Operator Panel And Display; Station; Wico - IKA RC 5 control Operating Instructions Manual

station:

A
Fig. 16
Item Designation
A Fluid level indicator:
B LED bar:
C Contacts:
D safe STOP key:
E Bluetooth searching key: Search the WiCo when the Bluetooth
®
F Bluetooth LED:
®

WiCo:

Fig. 17
Item Designation
L On/Off button:
M "int/ext" button:
N "Timer/Pump" button:
O Graph button:
P Rotating/pressing knob:
R Rotating/pressing knob:
S Display:
T "Back" button:
U "Menu" button:
V Lock button:

Operator panel and display

F
High
Low
Fluid level
B
Function
Indicate the bath fluid level (when the fluid level is too low or too high, the
bottom or the top LED segment change into red color)�
Display different status of the circulator with different color�
Communicate and charge the WiCo�
Safely stop the working of the circulator in emergency�
Bluetooth indicator�
®
L
M
N
O
P
Function
Switch the WiCo on and off�
Switch between the internal and external temperature display and control�
Switch between the timer and pump display�
Display time/temperature graph�
Set the temperature value�
Start/Stop the cooling function�
Navigation, selecting and changing the settings in the menu�
Set the pump speed value�
Start/Stop the pump function�
Screen�
Return to the previous menu level�
Press it once: main menu is displayed�
Press it a second time: back to the working screen�
Lock/Unlock the knobs and buttons�
C
is active�
®
E
D
V
U
T
S
R
