protech BM-0982 User Manual

Thin mini-itx intel pentium n4200 / celeron j3455 / celeron n3350 embedded soc
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
USER
MANUAL
BM-0982 M1
BM-0982
Thin Mini-ITX Intel
Pentium
N4200 / Celeron
®
J3455 / Celeron
Embedded SoC
®
N3350
®
®

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BM-0982 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for protech BM-0982

Summary of Contents for protech BM-0982

  • Page 1 USER MANUAL BM-0982 Thin Mini-ITX Intel ® Pentium N4200 / Celeron ® ® J3455 / Celeron N3350 ® Embedded SoC BM-0982 M1...
  • Page 2 BM-0982 ® ® Thin Mini-ITX Intel Pentium N4200 / ® ® Celeron J3455 / Celeron N3350 Embedded SoC COPYRIGHT NOTICE & TRADEMARK All trademarks and registered trademarks mentioned herein are the property of their respective owners. This manual is copyrighted in March 2019. You may not reproduce or transmit in any form or by any means, electronic, or mechanical, including photocopying and recording.
  • Page 3 a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications.

  • Page 4: Table Of Contents

    Introduction ..................1-1 About This Manual ..............1-2 Getting Started ..................2-1 Packing List ................2-2 BM-0982 Specifications ............2-3 Safety Precautions ..............2-5 Hardware Configuration ..............3-1 Jumper & Connector Quick Reference Table ......3-2 Component Locations ............... 3-3 3.2.1...
  • Page 5 3.4.11 HD Audio Connector ............3-16 3.4.12 Front Panel Connector ............ 3-17 3.4.13 TPM Module / 80 Port ............. 3-17 3.4.14 Mini PCI Express Slot ............3-18 3.4.15 PCI Express Slot ............. 3-19 3.4.16 SATA 3.0 Connector ............3-20 3.4.17 SATA Power Connector ...........
  • Page 6 ® Installing Intel Serial I/O Driver Utility ........4-8 Microsoft Hotfix kb3211320 and kb3213986 Driver installation 4-9 BIOS SETUP ..................5-1 Introduction ................5-2 Accessing Setup Utility .............. 5-3 Main ................... 5-5 Advanced .................. 5-7 5.4.1 Advanced – Trusted Computing ........5-8 5.4.2 Advanced - ACPI Settings ..........
  • Page 7 Chipset - Display Configuration ........5-40 Security ................... 5-41 Boot ..................5-43 Save & Exit ................5-45 Appendix A Technical Summary ..........A-1 BM-0982 Block Diagram ................. A-2 Interrupt Map ..................... A-3 I/O MAP ......................A-17 Memory Map ....................A-19 Configuring WatchDog Timer ................ A-21...

  • Page 8: Introduction

    Introduction This chapter provides the introduction for the BM-0982 system as well as the framework of the user manual. The following topics are included: • About This Manual Page: 1-1 BM-0982 SERIES USER MANUAL...

  • Page 9: About This Manual

    It is not intended for general users. The following section outlines the structure of this user manual. Chapter 1 Introduction This chapter provides the introduction for the BM-0982 system as well as the framework of the user manual. Chapter 2 Getting Started This chapter describes the package contents and outlines the system specifications.

  • Page 10: Getting Started

    Getting Started This chapter provides the information for the BM-0982 system. It describes the package contents and outlines the system specifications. The following topics are included: • Package List • System Specification • Safety Precautions Experienced users can go to...

  • Page 11: Packing List

    If you discover any of the items listed above are damaged or list, please contact your local distributor immediately. Item Q’ty BM-0982 Quick Reference Guide Manual / Driver DVD Mini Jumper (2.0 mm) SATA Cable (170mm) I/O Shield Page: 2-2 BM-0982 SERIES USER MANUAL...

  • Page 12: Bm-0982 Specifications

     COM 1/2: RS-232 / 422 / 485 & support RI / 5V / 12V Serial Ports selected under BIOS (Rear I/O)  COM 3~6: RS-232 (pin header)  8bit GPIO: 4in / 4out (pin header) DIO Port Page: 2-3 BM-0982 SERIES USER MANUAL...
  • Page 13  2 x PS/2 (rear I/O) Keyboard/ Mouse Environment  0°C ~ 60°C (32°F ~ 140°F) Operating Temp.  -40° C ~ 80° C (-4°F ~ 176°F) Storage Temp.  20%~ 90% (68°F ~ 194°F) Humidity Page: 2-4 BM-0982 SERIES USER MANUAL...

  • Page 14: Safety Precautions

    Avoid direct sunlight exposure for a long period of time (for example, in a closed car in summer time. Also avoid the system from any heating device.). Or do not use BM-0982 when it has been left outdoors in a cold winter day. •...

  • Page 15: Hardware Configuration

    This chapter contains helpful information about the jumper & connector settings, and component locations. The following sections are included: • Jumper & Connector Quick Reference Table • Component Locations • Configuration and Jumper Settings • Connector Pin Assignments Page: 3-1 BM-0982 SERIES USER MANUAL...

  • Page 16: Jumper & Connector Quick Reference Table

    SATA 3.0 Connector SATA1, SATA2 SATA Power Connector SATA_PWR1, SATA_PWR2 M.2 M-KEY Slot M2_M TPM MODULE / 80 Port JLPC1 PS2 Keyboard / Mouse Connector KB_MS1 CASH DRAWER Connector JPDRW1 RTC Battery Connector JBAT1 Page: 3-2 BM-0982 SERIES USER MANUAL...

  • Page 17: Component Locations

    Make sure both the system and peripheral devices are turned OFF as sudden surge of power could damage sensitive components. Make sure BM-0982 is properly grounded. CAUTION: Observe precautions while handling electrostatic sensitive components. Make sure to ground yourself to prevent static charge while you are working on the connectors and jumpers.

  • Page 18: Jumper Setting Of Bm-0982Ra-**N

    SATA_PWR1 LVDS Panel Selection Selection SATA1 JP_VDD2 LVDS2 Normal Clear CMOS Data 30 29 CH7511 JINV2 (default) (default) JPDRW1 SO_DIMM2 LVDS Backlight JFP1 Control Selection JP_VDD1 JBAT1 FAN1 JI2C1 JINV1 LVDS1 SO_DIMM1 3.3V (default) Page: 3-4 BM-0982 SERIES USER MANUAL...

  • Page 19: Bottom View Of Bm-0982Ra-**N

    Chapter 3 Hardware Configuration 3.2.3 Bottom View of BM-0982RA-**N 3.2.4 I/O View of BM-0982RA-**N VGA Port LAN Ports COM Port Line In PS/2 Keyboard Line Out Mic In DC IN PS/2 Mouse USB Ports Display Port Page: 3-5 BM-0982 SERIES USER MANUAL...

  • Page 20: How To Set Jumpers

    PIN1 & PIN2 to create one setting by shorting. You can either connect PIN2 & PIN3 to create another setting. The same jumper diagrams are applied all through this manual. The figure below shows what the manual diagrams look and what they represent. Page: 3-6 BM-0982 SERIES USER MANUAL...
  • Page 21 Jumper Block looks like this Jumper Settings 2 pin Jumper close(enabled) Looks like this 3 pin Jumper 2-3 pin close(enabled) Looks like this Jumper Block 1-2 pin close(enabled) Looks like this Page: 3-7 BM-0982 SERIES USER MANUAL...

  • Page 22: Setting Connectors And Jumpers

    3.4.1 COM1 and COM2 PIN9 Definition Selection Guide Jumper Location: JP_COM1, JP_COM2 Description: COM1 and COM2 Port pin9 RI/5V/12V Selection SELECTION JUMPER SETTING JUMPER ILLUSTRATION (Default Setting) JP_COM1 JP_COM2 +12V JP_COM1 JP_COM2 JP_COM2 JP_COM1 Page: 3-8 BM-0982 SERIES USER MANUAL...

  • Page 23: Com Connector

    COM5_CTS_R COM5_DTR_R COM5_RI_R COM6(RS232) Connector Pin Assignment: ASSIGNMENT ASSIGNMENT COM6_DCD_R COM6_DSR_R COM6_RX_R COM6_RTS_R COM6_TX_R COM6_CTS_R COM6_DTR_R COM6_RI_R Notes: Default setting is RS232. Please see Chapter 5 “Advanced – Onboard Device Configuration” for selection details. Page: 3-9 BM-0982 SERIES USER MANUAL...
  • Page 24 COM2_CTS_R COM1_RI_SEL COM2_RI_SEL Note: COM1, COM2: Pin 9 is selectable for RI, +5V or +12V by jumper setting. Default setting is RI, please see “COM1 and COM2 PIN9 Definition Selection Guide” for selection details. Page: 3-10 BM-0982 SERIES USER MANUAL...

  • Page 25: Vga Port

    CRT_VSYNC_O CRT_DDC_CLK_O 3.4.4 DISPLAY Port Connector Location: DISPLAY1 Description: Display Port Connector PIN ASSIGNMENT PIN ASSIGNMENT DP0_TX0_DP_C DP0_TX0_DN_C DP0_TX1_DP_C DP0_TX1_DN_C DP0_TX2_DP_C DP0_TX2_DN_C DP0_TX3_DP_C DP0_TX3_DN_C G_CEC G_NC AUXP_SCL G_SDA AUXN_G DPHPD_HDMI5V HDMIHPD DP VCC3 DISPLAY1 Page: 3-11 BM-0982 SERIES USER MANUAL...

  • Page 26: Lan & Usb Port

    No LAN Switch/HUB connected Right Side LED Yellow Color Blinking LAN Message Active No LAN Message Active USB 3.0 signals: ASSIGNMENT ASSIGNMENT VCC5_USB1 VCC5_USB1 USB2_P1_DN USB2_P0_DN USB2_P1_DP USB2_P0_DP USB3_RXN1 USB3_RXN0 USB3_RXP1 USB3_RXP0 USB3_TXN1 USB3_TXN0 USB3_TXP1 USB3_TXP0 Page: 3-12 BM-0982 SERIES USER MANUAL...
  • Page 27 No LAN Switch/HUB connected Right Side LED Yellow Color Blinking LAN Message Active No LAN Message Active USB 3.0 signals: ASSIGNMENT ASSIGNMENT VCC5_USB1 VCC5_USB1 USB2_P3_DN USB2_P4_DN USB2_P3_DP USB2_P4_DP USB3_RXN3 USB3_RXN4 USB3_RXP3 USB3_RXP4 USB3_TXN3 USB3_TXN4 USB3_TXP3 USB3_TXP4 Page: 3-13 BM-0982 SERIES USER MANUAL...

  • Page 28: Usb 2.0 Port

    Description: Digital Input / Output pin header and 5V power. PIN ASSIGNMENT PIN ASSIGNMENT VCC5 DIN0 DOUT0 DIN1 DOUT1 DIN2 DOUT2 DIN3 DOUT3 JDIO1 Notes: Users can set the DIN/DOUT configuration via Protech’s API/Utility. Page: 3-14 BM-0982 SERIES USER MANUAL...

  • Page 29: I2C Wafer

    Description: I2C Wafer ASSIGNMENT V3P3S I2C0_SCL_33 I2C0_SDA_33 JI2C1 3.4.10 System Fan Connector Connector Location: FAN1 Description: System Fan Connector ASSIGNMENT VCC12 SYS_FANOUT SYS_FANIN FAN1 Notes: Fan speed mode can be set by BIOS or API. (Optional) Page: 3-15 BM-0982 SERIES USER MANUAL...

  • Page 30: Hd Audio Connector

    Chapter 3 Hardware Configuration 3.4.11 HD Audio Connector Connector Location: AUDIO1 Description: HD Audio Connector Line-In: ASSIGNMENT HD_FRONT-L HD_GND HD_FRONT-R HD_GND Line-Out: ASSIGNMENT HD_LINE-IN-L HD_GND HD_LINE-IN-R HD_GND AUDIO1 MIC-In: ASSIGNMENT HD_GND HD_MIC1-L HD_GND HD_MIC1-R HD_GND Page: 3-16 BM-0982 SERIES USER MANUAL...

  • Page 31: Front Panel Connector

    VCC-LED SATA_LED_A_N RST_SW LPC_PWRBTNJ JFP1 3.4.13 TPM Module / 80 Port Connector Location: JLPC1 Description: TPM Module / 80 Port PIN ASSIGNMENT PIN ASSIGNMENT LPC_CLKOUT1_33 LPC_LFRAMEJ_33 GND/LPC_SER_IRQ_33 PMU_PLTRST_N LPC_AD0_33 LPC_AD3_33 LPC_AD2_33 V3P3A/V3P3S LPC_AD1_33 JLPC1 Page: 3-17 BM-0982 SERIES USER MANUAL...

  • Page 32: Mini Pci Express Slot

    Mini PCI Express is the successor of the Mini PCI card and provides an increased data throughput. The cards have a detached network interface and are equipped with one lane. They are used in particular in embedded designs or compact box PCs. Page: 3-18 BM-0982 SERIES USER MANUAL...

  • Page 33: Pci Express Slot

    PCI Express Slot Connector Location: PCI_E1 Description: PCI Express Slot ASSIGNMENT ASSIGNMENT VCC12 VCC12 VCC12 VCC12 VCC12 SMB_3P3_SCL SMB_3P3_SDA V3P3S V3P3S V3P3A V3P3S PCI_E1 WAKE_PCIEx1_N PMU_PLTRST_N PCIE_CLKREQ3 PCIEx1_CLKP PCIE_P5_TXP PCIEx1_CLKN PCIE_P5_TXN PCIE_P5_RXP V3P3S PCIE_P5_RXN Page: 3-19 BM-0982 SERIES USER MANUAL...

  • Page 34: Sata 3.0 Connector

    Chapter 3 Hardware Configuration 3.4.16 SATA 3.0 Connector Connector Location: SATA1, SATA2 Description: SATA 3.0 Connector SATA1 signals: ASSIGNMENT SATA_TXP0 SATA_TXN0 SATA_RXN0 SATA_RXP0 SAT2 signals: ASSIGNMENT SATA1 / SATA2 SATA_TXP1_B SATA_TXN1_B SATA_RXN1_B SATA_RXP1_B Page: 3-20 BM-0982 SERIES USER MANUAL...

  • Page 35: Sata Power Connector

    SATA_PWR1 signals: ASSIGNMENT VDD5 SATA_PWR2 signals: SATA_PWR1 / ASSIGNMENT SATA_PWR2 VDD5 3.4.18 Keyboard & Mouse Port Connector Location: KB_MS1 Description: PS/2 Keyboard & Mouse Port ASSIGNMENT ASSIGNMENT KB_DATA_L MS_DATA_L KBMS_VCC_L KBMS_VCC_L KB_CLK_L MS_CLK_L KB_MS1 Page: 3-21 BM-0982 SERIES USER MANUAL...

  • Page 36: Rtc Battery Connector

    Chapter 3 Hardware Configuration 3.4.19 RTC Battery Connector Connector Location:JBAT1 Description: RTC (Real-Time Clock) Battery Connector ASSIGNMENT VBAT JBAT1 3.4.20 Cash Drawer Connector Connector Location:JPDRW1 Description: Cash Drawer Connector ASSIGNMENT Drawer1_Open Drawer1_Sensor JPDRW1 Page: 3-22 BM-0982 SERIES USER MANUAL...

  • Page 37: Lvds Panel Connector

    LVDS_A0_DN LVDS_A3_DP LVDS_A3_DN LVDS_VCC LVDS_VCC LVDS2 Pin Assifnment: ASSIGNMENT ASSIGNMENT LVDS_VCC_2nd LVDS_CLKB_DN_2nd LVDS_CLKB_DP_2nd LVDS_B2_DN_2nd LVDS_B2_DP_2nd LVDS_B1_DN_2nd LVDS_B1_DP_2nd LVDS_B3_DP_2nd LVDS_B3_DN_2nd LVDS_B0_DP_2nd LVDS_B0_DN_2nd LVDS_CLKA_DP_2nd LVDS_CLKA_DN_2nd LVDS_A2_DP_2nd LVDS_A2_DN_2nd LVDS2 LVDS_A1_DP_2nd LVDS_A1_DN_2nd LVDS_A0_DP_2nd LVDS_A0_DN_2nd LVDS_A3_DP_2nd LVDS_A3_DN_2nd LVDS_VCC_2nd LVDS_VCC Page: 3-23 BM-0982 SERIES USER MANUAL...

  • Page 38: Lvds Backlight Connector

    Chapter 3 Hardware Configuration 3.4.22 LVDS Backlight Connector Connector Location: JINV1, LINV2 Description: LVDS Backlight Connector JINV1 Pin Assifnment: ASSIGNMENT V12P0_INV V12P0_INV LVDS_BKLCTL LVDS_BKLTEN JINV2 Pin Assifnment: JINV1 / JINV2 ASSIGNMENT V12P0_INV_2nd V12P0_INV_2nd LVDS_BKLCTL_2nd LVDS_BKLTEN_2nd Page: 3-24 BM-0982 SERIES USER MANUAL...

  • Page 39: M-Key Solt

    Chapter 3 Hardware Configuration 3.4.23 M.2 M-KEY Solt Connector Location: M2_M Description: M.2 M-KEY Solt ASSIGNMENT ASSIGNMENT V3P3S V3P3S M2_M TP28 TP27 SATA_RXP1_C SATA_RXN1_C SATA_TXN1_C SATA_TXP1_C TP26 V3P3S V3P3S Page: 3-25 BM-0982 SERIES USER MANUAL...

  • Page 40: Lvds Backlight Control Selection

    LVDS Backlight Control Selection Jumper Name: JP5, JP6 Description: Jumper for selecting PIN18 (LVDS_BKLCTL) voltage of JINV1. SELECTION JUMPER SETTING JUMPER ILLUSTRATION 3.3V (Default Setting) Note 1: Users can change the setting according to panel specification Page: 3-26 BM-0982 SERIES USER MANUAL...

  • Page 41: Lvds Panel Selection

    3.4.25 LVDS Panel Selection Jumper Name: JP4 Description: LVDS Panel Mode Selection SELECTION JUMPTER SETTING JUMPER ILLUSTRATION (Default Setting) JPM2_1 CH7511 JPM2_1 LVDS Sequence BKLTCTL FROM 1-3 (Default) CH7511 BKLEN FROM 2-4 (Default) CH7511 Page: 3-27 BM-0982 SERIES USER MANUAL...

  • Page 42: Lvds Vcc Voltage Selection

    Description: Voltage selection jumper for selecting PIN1, PIN29, PIN30 (LVDS_VCC) voltage of LVDS1. JUMPTER SELECTION JUMPER ILLUSTRATION SETTING 3.3V (Default Setting) JP_VDD1 JP_VDD2 JP_VDD2 JP_VDD1 JP_VDD1 JP_VDD2 Note: Please refer to PANEL INVERTER CONNECTOR for more information about pin definition of JINV1. Page: 3-28 BM-0982 SERIES USER MANUAL...

  • Page 43: Sata Con/M.2 Selection

    Chapter 3 Hardware Configuration 3.4.27 SATA Con/M.2 Selection Jumper Name: JPM2_1 Description: SATA Con/M.2 Selection SELECTION JUMPTER SETTING JUMPER ILLUSTRATION SATA (Default Setting) JPM2_1 M.2_M JPM2_1 Page: 3-29 BM-0982 SERIES USER MANUAL...

  • Page 44: Tpm Module Selection

    Chapter 3 Hardware Configuration 3.4.28 TPM Module Selection Jumper Name: JP_TPM1 Description: TPM Module Selection SELECTION JUMPTER SETTING JUMPER ILLUSTRATION Normal (Default Setting) JPM2_1 Enable JPM2_1 Page: 3-30 BM-0982 SERIES USER MANUAL...

  • Page 45: Clear Cmos Data Selection

    Step3. Remove the cap which is just used on JP3 (1-2), so that JP3 returns to “OPEN”. Step4. Power on the PC and the PC will then auto-reboot for once in order to set SoC’s register. Step5. Done! SELECTION JUMPER SETTING JUMPER ILLUSTRATION Open Normal (Default Setting) Clear CMOS* Page: 3-31 BM-0982 SERIES USER MANUAL...

  • Page 46: Software Utilities

    • Installing Intel ® Trusted Execution Engine Driver installation • Installing LAN Driver Utility • Installing Sound Driver Utility • Installing Intel ® Serial I/O Driver Utility • Microsoft Hotfix kb3211320 and kb3213986 Driver installation BM-0982 SERIES USER MANUAL Page: 4-1...

  • Page 47: Introduction

    Chapter 4 Software Utilities Introduction Enclosed with the BM-0982 Series package is our driver utilities contained in a DVD-ROM disk. Refer to the following table for driver locations: Filename (Assume that DVD-ROM drive Purpose Win10 UEFI is D:) (64-bit) For Aptio(EFI) BIOS update ...

  • Page 48: Installing Intel Chipset Software Installation Utility

    10 series, and it should be installed immediately after the OS installation is finished. Please follow the steps below: Connect the USB DVD-ROM device to BM-0982 and insert the driver disk. Enter the 1_Main Chip folder where the Chipset driver is located (depending on your OS platform).

  • Page 49: Installing Graphics Driver Utility

    Chapter 4 Software Utilities Installing Graphics Driver Utility The GRAPHICS interface embedded in BM-0982 can support a wide range of display types. You can have dual displays via LVDS interfaces and make the system work simultaneously. To install the VGA driver utility, follow the steps below: Connect the USB DVD-ROM device to BM-0982 and insert the driver disk.

  • Page 50: Intel Trusted Execution Engine Driver Installation

    Installation Instructions for Windows 10 Insert the driver disk into a DVD ROM device. Under Windows system, go to the directory where the driver is located. Run the application with administrative privileges. BM-0982 SERIES USER MANUAL Page: 4-5...

  • Page 51: Installing Lan Driver Utility

    Enhanced with LAN function, BM-0982 supports various network adapters. To install the LAN Driver, follow the steps below: Connect the USB DVD-ROM device to BM-0982 and insert the driver disk. Enter the 5_LAN Chip folder where the driver is located (depending on your OS platform).

  • Page 52: Installing Sound Driver Utility

    POSReady 7 & Windows 7 series. To install the Sound Driver, follow the steps below: Connect the USB DVD-ROM device to BM-0982 and insert the driver disk. Open the 4_Sound folder where the driver is located (depending on your OS platform).

  • Page 53: Installing Intel Serial I/O Driver Utility

    Installing Intel Serial I/O Driver Utility To install the Serial I/O Driver, follow the steps below: Connect the USB DVD-ROM device to BM-0982 and insert the driver disk. Open the 6_Serial I/O folder where the driver is located. Select Windows 10 (64-bit) for your OS platform.

  • Page 54: Microsoft Hotfix Kb3211320 And Kb3213986 Driver Installation

    To install the utility, simply follow the following steps: Insert the driver disk into a DVD ROM device. Under Windows system, go to the directory where the driver is located. Run the application with administrative privileges. BM-0982 SERIES USER MANUAL Page: 4-9...

  • Page 55: Bios Setup

    The BIOS Setup Utilities consist of the following menu items: • Accessing Setup Utilities • Main Menu • Advanced Menu • Chipset Menu • Boot Menu • Security Menu • Save & Exit Menu BM-0982 SERIES USER MANUAL Page: 5-1...

  • Page 56: Introduction

    Chapter 5 BIOS Setup Introduction The BM-0982 System uses an AMI (American Megatrends Incorporated) Aptio BIOS that is stored in the Serial Peripheral Interface Flash Memory (SPI Flash) and can be updated. The SPI Flash contains the built-in BIOS setup program, Power-On Self-Test (POST), PCI auto-configuration utility, LAN EEPROM information, and Plug and Play support.

  • Page 57: Accessing Setup Utility

    Press <DEL> or <ESC> to enter setup. Figure 5-2. POST Screen with AMI Logo Press <Del> or <Esc> to access the Setup Utility program and the Main menu of the Aptio Setup Utility will appear on the screen as below: BM-0982 SERIES USER MANUAL Page: 5-3...
  • Page 58 Load the previous configuration values. <F3> Load the default configuration values. <F4> Save the current values and exit the BIOS setup menu. <Esc> Close the sub-menu. Trigger the confirmation to exit BIOS setup menu. BM-0982 SERIES USER MANUAL Page: 5-4...

  • Page 59: Main

    No changeable options Time version is built. Access Level No changeable options Displays the current user access level. TXE FW No changeable options Displays the TXE FW version. No changeable options Displays the GOP version. BM-0982 SERIES USER MANUAL Page: 5-5...
  • Page 60 The “Day” is automatically changed. Sets the system time. The format is [Hour: Minute: Second]. Users can directly enter System Time Hour, minute, second values or use <+> or <-> arrow keys to increase/decrease it. BM-0982 SERIES USER MANUAL Page: 5-6...

  • Page 61: Advanced

    S5 RTC Wake Settings Sub-Menu RTC wake parameters. CPU Configuration Sub-Menu CPU configuration parameters. F81966 Super IO Sub-Menu System Super IO chip parameters Configuration Network Stack Sub-Menu Network Stack parameters. Configuration USB Configuration Sub-Menu USB configuration parameters. BM-0982 SERIES USER MANUAL Page: 5-7...

  • Page 62: Advanced - Trusted Computing

    - Disabled security device. O.S. will not show Security Support - Enabled Device. TCG EFI protocol and INT1A interface will not be available. No Security Device - No changeable options Display the Security Device Found BM-0982 SERIES USER MANUAL Page: 5-8...

  • Page 63: Advanced - Acpi Settings

    Hibernate (OS/S4 Sleep State). This option (S4) - Enabled (default) may be not effective with some OS. - Disabled Enables or Disables System ability to Sleep Enable Sleep (S3) - Enabled (default) (OS/S3 Sleep State). BM-0982 SERIES USER MANUAL Page: 5-9...

  • Page 64: Advanced - Onboard Device Configuration

    Onboard Device Configuration Screen BIOS Setting Options Description/Purpose - RS-422 COM1 Mode Selection - RS-232 (default) Selects COM1 mode. - RS-485 - RS-422 COM2 Mode Selection - RS-232 (default) Selects COM2 mode. - RS-485 BM-0982 SERIES USER MANUAL Page: 5-10...

  • Page 65: Advanced - Hardware Monitor

    Detects and displays the voltage level VCC5V No changeable options of VCC5V in supply. Detects and displays the voltage level VSB5V No changeable options of VSB5V in supply. Detects and displays the battery VBAT No changeable options voltage. BM-0982 SERIES USER MANUAL Page: 5-11...

  • Page 66: Advanced - F81966 Watchdog

    BIOS Setting Options Description/Purpose - Disabled Enables/Disables 81966 Watchdog Enable Watchdog - Enabled (default) timer settings. Sets the timeout for Watchdog timer. Watchdog Timer Count (Numeric) 10 to 255 Watchdog Timer = 1sec * Count BM-0982 SERIES USER MANUAL Page: 5-12...

  • Page 67: Advanced - S5 Rtc Wake Settings

    • Fixed Time: The system will wake - Disabled (default) Wake system from S5 - Fixed Time on the time (hr::min::sec) specified. • Dynamic Time: The system will - Dynamic Time wake on the current time + increased minute(s). BM-0982 SERIES USER MANUAL Page: 5-13...

  • Page 68: S5 Rtc Wake Settings [Fixed Time]

    (Numeric) from 0 to 23 power-on event. Sets a minute for a scheduled Wake up minute (Numeric)from 0 to 59 power-on event. Sets a second for a scheduled Wake up second (Numeric)from 0 to 59 power-on event. BM-0982 SERIES USER MANUAL Page: 5-14...

  • Page 69: S5 Rtc Wake Settings [Dynamic Time]

    S5 RTC Wake Setting Screen (Dynamic Time) BIOS Setting Options Description/Purpose Sets a period of time (in minutes) Wake up minute increase (Numeric) from 1 to 5 after which the board wakes up from S5 state. BM-0982 SERIES USER MANUAL Page: 5-15...

  • Page 70: Advanced - Cpu Configuration

    CPU power management options. When enabled, a VMM can utilize Intel Virtualization - Disabled the additional hardware capabilities Technology - Enabled (default) provided by Vanderpool Technology (VT). - Disabled (default) VT-d Enables/Disables CPU VT-d. - Enabled BM-0982 SERIES USER MANUAL Page: 5-16...

  • Page 71: Cpu Configuration Socket - 0 Cpu Information

    L1 Data Cache No changeable options L1 Data Cache Size. L1 Code Cache No changeable options L1 Code Cache Size. L2 Cache No changeable options L2 Cache Size. L3 Cache No changeable options L3 Cache Size. BM-0982 SERIES USER MANUAL Page: 5-17...

  • Page 72: Cpu Configuration - Cpu Power Management

    Advanced > CPU Configuration > CPU Power Management Configuration CPU Power Management Configuration Screen BIOS Setting Options Description/Purpose Enables/Disables Intel Speed Step - Disabled EIST feature for dynamic scaling - Enabled (default) processor frequency. BM-0982 SERIES USER MANUAL Page: 5-18...
  • Page 73 Set Parameters of Serial Port 4 Serial Port 4 Configuration Sub-Menu (COMB) Set Parameters of Serial Port 5 Serial Port 5 Configuration Sub-Menu (COMA) Set Parameters of Serial Port 6 Serial Port 6 Configuration Sub-Menu (COMB) BM-0982 SERIES USER MANUAL Page: 5-19...

  • Page 74: F81966 Super Io Configuration - Serial Port

    - IO=3F8h; IRQ=4; Allows users to change Device's - IO=3F8h; IRQ=3,4,5,7,9,10,11,12; Resource settings. New settings Change Settings - IO=2F8h; IRQ=3,4,5,7,9,10,11,12; will be reflected on this Setup - IO=3E8h; IRQ=3,4,5,7,9,10,11,12; Page after System restarts. - IO=2E8h; IRQ=3,4,5,7,9,10,11,12; BM-0982 SERIES USER MANUAL Page: 5-20...

  • Page 75: Configuration

    - IO=3F8h; IRQ=4; Allows users to change Device's - IO=3F8h; IRQ=3,4,5,7,9,10,11,12; Resource settings. New settings Change Settings - IO=2F8h; IRQ=3,4,5,7,9,10,11,12; will be reflected on this Setup - IO=3E8h; IRQ=3,4,5,7,9,10,11,12; Page after System restarts. - IO=2E8h; IRQ=3,4,5,7,9,10,11,12; BM-0982 SERIES USER MANUAL Page: 5-21...
  • Page 76 - IO=3F8h; IRQ=4; Allows users to change Device's - IO=3F8h; IRQ=3,4,5,7,9,10,11,12; Resource settings. New settings Change Settings - IO=2F8h; IRQ=3,4,5,7,9,10,11,12; will be reflected on this Setup Page - IO=3E8h; IRQ=3,4,5,7,9,10,11,12; after System restarts. - IO=2E8h; IRQ=3,4,5,7,9,10,11,12; BM-0982 SERIES USER MANUAL Page: 5-22...
  • Page 77 - IO=3F8h; IRQ=4; Allows users to change Device's - IO=3F8h; IRQ=3,4,5,7,9,10,11,12; Resource settings. New settings Change Settings - IO=2F8h; IRQ=3,4,5,7,9,10,11,12; will be reflected on this Setup - IO=3E8h; IRQ=3,4,5,7,9,10,11,12; Page after System restarts. - IO=2E8h; IRQ=3,4,5,7,9,10,11,12; BM-0982 SERIES USER MANUAL Page: 5-23...
  • Page 78 - IO=3F8h; IRQ=4; Allows users to change Device's - IO=3F8h; IRQ=3,4,5,7,9,10,11,12; Resource settings. New settings Change Settings - IO=2F8h; IRQ=3,4,5,7,9,10,11,12; will be reflected on this Setup - IO=3E8h; IRQ=3,4,5,7,9,10,11,12; Page after System restarts. - IO=2E8h; IRQ=3,4,5,7,9,10,11,12; BM-0982 SERIES USER MANUAL Page: 5-24...
  • Page 79 - IO=3F8h; IRQ=4; Allows users to change Device's - IO=3F8h; IRQ=3,4,5,7,9,10,11,12; Resource settings. New settings Change Settings - IO=2F8h; IRQ=3,4,5,7,9,10,11,12; will be reflected on this Setup - IO=3E8h; IRQ=3,4,5,7,9,10,11,12; Page after System restarts. - IO=2E8h; IRQ=3,4,5,7,9,10,11,12; BM-0982 SERIES USER MANUAL Page: 5-25...

  • Page 80: Advanced - Network Stack Configuration

    Wait time to press ESC key to abort the PXE boot wait time Numeric (from 0 to 5) PXE boot. Numbers of times presence of media Media detect count Numeric (from 1 to 50) will be checked. BM-0982 SERIES USER MANUAL Page: 5-26...

  • Page 81: Advanced - Usb Configuration

    - Floppy Mass Storage Optical drives are emulated as - Forced FDD Devices: [drive(s)] 'CD-ROM'. Drives with no media - Hard Disk will be emulated according to a - CD-ROM drive type. BM-0982 SERIES USER MANUAL Page: 5-27...

  • Page 82: Chipset

    This menu allows users to configure advanced Chipset settings such as North Bridge, South Bridge and Display configuration parameters. Chipset Screen BIOS Setting Options Description/Purpose North Bridge Sub-menu North Bridge Parameters. South Bridge Sub-menu South Bridge Parameters. Display Configuration Sub-menu Display Parameters BM-0982 SERIES USER MANUAL Page: 5-28...

  • Page 83: Chipset - North Bridge

    Displays the current amount and Memory Slot0 No changeable options type of memory on each memory slot Displays the current amount and Memory Slot1 No changeable options type of memory on each memory slot, e.g. "8192 MB (DDR3)". BM-0982 SERIES USER MANUAL Page: 5-29...

  • Page 84: Chipset - South Bridge

    Description/Purpose HD-Audio Configuration Sub-Menu HD-Audio configuration settings. LPSS Configuration Sub-Menu LPSS configuration settings. PCI Express Configuration Sub-Menu PCI Express configuration settings. SATA Drives Sub-Menu SATA Drives configuration settings. Miscellaneous configuration Miscellaneous Configuration Sub-Menu settings BM-0982 SERIES USER MANUAL Page: 5-30...

  • Page 85: South Bridge - Hd-Audio Configuration

    5.5.2.1 South Bridge - HD-Audio Configuration Menu Path Chipset > South Bridge > HD-Audio Configuration HD-Audio Configuration Screen BIOS Setting Options Description/Purpose - Disabled Enables / Disables HD-Audio HD-Audio Support - Enabled (default) support. BM-0982 SERIES USER MANUAL Page: 5-31...

  • Page 86: South Bridge - Lpss Configuration

    Enables/Disables LPSS I2C #1 (D22:F0) - Enable (default) support. - Fast Mode (default) - Standard Mode Set LPSS I2C #1 Speed Selects LPSS I2C #1 speed. - Fast Plus Mode - High Speed Mode BM-0982 SERIES USER MANUAL Page: 5-32...

  • Page 87: South Bridge - Pci Express Configuration

    PCI Express Root Port 1 Sub-Menu PCIE RP1 parameters (I210 LAN). (I210 LAN) PCI Express Root Port 2 Sub-Menu PCIE RP2 parameters (I210 LAN). (I210 LAN) PCI Express Root Port 3 Sub-Menu PCIE RP3 parameters (Mini PCIe). (Mini-PCIe) BM-0982 SERIES USER MANUAL Page: 5-33...
  • Page 88 - Enabled (PCIEx 1) power savings. - Auto Enable: Enable PCIe root port. Disable: Disable PCIe root port. - Auto PCIe Speed - Gen1 Configure PCIe Speed. - Gen2 BM-0982 SERIES USER MANUAL Page: 5-34...
  • Page 89 - Enable (default) (I210 LAN) power savings. - Auto Enable: Enable PCIe root port. Disable: Disable PCIe root port. - Auto (default) PCIe Speed - Gen1 Configure PCIe Speed. - Gen2 BM-0982 SERIES USER MANUAL Page: 5-35...
  • Page 90 - Enable (I210 LAN) power savings. - Auto (default) Enable: Enable PCIe root port. Disable: Disable PCIe root port. - Auto (default) PCIe Speed - Gen1 Configure PCIe Speed. - Gen2 BM-0982 SERIES USER MANUAL Page: 5-36...
  • Page 91 - Enable (Mini-PCIe) power savings. - Auto (default) Enable: Enable PCIe root port. Disable: Disable PCIe root port. - Auto (default) PCIe Speed - Gen1 Configures PCIe speed. - Gen2 BM-0982 SERIES USER MANUAL Page: 5-37...

  • Page 92: South Bridge - Sata Drives

    Enables/Disables SATA port 0. - Enabled (default) Displays SATA drive branding SATA Port 1 No changeable options information if device exists on port 1. - Disabled Port 1 Enables/Disables SATA port 1. - Enabled (default) BM-0982 SERIES USER MANUAL Page: 5-38...

  • Page 93: South Bridge - Miscellaneous Configuration

    Win 8/8.1/10 don't support WOL from - Disable Wake On Lan hybrid shutdown state (S4). If you - Enable (default) want to support WOL from classic shutdown state (S5), please turn off 'fast startup' feature in OS. BM-0982 SERIES USER MANUAL Page: 5-39...

  • Page 94: Chipset - Display Configuration

    BIOS Setting Options Description/Purpose - DP+HDMI (default) VBT Select Select VBT for GOP Driver. - Only HDMI 4K - Disable(default) LVDS1 Enable/Disable LVDS1 Display - Enable - Disable(default) LVDS2 Enable/Disable LVDS2 Display - Enable BM-0982 SERIES USER MANUAL Page: 5-40...

  • Page 95: Security

    Setup utility. Security Screen BIOS Setting Options Description/Purpose Setup Administrator Password can be 3-20 Specifies the administrator Password alphanumeric characters. password. Password can be 3-20 User Password Specifies the user password. alphanumeric characters. BM-0982 SERIES USER MANUAL Page: 5-41...
  • Page 96 <Enter>, and the password dialog entry boxappears. Select the configured Administrator Password or User Password that youwant to delete. Leave the dialog box blank and press <Enter>. Press <Enter> again when the password confirmation box appears. BM-0982 SERIES USER MANUAL Page: 5-42...

  • Page 97: Boot

    • Off: Disables the NumLock function after the system is powered on. - Disabled (default) When quite boot is enabled, it Quiet Boot - Enabled displays AMI or OEM logo (if BM-0982 SERIES USER MANUAL Page: 5-43...
  • Page 98 Chapter 5 BIOS Setup BIOS Setting Options Description/Purpose implemented) instead of POST messages during the boot. - [Drive(s)] Boot Option #1~#n Sets the system boot order. - Disabled BM-0982 SERIES USER MANUAL Page: 5-44...

  • Page 99: Save & Exit

    Discard Changes and Reset to discard any changes you have made and restore the factory BIOS defaults. Load User Defaults You may simply press F3 at any time to load the Optimized Values which resets all BIOS settings to the factory defaults. Save & Exit Screen BM-0982 SERIES USER MANUAL Page: 5-45...
  • Page 100 No changeable options Defaults. Restore the User Defaults to all the Restore User Defaults No changeable options setup options. Forces to boot from selected Boot Override - [Drive(s)] [drive(s)]. AMIFWUpdate No changeable options Launches AMIFWUpdate BM-0982 SERIES USER MANUAL Page: 5-46...

  • Page 101: Appendix A Technical Summary

    Appendix A Technical Summary This appendix will give you a brief introduction of the allocation maps for BM-0982 resources. The following topics are included: • BM-0982 Block Diagram • Interrupt Map • I/O Map • Memory Map • Configuring WatchDog Timer •...

  • Page 102: Bm-0982 Block Diagram

    RS-232 COM 3 / 4 / 5 / 6 RS232 F81966D USB2.0 USB 2.0 x2 LOW PIN COUNT (Super IO) TPM/80 Port SATA SATA3.0 BOARD ID FOR BIOS VERSION DETECT SATA or M.2 SATA3.0 Page: A-2 BM-0982 SERIES USER MANUAL...

  • Page 103: Interrupt Map

    IRQ 67 Microsoft ACPI-Compliant System IRQ 68 Microsoft ACPI-Compliant System IRQ 69 Microsoft ACPI-Compliant System IRQ 70 Microsoft ACPI-Compliant System IRQ 71 Microsoft ACPI-Compliant System IRQ 72 Microsoft ACPI-Compliant System IRQ 73 Microsoft ACPI-Compliant System Page: A-3 BM-0982 SERIES USER MANUAL...
  • Page 104 IRQ 100 Microsoft ACPI-Compliant System IRQ 101 Microsoft ACPI-Compliant System IRQ 102 Microsoft ACPI-Compliant System IRQ 103 Microsoft ACPI-Compliant System IRQ 104 Microsoft ACPI-Compliant System IRQ 105 Microsoft ACPI-Compliant System IRQ 106 Microsoft ACPI-Compliant System Page: A-4 BM-0982 SERIES USER MANUAL...
  • Page 105 IRQ 133 Microsoft ACPI-Compliant System IRQ 134 Microsoft ACPI-Compliant System IRQ 135 Microsoft ACPI-Compliant System IRQ 136 Microsoft ACPI-Compliant System IRQ 137 Microsoft ACPI-Compliant System IRQ 138 Microsoft ACPI-Compliant System IRQ 139 Microsoft ACPI-Compliant System Page: A-5 BM-0982 SERIES USER MANUAL...
  • Page 106 IRQ 166 Microsoft ACPI-Compliant System IRQ 167 Microsoft ACPI-Compliant System IRQ 168 Microsoft ACPI-Compliant System IRQ 169 Microsoft ACPI-Compliant System IRQ 170 Microsoft ACPI-Compliant System IRQ 171 Microsoft ACPI-Compliant System IRQ 172 Microsoft ACPI-Compliant System Page: A-6 BM-0982 SERIES USER MANUAL...
  • Page 107 IRQ 199 Microsoft ACPI-Compliant System IRQ 200 Microsoft ACPI-Compliant System IRQ 201 Microsoft ACPI-Compliant System IRQ 202 Microsoft ACPI-Compliant System IRQ 203 Microsoft ACPI-Compliant System IRQ 204 Microsoft ACPI-Compliant System IRQ 256 Microsoft ACPI-Compliant System Page: A-7 BM-0982 SERIES USER MANUAL...
  • Page 108 IRQ 283 Microsoft ACPI-Compliant System IRQ 284 Microsoft ACPI-Compliant System IRQ 285 Microsoft ACPI-Compliant System IRQ 286 Microsoft ACPI-Compliant System IRQ 287 Microsoft ACPI-Compliant System IRQ 288 Microsoft ACPI-Compliant System IRQ 289 Microsoft ACPI-Compliant System Page: A-8 BM-0982 SERIES USER MANUAL...
  • Page 109 IRQ 316 Microsoft ACPI-Compliant System IRQ 317 Microsoft ACPI-Compliant System IRQ 318 Microsoft ACPI-Compliant System IRQ 319 Microsoft ACPI-Compliant System IRQ 320 Microsoft ACPI-Compliant System IRQ 321 Microsoft ACPI-Compliant System IRQ 322 Microsoft ACPI-Compliant System Page: A-9 BM-0982 SERIES USER MANUAL...
  • Page 110 IRQ 349 Microsoft ACPI-Compliant System IRQ 350 Microsoft ACPI-Compliant System IRQ 351 Microsoft ACPI-Compliant System IRQ 352 Microsoft ACPI-Compliant System IRQ 353 Microsoft ACPI-Compliant System IRQ 354 Microsoft ACPI-Compliant System IRQ 355 Microsoft ACPI-Compliant System Page: A-10 BM-0982 SERIES USER MANUAL...
  • Page 111 IRQ 382 Microsoft ACPI-Compliant System IRQ 383 Microsoft ACPI-Compliant System IRQ 384 Microsoft ACPI-Compliant System IRQ 385 Microsoft ACPI-Compliant System IRQ 386 Microsoft ACPI-Compliant System IRQ 387 Microsoft ACPI-Compliant System IRQ 388 Microsoft ACPI-Compliant System Page: A-11 BM-0982 SERIES USER MANUAL...
  • Page 112 IRQ 415 Microsoft ACPI-Compliant System IRQ 416 Microsoft ACPI-Compliant System IRQ 417 Microsoft ACPI-Compliant System IRQ 418 Microsoft ACPI-Compliant System IRQ 419 Microsoft ACPI-Compliant System IRQ 420 Microsoft ACPI-Compliant System IRQ 421 Microsoft ACPI-Compliant System Page: A-12 BM-0982 SERIES USER MANUAL...
  • Page 113 IRQ 448 Microsoft ACPI-Compliant System IRQ 449 Microsoft ACPI-Compliant System IRQ 450 Microsoft ACPI-Compliant System IRQ 451 Microsoft ACPI-Compliant System IRQ 452 Microsoft ACPI-Compliant System IRQ 453 Microsoft ACPI-Compliant System IRQ 454 Microsoft ACPI-Compliant System Page: A-13 BM-0982 SERIES USER MANUAL...
  • Page 114 IRQ 481 Microsoft ACPI-Compliant System IRQ 482 Microsoft ACPI-Compliant System IRQ 483 Microsoft ACPI-Compliant System IRQ 484 Microsoft ACPI-Compliant System IRQ 485 Microsoft ACPI-Compliant System IRQ 486 Microsoft ACPI-Compliant System IRQ 487 Microsoft ACPI-Compliant System Page: A-14 BM-0982 SERIES USER MANUAL...
  • Page 115 Intel(R) I210 Gigabit Network Connection #2 IRQ 4294967281 Intel(R) I210 Gigabit Network Connection #2 IRQ 4294967282 Intel(R) I210 Gigabit Network Connection #2 IRQ 4294967283 Intel(R) I210 Gigabit Network Connection #2 IRQ 4294967284 Intel(R) I210 Gigabit Network Connection Page: A-15 BM-0982 SERIES USER MANUAL...
  • Page 116 IRQ 4294967293 Root Port - 5AD9 Intel(R) Celeron(R)/Pentium(R) Processor PCI Express IRQ 4294967294 Root Port - 5AD8 Note: These resource information were gathered using Windows 10 (the IRQ could be assigned differently depending on OS). Page: A-16 BM-0982 SERIES USER MANUAL...

  • Page 117: I/O Map

    Communications Port (COM3) 0x000002E8-0x000002EF Communications Port (COM4) 0x0000F000-0x0000F03F Intel(R) HD Graphics Intel(R) Celeron(R)/Pentium(R) Processor 0x0000E000-0x0000EFFF PCI Express Root Port - 5AD8 0x00000000-0x0000006F PCI Express Root Complex 0x00000078-0x00000CF7 PCI Express Root Complex 0x00000D00-0x0000FFFF PCI Express Root Complex Page: A-17 BM-0982 SERIES USER MANUAL...
  • Page 118 Programmable interrupt controller 0x000000B8-0x000000B9 Programmable interrupt controller 0x000000BC-0x000000BD Programmable interrupt controller 0x000004D0-0x000004D1 Programmable interrupt controller 0x0000F090-0x0000F097 Standard SATA AHCI Controller 0x0000F080-0x0000F083 Standard SATA AHCI Controller 0x0000F060-0x0000F07F Standard SATA AHCI Controller 0x00000040-0x00000043 System timer 0x00000050-0x00000053 System timer Page: A-18 BM-0982 SERIES USER MANUAL...

  • Page 119: Memory Map

    High precision event timer Intel(R) USB 3.0 eXtensible Host 0x91300000-0x9130FFFF Controller - 1.0 (Microsoft) 0x90000000-0x90FFFFFF Intel(R) HD Graphics 0x80000000-0x8FFFFFFF Intel(R) HD Graphics 0x80000000-0x8FFFFFFF PCI Express Root Complex Intel(R) Celeron(R)/Pentium(R) Processor 0x91200000-0x912FFFFF PCI Express Root Port - 5AD8 Page: A-19 BM-0982 SERIES USER MANUAL...
  • Page 120 0xCFFFE000-0xCFFFEFFF Intel SD Host Controller 0x91314000-0x91315FFF Standard SATA AHCI Controller 0x9131E000-0x9131E0FF Standard SATA AHCI Controller 0x9131D000-0x9131D7FF Standard SATA AHCI Controller Intel(R) I210 Gigabit Network 0x91280000-0x912FFFFF Connection #2 Intel(R) I210 Gigabit Network 0x9127C000-0x9127FFFF Connection #2 Page: A-20 BM-0982 SERIES USER MANUAL...

  • Page 121: Configuring Watchdog Timer

    To exit the Extended Function Mode, writing 0xAA to the EFER is required. Once the chip exits the Extended Function Mode, it is in the normal running mode and is ready to enter the configuration mode. Page: A-21 BM-0982 SERIES USER MANUAL...
  • Page 122 ;---------------------------------Enable Watch dog feature ------------------------------ 030h dx, al dx, al ;------------------------------- Enable Watch PME-------------------------------------------- 0FAh dx, al dx, al ; ------------------------ Set timeout interval to 30 ------------------------------------------ 0F6h dx, al Page: A-22 BM-0982 SERIES USER MANUAL...
  • Page 123 Appendix A Technical Summary dx, al ;-------------------Set second as counting unit and start counting --------------------- 0F5h dx, al dx, al ;---------------------------------Exit the extended function mode ------------------------- 0AAh dx, al Page: A-23 BM-0982 SERIES USER MANUAL...

  • Page 124: Flash Bios Update

    (3) Select [Boot] menu and set [UEFI: Built-in EFI Shell] and set the USB bootable device as the 1st boot device. (4) Press F4 to save the configuration and exit the BIOS setup menu. Page: A-24 BM-0982 SERIES USER MANUAL...
  • Page 125 BIOS ROM may be crashed and the system will be unable to boot up next time. After the BIOS update procedure is completed, the following messages will be shown: Page: A-25 BM-0982 SERIES USER MANUAL...
  • Page 126 Restart the system and boot up with the new BIOS configurations. The BIO Update is completed after the system is restarted. Reboot the system and verify if the BIOS version shown on the initialization screen has been updated. Page: A-26 BM-0982 SERIES USER MANUAL...

Table of Contents
