IKA Service-Manual
Shaker / Schüttler
KS 4000i control
No. 35100.00
IKA ®
IKA – Werke GmbH & Co. KG
Janke & Kunkel-Str. 10
D - 79219 Staufen
Phone: 0049 (0)7633 831 139 / 202
Fax: 0049 (0) 7633 500 212
E-Mail: service@ika.de
Internet:
www.ika.de
Previous
Page
Next
Page
1
2
3
4
5
Advertisement
Related Manuals for IKA KS 4000i
Controller IKA C 5000 Service Manual
(32 pages)
Controller IKA EUROSTAR 20 Manual
High speed control (18 pages)
Controller IKA RC 5 control Operating Instructions Manual
(32 pages)
Controller IKA RC 2 GREEN control Operating Instructions Manual
(30 pages)
Controller IKA VC 10 Operating Instructions Manual
(164 pages)
Controller IKA VC 10 Operating Instructions Manual
(81 pages)
Summary of Contents for IKA KS 4000i
Page 1
IKA Service-Manual Shaker / Schüttler KS 4000i control No. 35100.00 IKA ® IKA – Werke GmbH & Co. KG Janke & Kunkel-Str. 10 D - 79219 Staufen Phone: 0049 (0)7633 831 139 / 202 Fax: 0049 (0) 7633 500 212 E-Mail: service@ika.de...
Page 2
Type: Item No.:3510000 KS 4000i control Voltage: 230 V~ 50/60 Hz ® Service-Manual Date: SZ: 3510000SZ 11-SEP-2008 Item No Bezeichnung Description Technical data Bemerkung Remark 1 1466400 LINSENSCHRAUBE OVAL HEAD SCREW M 5,0x16,0 4.8-A 2 2636200 SICHERUNGSSCHRAUBE SECURING SCREW M 5,0x 16,0 100verz...
Page 3
Type: Item No.:3510000 KS 4000i control Voltage: 230 V~ 50/60 Hz ® Service-Manual Date: SZ: 3510000SZ 11-SEP-2008 Item No Bezeichnung Description Technical data Bemerkung Remark 37 3685300 Kabelhalter cable holder Typ: PKKL-4 38 3685500 Kabelklemme cable clamping Typ: SRCC-1 39 3453400 GEWINDESTIFT hexagon sock.set screw...
Page 4
Type: Item No.:3510000 KS 4000i control Voltage: 230 V~ 50/60 Hz ® Service-Manual Date: SZ: 3510000SZ 11-SEP-2008 Item No Bezeichnung Description Technical data Bemerkung Remark 74 2334200 SCHLAUCH HOSE d= 10,0x 2,0 PVC 75 2276800 DURCHFÜHRUNGS-TÜLLE GROMMET 24,0x14,0x 7,0PVCsw 77 2931000 SNAP-KABELDURCHFÜHRUNG SNAP-CABLE DUCT...
Page 5: Connecting Terminal
Type: Item No.:3510000 KS 4000i control Voltage: 230 V~ 50/60 Hz ® Service-Manual Date: SZ: 3510000SZ 11-SEP-2008 Item No Bezeichnung Description Technical data Bemerkung Remark 119 3037200 ANSCHLUSSKLEMME CONNECTING TERMINAL P 3 A10,0V 250 120 2839900 EINBAUGERÄTESTECKER ASSEMBLY APPARATUS Plug...
Page 6: Danger Sign
Type: Item No.:3510000 KS 4000i control Voltage: 230 V~ 50/60 Hz ® Service-Manual Date: SZ: 3510000SZ 11-SEP-2008 Item No Bezeichnung Description Technical data Bemerkung Remark 175 2913101 WARNSCHILD DANGER SIGN 180 3713800 Warnschild warning sign 181 3713900 Warnschild warning sign...
Page 7
40+43 36+115+122 80+110 34+35 36+115+122 61+154 59+60 11+137+139 18+20 155+156 Servicezeichnung / service drawing KS 4000 i control 35 100 00SZ_ 24.06.08...
Page 8
41+42 15+52 25+39 14+53+113 94+171 16+32 Erdung Verteiler Pos. 165 / 8x Litze zwischen Gehäuseaussenteilen Servicezeichnung / service drawing Pos. 164 Litze mit Schraublasche an Boden grounding distributor KS 4000 i control Pos. 165 / 8x wire betrween outside planking parts Pos.
Page 9
8+54 18+20+164 123+161+162 Servicezeichnung / service drawing KS 4000 i control 35 100 00SZ_ 24.06.08...
Page 10
Verdrahtungsplan / wiring diagram Lüfter / blower 1703 Markierung mit Kabelbinder marked with cable tie 1702 Lichtschranke 2 / Light interrupter 2 164 / 18 / 20 Lichtschranke 1, Markierung mit kabelbinder Light interrupter 1, marking with cable tie RD + / BK - 2001 1701 Motor...
