OK
> Calibration > Internal
2 Point Calibration
Step: 1 / 2
Enter the temperature from the
measuring device
5�00
OC
OK
Fig. 27
2) Reset Calibration:
By "Reset Calibration", the calibration value for the internal or the external temperature sensor will be deleted�
4� Notification:
1) ON:
This menu option allows you to activate/deactivate the "Notification" function� A green check mark and a beep inform-
ing when the target value (hysteresis) has been reached�
2) Hysteresis:
This menu option allows you to set the hysteresis from 0 to ± 2�0 K�
3) Sound:
Infinite: Beep until you press the "Back" button�
Beep: Single beep�
PUMP
Limits:
In "Limits" option, the user is allowed to set the maximum
and minimum speed to the pump, and also the maximum
pressure�
> Temperature Sensor
Calibration
Internal
External
> Calibration > Internal
2 Point Calibration
Step: 1 / 2
Temperature sensor calibration
at
30�00
OC
OK
> Calibration > Internal
2 Point Calibration
Step: 1 / 2
Enter the temperature from the
measuring device
32�00
OC
OK
> Calibration
Internal
2 Point Calibration
3 Point Calibration
> Calibration > Internal
2 Point Calibration
Step: 1 / 2
30�00
Target Temp: OC
25�00
Actual Temp: OC
Please wait���
> Calibration > Internal
2 Point Calibration
Step: 1 / 2
Enter the temperature from the
measuring device
32�00
OC
OK
TIMER
1� Set:
The user can set a target time (duration)�
When device functions are started normally, this time is
displayed on the working screen� The device functions
stop automatically once this time has expired� The running
time is then displayed again on the display�
Note: To deactivate the target time specification, set the
target time to 00:00�
2� Display:
Activate the timer display on the main display (working
screen)�
> Calibration > Internal
2 Point Calibration
Step: 1 / 2
Temperature sensor calibration
at
5�00
OC
OK
> Calibration > Internal
2 Point Calibration
Step: 1 / 2
30�00
Target Temp: OC
30�00
Actual Temp: OC
OK
> Calibration > Internal
2 Point Calibration
Sensor calibrated successfully
OK
