protech BE-0961 User Manual

3.5” sbc with intel® celeron® / atomtm soc on top side (baytrail-m/i) / dual lan
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
USER
MANUAL
BE-0961 M5
BE-0961
3.5" SBC with Intel
Atom
SoC on Top Side
TM
(Baytrail-M/I) / Dual LAN
Celeron
/
®
®

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BE-0961 and is the answer not in the manual?

Questions and answers

Related Manuals for protech BE-0961

Summary of Contents for protech BE-0961

  • Page 1 USER MANUAL BE-0961 3.5” SBC with Intel Celeron ® ® Atom SoC on Top Side (Baytrail-M/I) / Dual LAN BE-0961 M5...
  • Page 2 BE-0961 3.5” Single Board Computer COPYRIGHT NOTICE & TRADEMARK All trademarks and registered trademarks mentioned herein are the property of their respective owners. This manual is copyrighted in Mar 2023. You may not reproduce or transmit in any form or by any means, electronic, or mechanical, including photocopying and recording.
  • Page 3 FCC NOTICE This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.

  • Page 4: Table Of Contents

    Hardware Configuration ..............3-1 JUMPER & CONNECTOR QUICK REFERENCE TABLE ..3-2 COMPONENT LOCATIONS OF SYSTEM MAIN BOARD ..3-3 3.2.1 Top View of BE-0961 ............3-3 3.2.2 Bottom View of BE-0961 ........... 3-5 HOW TO SET JUMPERS ............3-6 Setting Connectors and Jumpers ..........
  • Page 5 3.4.11 POWER CONNECTOR (PWR_CN1) ......3-17 3.4.12 SATA & SATA POWER CONNECTOR (SATA1, SATA_PWR1) ..................3-17 3.4.13 DIGITAL I/O CONNECTOR (DIO1) ......... 3-18 3.4.14 AUDIO CONNECTOR (JAUDIO1) ........3-18 3.4.15 FAN CONNECTOR (FAN1) ..........3-18 3.4.16 BACKLIGHT CONNECTOR (INV1)......... 3-19 3.4.17 BATTERY CONNECTOR (BAT1) ........
  • Page 6 Introduction ................5-2 Accessing Setup Utility .............. 5-3 Main ................... 5-7 Advanced .................. 5-9 5.4.1 Advanced – ACPI Settings ..........5-10 5.4.2 Advanced – F81866 Super IO Configuration ....5-11 5.4.3 F81866 Super IO Configuration – Serial Port 1 Configuration ..................
  • Page 7 Appendix A EXPANSION BUS ............. A-1 CFAST SLOT PIN ASSIGNMENT ............A-2 Appendix B Technical Summary ..........B-1 Block Diagram ..................B-2 I/O Map .....................B-3 Interrupt Map ....................B-7 Memory Map ...................B-15 Watchdog Timer Configuration ...............B-17 Flash BIOS Update .................B-20...

  • Page 8: Introduction

    Introduction This chapter provides the introduction for the BE-0961 system as well as the framework of the user manual. The following topics are included: • About This Manual BE-0961 SERIES USER MANUAL Page: 1-1...

  • Page 9: About This Manual

    Chapter 1 Introduction 1.1 About This Manual Thank you for purchasing our BE-0961 with Intel® 4th Gen. Atom E3000/N2000 SBC enhanced with VGA/Audio/2LAN/4COM, which is fully PC/AT compatible. The BE-0961 provides faster processing speed, greater expandability and can handle more tasks than before. This manual is designed to assist you how to install and set up the system.

  • Page 10: Getting Started

    Getting Started This chapter provides the information for the BE-0961 system. It describes the package contents and outlines the system specifications. The following topics are included: • Package List • System Specification • Safety Precautions Experienced users can go to Chapter 3 System Configuration on page 3-1 for a quick start.

  • Page 11: Packing List

    If you discover any of the items listed above are damaged or lost, please contact your local distributor immediately. Item Q’ty BE-0961 Quick Reference Guide Manual / Driver DVD Mini Jumper (2.0 mm) SATA & SATA Power Y-type Cable (150mm) DC In Power Cable (200mm) BE-0961 SERIES USER MANUAL Page: 2-2...

  • Page 12: Be-0961 Specifications

     PWM’s duty cycle can be controlled by Windows built-in  BLEN pin is obtained directly by CH7511  Dual LAN (2xRJ45 on Rear I/O)  Supports Wake-On-LAN  Controller : 2 x Intel I210-IT (MAC+PHY, PCIe interface ) BE-0961 SERIES USER MANUAL Page: 2-3...
  • Page 13  2x5 Pin header: HDD LED / PWR LED / RST BTN / PWR Front Panel Buzzer  N/A Other Function  1 x 3-pin CPU FAN connector  Supports only DC 12V power input (1x 4 pin power Power Supply connector) BE-0961 SERIES USER MANUAL Page: 2-4...
  • Page 14  Dual LAN (2xRJ45 on Rear I/O)  Supports Wake-On-LAN  Controller : 2 x Intel I210-IT (MAC+PHY, PCIe interface )  Line-in / Line-out / MIC-in (onboard pin header) Sound  Codec IC: Realtek ALC888 (High Definition Codec) BE-0961 SERIES USER MANUAL Page: 2-5...
  • Page 15  Way to Boot-Up from S5: (1)Power Button (2)Wake-On-LAN  Way to shut down to S5/S4/S3: (1) Power button (2) OS command  Supports S0/S3/S4/S5 Battery  2-pin wafer, connected with a cable type BAT BE-0961 SERIES USER MANUAL Page: 2-6...

  • Page 16: Safety Precautions

    Always disconnect power when the system is not in use. Disconnect power source when you change any hardware devices. For instance, when you connect a jumper or install any cards, a surge of power may damage the electronic components or the whole system. BE-0961 SERIES USER MANUAL Page: 2-7...

  • Page 17: Hardware Configuration

    This chapter contains helpful information about the jumper & connector settings and component locations. The following sections are included: • Jumper & Connector Quick Reference Table • Main Board Component Locations • Configuration and Jumper Settings • Connector Pin Assignments BE-0961 SERIES USER MANUAL Page: 3-1...

  • Page 18: Jumper & Connector Quick Reference Table

    JP17 Power Connector PWR_CN1 SATA Connector SATA1 SATA Power Connector SATA_PWR1 Digital I/O Connector DIO1 Audio Connector JAUDIO1 System Fan Connector FAN1 Backlight Connector INV1 Battery Connector BAT1 CFAST Voltage Selection LVDS Connector LVDS1 BE-0961 SERIES USER MANUAL Page: 3-2...

  • Page 19: Component Locations Of System Main Board

    Make sure both the system and peripheral devices are turned OFF as sudden surge of power could damage sensitive components. Make sure BE-0961 is properly grounded. CAUTION: Observe precautions while handling electrostatic sensitive components. Make sure to ground yourself to prevent static charge while you are working on the connectors and jumpers.
  • Page 20 CAUTION: Always touch the motherboard components by the edges. Never touch components such as a processor by its pins. Take special cares while you are holding electronic circuit boards by the edges only. Do not touch the main board components. BE-0961 SERIES USER MANUAL Page: 3-4...

  • Page 21: Bottom View Of Be-0961

    Chapter 3 Hardware Configuration 3.2.2 Bottom View of BE-0961 JCFAST2 S7 PC1 PC17 SLOT1 DIMM1 BE-0961 SERIES USER MANUAL Page: 3-5...

  • Page 22: How To Set Jumpers

    PIN1 & PIN2 to create one setting by shorting. You can either connect PIN2 & PIN3 to create another setting. The same jumper diagrams are applied all through this manual. The figure below shows what the manual diagrams look and what they represent. BE-0961 SERIES USER MANUAL Page: 3-6...
  • Page 23 Jumper Block looks like this Jumper Settings 2 pin Jumper close(enabled) Looks like this 3 pin Jumper 2-3 pin close(enabled) Looks like this Jumper Block 1-2 pin close(enabled) Looks like this BE-0961 SERIES USER MANUAL Page: 3-7...

  • Page 24: Setting Connectors And Jumpers

    The pin assignments are as follows: COM1: ASSIGNMENT ASSIGNMENT COM1 COM2(RS-232) Connector Pin Assignment: ASSIGNMENT ASSIGNMENT COM2_DCD COM2_DSR COM2_RX COM2_RTS COM2_TX COM2_CTS COM2 COM2_DTR COM2_RI COM2(RS-422) Connector Pin Assignment: ASSIGNMENT ASSIGNMENT COM2(RS485) Connector Pin Assignment: ASSIGNMENT ASSIGNMENT BE-0961 SERIES USER MANUAL Page: 3-8...
  • Page 25 Chapter 3 Hardware Configuration COM3, COM4: ASSIGNMENT ASSIGNMENT COM3/ COM4/ BE-0961 SERIES USER MANUAL Page: 3-9...

  • Page 26: Com2 Rs-232/422/485 Selection (Jp_Com2)

    3.4.2 COM2 RS-232/422/485 SELECTION (JP_COM2) Jumper Location: JP_COM2 Description: COM2 RS-232/422/485 Selection connector, used to set COM2 function. SELECTION JUMPER SETTINGS JUMPER ILLUSTRATION RS-232 (Default Setting) JP_COM2 1-2, RS-422 3-4, JP_COM2 RS-485 Open JP_COM2 BE-0961 SERIES USER MANUAL Page: 3-10...

  • Page 27: Com3 & Com4 Ri & Voltage Selection

    Jumper Location: JP_COM3, JP_COM4 Description: COM3 & COM4 RI & Voltage Selection connectors, used to set COM3 & COM4 function. JUMPER ILLUSTRATION JUMPER SELECTION SETTINGS COM3 COM4 (Default Setting) JP_COM3 JP_COM4 JP_COM3 JP_COM4 JP_COM3 JP_COM4 BE-0961 SERIES USER MANUAL Page: 3-11...

  • Page 28: Usb Port & Connector (Usb10, Jusb1)

    Description: USB Ports The pin assignments are as follows: USB3.0 signal: ASSIGNMENT ASSIGNMENT VCC5 RX1_DP USBP1N USBP1P TX1_DN TX1_DP RX1_DN USB2.0 signal: USB10 ASSIGNMENT VCC5 USBP2N USBP2P Connector Location: JUSB1 Description: USB Connector ASSIGNMENT VCC5 JUSB1 BE-0961 SERIES USER MANUAL Page: 3-12...

  • Page 29: Lan Port (Lan1, Lan2)

    100 LAN Speed Indicator Orange Color ON Giga LAN Speed Indicator 10 LAN Speed Indicator Right Side LED Yellow Color Blinking LAN Message Active Yellow Color ON LAN Switch/Hub connected No LAN Switch/Hub connected BE-0961 SERIES USER MANUAL Page: 3-13...

  • Page 30: Vga Port (Vga1)

    *To clear CMOS data, user must power-off the computer and set the jumper to “Clear CMOS” as illustrated above. After five to six seconds, set the jumper back to “Normal” and power on the computer. BE-0961 SERIES USER MANUAL Page: 3-14...

  • Page 31: Auto Boot-Up After Ac Returns From Power-Loss (Jp16)

    Open Keep on S5 JP16 Note: Manufacturing Default is ATX. 3.4.9 LVDS VCC VOLTAGE SELECTION (JP14) Jumper Location: JP14 Description: LVDS VCC Voltage Selection SELECTION JUMPER SETTING JUMPER ILLUSTRATION 3.3V (Default Setting) JP14 JP14 BE-0961 SERIES USER MANUAL Page: 3-15...

  • Page 32: Front Panel Selection (Jp17)

    2. PWR_LED+ Power LED JP17 4. PWR_LED- 5. RSTSW- Reset Button JP17 7. RSTSW+ 6. SPEAKER+ 8. SPEAKER- External 6-8-10-12 Speaker JP17 10. SPEAKER- 12. SPEAKER- 9. PWRSW+ ATX Power 9-11 Button JP17 11. PWRSW- BE-0961 SERIES USER MANUAL Page: 3-16...

  • Page 33: Power Connector (Pwr_Cn1)

    VCC12 VCC12 PWR_CN1 3.4.12 SATA & SATA POWER CONNECTOR (SATA1, SATA_PWR1) Port Location: SATA1 Description: SATA Port ASSIGNMENT ASSIGNMENT RX_N_C TX_P_C RX_P_C TX_N_C SATA1 Port Location: SATA_PWR1 Description: SATA Power Connector ASSIGNMENT VCC5 SATA_PWR1 BE-0961 SERIES USER MANUAL Page: 3-17...

  • Page 34: Digital I/O Connector (Dio1)

    Description: Audio Connector, including Line In & Line Out ASSIGNMENT ASSIGNMENT MIC-IN L LINE-IN R MIC-IN R LINE-OUT L LINE-IN L LINE-OUT R JAUDIO1 3.4.15 FAN CONNECTOR (FAN1) Connector Location: FAN1 Description: System Fan Connector ASSIGNMENT VCC12 SENCE FAN1 BE-0961 SERIES USER MANUAL Page: 3-18...

  • Page 35: Backlight Connector (Inv1)

    Connector Location: BAT1 Description: Battery Connector ASSIGNMENT VCC3.3 BAT1 3.4.18 CFAST VOLTAGE SELECTION (JP7) Jumper Location: JP7 Description: CFAST Voltage Selection The selections are as follows: SELECTION JUMPER SETTING JUMPER ILLUSTRATION 3.3V (Default Setting) BE-0961 SERIES USER MANUAL Page: 3-19...

  • Page 36: Lvds Connector (Lvds1)

    LVDS CONNECTOR (LVDS1) Connector Location: LVDS1 Description: LVDS Connector ASSIGNMENT ASSIGNMENT LVDS_VCC LVDS_CLKAP LVDS_CLKAM LVDS_CLKBM LVDS_CLKBP LVDS_YAP2 LVDS_YAM2 LVDS1 LVDS_YBM2 LVDS_YBP2 LVDS_YAP1 LVDS_YAM1 LVDS_YBM1 LVDS_YBP1 LVDS_YAP0 LVDS_YBP3 LVDS_YAM0 LVDS_YBM3 LVDS_YAP3 LVDS_YBP0 LVDS_YAM3 LCDS_YBM0 LVDS_VCC LVDS_VCC BE-0961 SERIES USER MANUAL Page: 3-20...

  • Page 37: Software Utilities

    Installation Utility • Installing Intel ® Trusted Execution Engine Driver Installer • Installing USB 3.0 eXtensible Host Controller Utility • Installing Graphics Driver Utility • Installing LAN Driver Utility • Installing Sound Driver Utility BE-0961 SERIES USER MANUAL Page: 4-1...

  • Page 38: Introduction

    Chapter 4 Software Utilities 4.1 Introduction Enclosed with the BE-0961 Series package is our driver utilities contained in a DVD-ROM disk. Refer to the following table for driver locations: Filename (Assume that Purpose DVD- ROM drive is D :)  D:\Driver\Platform\Win7(32bit)\UTILITY ...

  • Page 39: Installing Intel ® Chipset Software Installation Utility

    Core PCI and ISAPNP Services  PCIe Support  IDE/ATA33/ATA66/ATA100 Storage Support  SATA Storage Support  USB Support  ® Identification of Intel Chipset Components in the Device Manager  BE-0961 SERIES USER MANUAL Page: 4-3...

  • Page 40: Installation Of Utility For Windows 8 / Windows 7

    OS installation. Please follow the steps below: Insert the driver disk into a CD ROM device. Under Windows system, go to the directory where the Utility driver is located. Run the application with the Administrator privilege. BE-0961 SERIES USER MANUAL Page: 4-4...

  • Page 41: Intel ® Usb3.0 Extensible Host Controller Installation Utility

    4.5 Installation Instructions for Windows 7 Insert the driver disk into a CD ROM device. Under Windows system, go to the directory where the driver is located. Run the application with the Administrator privilege. BE-0961 SERIES USER MANUAL Page: 4-5...

  • Page 42: Intel ® Trusted Execution Engine Installation Utility

    Installation Instructions for Windows 8 / Windows 7 Insert the driver disk into a CD ROM device. Under Windows system, go to the directory where the driver is located. Run the application with the Administrator privilege. BE-0961 SERIES USER MANUAL Page: 4-6...

  • Page 43: Installation Of Vga Driver Utility

    Chapter 4 Software Utilities 4.7 INSTALLATION OF VGA DRIVER UTILITY Introduction The VGA interface embedded with our BE-0961 can support a wide range of display. You can display CRT, LVDS simultaneously with the same mode. 1. Win 7 Series 2. Win 8 Series To install the VGA Driver, simply follow the following steps: Insert the driver disk into a CD ROM device.

  • Page 44: Lan Driver Utility

    Chapter 4 Software Utilities 4.8 LAN DRIVER UTILITY Introduction BE-0961 is enhanced with LAN function that can support various network adapters. Installation programs for LAN drivers are listed as follows: 1. Win 7 Series 2. Win 8 Series For more details on Installation procedure, please refer to Readme.txt file found on LAN Driver Utility.

  • Page 45: Sound Driver Utility

    4.9 SOUND DRIVER UTILITY Introduction The Realtek sound function enhanced in this system is fully compatible with Windows 7. Below, you will find the content of the Sound driver: 1. Win 7 Series 2. Win 8 Series BE-0961 SERIES USER MANUAL Page: 4-9...
  • Page 46 Run the application with administrative privileges. Follow the instructions on the screen to complete the installation. Once the installation is completed, shut down the system and restart in order for the changes to take effect. BE-0961 SERIES USER MANUAL Page: 4-10...

  • Page 47: Bios Setup

    The BIOS Setup Utilities consist of the following menu items: Accessing Setup Utilities • Main Menu • Advanced Menu • Chipset Menu • Security Menu • Boot Menu • Save & Exit Menu • BE-0961 SERIES USER MANUAL Page: 5-1...

  • Page 48: Introduction

    Chapter 5 BIOS Setup 5.1 Introduction The board BE-0961 uses an AMI (American Megatrends Incorporated) Aptio BIOS that is stored in the Serial Peripheral Interface Flash Memory (SPI Flash) and can be updated. The SPI Flash contains the built-in BIOS setup program, Power-On Self-Test (POST), PCI auto-configuration utility, LAN EEPROM information, and Plug and Play support.

  • Page 49: Accessing Setup Utility

    POST message will be displayed: Figure 5-2. POST Screen with AMI Logo Press <Del> or <Esc> to access the Setup Utility program and the Main menu of the Aptio Setup Utility will appear on the screen as below: BE-0961 SERIES USER MANUAL Page: 5-3...
  • Page 50 Chapter 5 BIOS Setup For BayTrail-D Platform BE-0961 SERIES USER MANUAL Page: 5-4...
  • Page 51 English. You may use <↑> or <↓> key to select among the items and press <Enter> to confirm and enter the sub-menu. The following table provides the list of the navigation keys that you can use while operating the BIOS setup menu. BE-0961 SERIES USER MANUAL Page: 5-5...
  • Page 52 Load the previous configuration values. <F3> Load the default configuration values. <F4> Save the current values and exit the BIOS setup menu. Close the sub-menu. <Esc> Trigger the confirmation to exit BIOS setup menu. BE-0961 SERIES USER MANUAL Page: 5-6...

  • Page 53: Main

    Build Date and Time No changeable options Displays the date of current BIOS version. TXE Information No changeable options Displays the GOP driver version. Sec RC Version No changeable options Displays the current Sec RC version. BE-0961 SERIES USER MANUAL Page: 5-7...
  • Page 54 The “Day” is automatically changed. System Time Hour, minute, second Sets the system time. The format is [Hour: Minute: Second]. Users can directly enter values or use <+> or <-> arrow keys to increase/decrease it. BE-0961 SERIES USER MANUAL Page: 5-8...

  • Page 55: Advanced

    CPU Configuration. Parameters. CPU Configuration Sub-Menu IDE Configuration Sub-Menu SATA Configuration Parameters. OS Selection Sub-Menu OS selection settings. Configure Option ROM execution, CSM Configuration Sub-Menu boot options filters, etc.. USB Configuration Sub-Menu USB Configuration Parameters. BE-0961 SERIES USER MANUAL Page: 5-9...

  • Page 56: Advanced - Acpi Settings

    OS. ACPI Sleep State - Suspend Disabled Specifies the ACPI sleep state. - S3 Only (Suspend to RAM) Suspend Disabled disables ACPI sleep feature. S3 allows the platform to enter Suspend to RAM mode. BE-0961 SERIES USER MANUAL Page: 5-10...

  • Page 57: Advanced - F81866 Super Io Configuration

    Serial Port 1 Configuration Sub-Menu Set Parameters for COMA Serial Port 2 Configuration Sub-Menu Set Parameters for COMB Serial Port 3 Configuration Sub-Menu Set Parameters for COMC Serial Port 4 Configuration Sub-Menu Set Parameters for COMD BE-0961 SERIES USER MANUAL Page: 5-11...
  • Page 58 Displays the current settings of Serial Port 1. Change Settings -Auto Allows you to select specific I/O -IO=3F8h; IRQ=4 address and IRQ for Serial Port 1. -IO=3F8h; IRQ=3,4,5,6,7,9,10,11,12 -IO=2F8h; IRQ=3,4,5,6,7,9,10,11,12 -IO=3E8h; IRQ=3,4,5,6,7,9,10,11,12 -IO=2E8h; IRQ=3,4,5,6,7,9,10,11,12 BE-0961 SERIES USER MANUAL Page: 5-12...
  • Page 59 Displays the current settings of Serial Port 2. Change Settings -Auto Allows you to select specific I/O -IO=2F8h; IRQ=3 address and IRQ for Serial Port 2. -IO=3F8h; IRQ=3,4,5,6,7,9,10,11,12 -IO=2F8h; IRQ=3,4,5,6,7,9,10,11,12 -IO=3E8h; IRQ=3,4,5,6,7,9,10,11,12 -IO=2E8h; IRQ=3,4,5,6,7,9,10,11,12 BE-0961 SERIES USER MANUAL Page: 5-13...
  • Page 60 Displays the current settings of Serial Port 3. Change Settings -Auto Allows you to select specific I/O -IO=3E8h; IRQ=7 address and IRQ for Serial Port 3. -IO=3F8h; IRQ=3,4,5,6,7,9,10,11,12 -IO=2F8h; IRQ=3,4,5,6,7,9,10,11,12 -IO=3E8h; IRQ=3,4,5,6,7,9,10,11,12 -IO=2E8h; IRQ=3,4,5,6,7,9,10,11,12 BE-0961 SERIES USER MANUAL Page: 5-14...
  • Page 61 Displays the current settings of Serial Port 4. Change Settings -Auto Allows you to select specific I/O -IO=2E8h; IRQ=10 address and IRQ for Serial Port 4. -IO=3F8h; IRQ=3,4,5,6,7,9,10,11,12 -IO=2F8h; IRQ=3,4,5,6,7,9,10,11,12 -IO=3E8h; IRQ=3,4,5,6,7,9,10,11,12 -IO=2E8h; IRQ=3,4,5,6,7,9,10,11,12 BE-0961 SERIES USER MANUAL Page: 5-15...

  • Page 62: Advanced - Hardware Monitor

    No changeable options Displays processor's temperature. System temperature No changeable options Displays system's temperature. Fan1 Speed No changeable options Displays fan speed. Displays voltage level of the +VCORE VCORE No changeable options in supply. BE-0961 SERIES USER MANUAL Page: 5-16...

  • Page 63: Advanced - F81866 Watchdog

    Advanced - F81866 Watchdog Advanced > F81866 Watchdog Menu Path If the system hangs or fails to respond, enable the F81866 watchdog function to trigger a system reset via the 255-level watchdog timer. F81866 Watchdog Screen BE-0961 SERIES USER MANUAL Page: 5-17...
  • Page 64 Watch Dog timer unit Sets the desired value seconds or - 60s minutes for watchdog timer. Count for Timer multiple options ranging Sets the desired value (seconds) for (Seconds) from 1 to 255 watchdog timer. BE-0961 SERIES USER MANUAL Page: 5-18...

  • Page 65: Advanced - Cpu Configuration

    No changeable options Reports the CPU Signature Socket 0 CPU Information Sub-Menu Report CPU Information CPU Speed No changeable options Reports the current CPU Speed 64-bit No changeable options Reports if 64-bit is supported by processor. BE-0961 SERIES USER MANUAL Page: 5-19...
  • Page 66 BIOS Setting Options Description/Purpose CPU Signature No changeable options Reports the CPU Signature Microcode Patch No changeable options Reports the CPU Microcode Patch Version. Max CPU Speed No changeable options Reports the maximum CPU Speed. BE-0961 SERIES USER MANUAL Page: 5-20...
  • Page 67 Displays size of L1 Data Cache L1 Code Cache No changeable options Displays size of L1 Code Cache L2 Cache No changeable options Displays size of L2 Cache. L3 Cache No changeable options Displays size of L3 Cache. BE-0961 SERIES USER MANUAL Page: 5-21...

  • Page 68: Advanced -Ide Configuration

    SATA Mode - IDE mode Configures SATA as follows: - AHCI mode IDE: Set SATA operation mode to IDE mode. AHCI: SATA works as AHCI (Advanced Host Controller Interface) mode for getting better performance. BE-0961 SERIES USER MANUAL Page: 5-22...
  • Page 69 Displays the drive installed on this SATA Port 0. Shows [Empty] if no drive is installed. SATA Port 1 [drive] Displays the drive installed on this SATA Port 1. Shows [Empty] if no drive is installed. BE-0961 SERIES USER MANUAL Page: 5-23...

  • Page 70: Advanced - Os Selection

    Selects Windows 8.X or Windows 7 - Windows 7 Operating System. OS Selection: For Windows 8.X(64Bit), it is recommended to choose GOP VGA driver instead of Legacy BIOS. Please change settings under Advanced\ CSM\ Configuration\ Video\ select UEFI. BE-0961 SERIES USER MANUAL Page: 5-24...

  • Page 71: Advanced - Csm Configuration

    Selects Gate A20 operation mode. - Always UPON REQUEST: GA20 can be disabled using BIOS services. ALWAYS: do not allow disabling GA20; this option is useful when any RT code is executed above 1MB. BE-0961 SERIES USER MANUAL Page: 5-25...
  • Page 72 Controls the execution of UEFI and - UEFI Legacy Video. - Legacy Other PCI devices - Do not launch Determines OpROM execution policy - UEFI for devices other than Network, Storage, - Legacy or Video. BE-0961 SERIES USER MANUAL Page: 5-26...

  • Page 73: Advanced - Usb Configuration

    USB. XHCI Hand-off - Enabled This is a workaround for OSes without - Disabled XHCI hand-off support. EHCI Hand-off - Disabled This is a workaround for OSes without - Enabled EHCI hand-off support. BE-0961 SERIES USER MANUAL Page: 5-27...
  • Page 74 Delay range is 1..40 seconds, in one in seconds 0 to 40 second increments Mass Storage Devices: - Auto Displays the device name and choose - Floppy the device emulation type. - Force FDD - Hard Disk - CD-ROM BE-0961 SERIES USER MANUAL Page: 5-28...

  • Page 75: Chipset

    This menu allows users to configure advanced Chipset settings such as North Bridge and South Bridge configuration parameters. Chipset Screen BIOS Setting Options Description/Purpose Sets Parameter for Panther Point (North Bridge) North Bridge Sub-Menu configuration. Sets Parameter for Ivy Bridge (South Bridge) South Bridge Sub-Menu configuration. BE-0961 SERIES USER MANUAL Page: 5-29...

  • Page 76: Chipset - North Bridge

    Intel IGD Configuration Sub-Menu Configures Intel IGD Settings. Boot Display Control Sub-Menu Boot Display Control. Memory Information No changeable options Displays the DRAM information on platform. Total Memory No changeable options Displays the DRAM size BE-0961 SERIES USER MANUAL Page: 5-30...
  • Page 77 Enables or Disables GFX Boost accelerated - Disabled graphics processing DVMT Pre-Allocated - 64M Selects DVMT 5.0 Pre-Allocated (Fixed) - 96M Graphics Memory size used by the Internal - 128M Graphics Device. - 256M - 512M BE-0961 SERIES USER MANUAL Page: 5-31...
  • Page 78 - CRT Selects the Video Device which will be activated Display - LVDS during POST. Secondary IGFX Boot - Disabled Selects the Video Device which will be activated Display - CRT during POST. - LVDS BE-0961 SERIES USER MANUAL Page: 5-32...

  • Page 79: Chipset - South Bridge

    Power Off keeps the power off till the - Last State power button is pressed. Power On makes system power on after restores AC power to the board. Last State brings system back to the last power state before AC remove. BE-0961 SERIES USER MANUAL Page: 5-33...
  • Page 80 Enables or Disables per USB Port - Enabled USB Port 0 - Disabled Enables or Disables USB Port 0. - Enabled USB Port 1 - Disabled Enables or Disables USB Port 1. - Enabled BE-0961 SERIES USER MANUAL Page: 5-34...
  • Page 81 PCI Express Configuration Screen BIOS Setting Options Description/Purpose PCI Express Port 0 - Disabled Enables or Disables PCI Express Port 0. - Enabled Hot Plug - Disabled Enables or Disables PCI Express Hot Plug. - Enabled BE-0961 SERIES USER MANUAL Page: 5-35...
  • Page 82 Enabled or Disabled PCI Express Port 3 - Enabled Hot Plug - Disabled Enabled or Disabled PCI Express Hot Plug. - Enabled speed - Auto Selects PCI Express Port 3 speed. - Gen1 - Gen2 BE-0961 SERIES USER MANUAL Page: 5-36...

  • Page 83: Security

    Setup utility. Security Screen BIOS Setting Options Description/Purpose Administrator Password Password can be 3-20 Specifies Administrator password. alphanumeric characters. User Password Password can be 3-20 Specifies User password. alphanumeric characters. BE-0961 SERIES USER MANUAL Page: 5-37...

  • Page 84: Boot

    Number of seconds to wait for setup activation key. Bootup NumLock State - On Specifies the power-on state of the - Off NumLock Key. Quiet Boot - Disabled Enables/Disables Quiet Boot options. - Enabled BE-0961 SERIES USER MANUAL Page: 5-38...
  • Page 85 Sets the order of the legacy devices in Priorities the group. Hard Drive BBS Priorities Screen BIOS Setting Options Description/Purpose Boot Option #1 - #n - [Drive(s)] Changes the boot order of available drive(s). - Disabled BE-0961 SERIES USER MANUAL Page: 5-39...
  • Page 86 Chapter 5 BIOS Setup Network Device BBS Priorities Screen BIOS Setting Options Description/Purpose Boot Option #1 - #n - [Drive(s)] Sets the system boot order. - Disabled BE-0961 SERIES USER MANUAL Page: 5-40...

  • Page 87: Save & Exit

    Discard Changes and Reset to discard any changes you have made and restore the factory BIOS defaults. Load User Defaults You may simply press F3 at any time to load the Optimized Values which resets all BIOS settings to the factory defaults. Save & Exit Screen BE-0961 SERIES USER MANUAL Page: 5-41...
  • Page 88 No changeable options Resets without saving any changes made in BIOS Reset settings. Restore Defaults No changeable options Loads the optimized defaults for BIOS settings. Boot Override - [Drive(s)] Forces to boot from selected [drive(s)]. BE-0961 SERIES USER MANUAL Page: 5-42...

  • Page 89: Appendix A Expansion Bus

    Appendix A EXPANSION BUS This appendix indicates the pin assignments. The following topic is included: • CFast Slot Pin Assignment BE-0961 SERIES USER MANUAL Page: A-1...
  • Page 90 Appendix A Expansion Bus CFAST SLOT PIN ASSIGNMENT You will find a JCFAST2 slot on BE-0961. The pin assignments are as follows: ASSIGNMENT SATA_TXP0 SATA_TXN0 S7 PC1 PC17 SATA_RXN0 JCFAST2 SATA_RXP0 PC10 PC11 PC12 PC13 3.3V/5V PC14 3.3V/5V PC15 PC16...

  • Page 91: Appendix B Technical Summary

    This appendix will give you a brief introduction of the allocation maps for the system resources. The following topics are included: • Block Diagram • Interrupt Map • I/O Map • Memory Map • Configuring WatchDog Timer • Flash BIOS Update BE-0961 SERIES USER MANUAL Page: B-1...
  • Page 92 USB 3.0 USB 3.0 GPIO 4IN/4OUT SATA x1 SATA GEN2 CFAST x1 COM1 SYS FAN (D-SUB 9Pin) (3 Pin) COM2 FINTEK (Pin Header) LPC SIO 81866AD-I COM3 (Pin Header) COM4 (Pin Header) HW monitor BE-0961 SERIES USER MANUAL Page: B-2...

  • Page 93: I/O Map

    Programmable interrupt controller 0x000000AC-0x000000AD Programmable interrupt controller 0x000000B0-0x000000B1 Programmable interrupt controller 0x000000B2-0x000000B3 Motherboard resources 0x000000B4-0x000000B5 Programmable interrupt controller 0x000000B8-0x000000B9 Programmable interrupt controller 0x000000BC-0x000000BD Programmable interrupt controller 0x000002E0-0x000002EF Communications Port (COM4) 0x000002F8-0x000002FF Communications Port (COM2) BE-0961 SERIES USER MANUAL Page: B-3...
  • Page 94 Processor AHCI - 0F23 0x0000E050-0x0000E057 Intel(R) Atom(TM)/Celeron(R)/Pentium(R) Processor AHCI - 0F23 0x0000E060-0x0000E063 Intel(R) Atom(TM)/Celeron(R)/Pentium(R) Processor AHCI - 0F23 0x0000E070-0x0000E077 Intel(R) Atom(TM)/Celeron(R)/Pentium(R) Processor AHCI - 0F23 0x0000E080-0x0000E087 Intel(R) Atom(TM) Processor E3800 Series/Intel(R) Celeron(R) Processor N2920/J1900 BE-0961 SERIES USER MANUAL Page: B-4...
  • Page 95 Processor PCI Express-Root Port3 - 0F4C 0x0000E000-0x0000E01F Intel(R) Atom(TM)/Celeron(R)/Pentium(R) Processor Platform Control Unit - SMBus Port - 0F12 0x0000E020-0x0000E03F Intel(R) Atom(TM)/Celeron(R)/Pentium(R) Processor AHCI - 0F23 0x0000E040-0x0000E043 Intel(R) Atom(TM)/Celeron(R)/Pentium(R) Processor AHCI - 0F23 0x0000E050-0x0000E057 Intel(R) Atom(TM)/Celeron(R)/Pentium(R) BE-0961 SERIES USER MANUAL Page: B-5...
  • Page 96 Appendix B Technical Summary I/O MAP ASSIGNMENT Processor AHCI - 0F23 0x0000E060-0x0000E063 Intel(R) Atom(TM)/Celeron(R)/Pentium(R) Processor AHCI - 0F23 0x0000E070-0x0000E077 Intel(R) Atom(TM)/Celeron(R)/Pentium(R) Processor AHCI - 0F23 0x0000E080-0x0000E087 Intel(R) Atom(TM) Processor E3800 Series/Intel(R) Celeron(R) Processor N2920/J1900 BE-0961 SERIES USER MANUAL Page: B-6...

  • Page 97: Interrupt Map

    (ISA) IRQ 103 Microsoft ACPI-Compliant System (ISA) IRQ 104 Microsoft ACPI-Compliant System (ISA) IRQ 105 Microsoft ACPI-Compliant System (ISA) IRQ 106 Microsoft ACPI-Compliant System (ISA) IRQ 107 Microsoft ACPI-Compliant System (ISA) IRQ 108 Microsoft ACPI-Compliant System BE-0961 SERIES USER MANUAL Page: B-7...
  • Page 98 (ISA) IRQ 138 Microsoft ACPI-Compliant System (ISA) IRQ 139 Microsoft ACPI-Compliant System (ISA) IRQ 140 Microsoft ACPI-Compliant System (ISA) IRQ 141 Microsoft ACPI-Compliant System (ISA) IRQ 142 Microsoft ACPI-Compliant System (ISA) IRQ 143 Microsoft ACPI-Compliant System BE-0961 SERIES USER MANUAL Page: B-8...
  • Page 99 (ISA) IRQ 173 Microsoft ACPI-Compliant System (ISA) IRQ 174 Microsoft ACPI-Compliant System (ISA) IRQ 175 Microsoft ACPI-Compliant System (ISA) IRQ 176 Microsoft ACPI-Compliant System (ISA) IRQ 177 Microsoft ACPI-Compliant System (ISA) IRQ 178 Microsoft ACPI-Compliant System BE-0961 SERIES USER MANUAL Page: B-9...
  • Page 100 Processor PCI Express - Root Port4 - 0F4E (PCI) IRQ 22 High Definition Audio Controller (PCI) IRQ -3 Intel(R) USB3.0 eXtensible Host Controller (PCI) IRQ -2 Intel(R) Atom(TM) Processor E3800 Series/Intel(R) Celeron(R) Processor N2920/J1900 BE-0961 SERIES USER MANUAL Page: B-10...
  • Page 101 (ISA) IRQ 125 Microsoft ACPI-Compliant System (ISA) IRQ 126 Microsoft ACPI-Compliant System (ISA) IRQ 127 Microsoft ACPI-Compliant System (ISA) IRQ 128 Microsoft ACPI-Compliant System (ISA) IRQ 129 Microsoft ACPI-Compliant System (ISA) IRQ 130 Microsoft ACPI-Compliant System BE-0961 SERIES USER MANUAL Page: B-11...
  • Page 102 (ISA) IRQ 156 Microsoft ACPI-Compliant System (ISA) IRQ 157 Microsoft ACPI-Compliant System (ISA) IRQ 158 Microsoft ACPI-Compliant System (ISA) IRQ 159 Microsoft ACPI-Compliant System (ISA) IRQ 160 Microsoft ACPI-Compliant System (ISA) IRQ 161 Microsoft ACPI-Compliant System BE-0961 SERIES USER MANUAL Page: B-12...
  • Page 103 (ISA) IRQ 187 Microsoft ACPI-Compliant System (ISA) IRQ 188 Microsoft ACPI-Compliant System (ISA) IRQ 189 Microsoft ACPI-Compliant System (ISA) IRQ 190 Microsoft ACPI-Compliant System (PCI) IRQ 10 Ethernet Controller (PCI) IRQ 11 Ethernet Controller BE-0961 SERIES USER MANUAL Page: B-13...
  • Page 104 Processor PCI Express - Root Port4 - 0F4E (PCI) IRQ 22 High Definition Audio Controller (PCI) IRQ -3 Intel(R) USB3.0 eXtensible Host Controller (PCI) IRQ -2 Intel(R) Atom(TM) Processor E3800 Series/Intel(R) Celeron(R) Processor N2920/J1900 BE-0961 SERIES USER MANUAL Page: B-14...

  • Page 105: Memory Map

    Intel(R) Atom(TM)/Celeron(R)/Pentium(R) 0x92214000-0x9221401F Processor Platform Control Unit - SMBus Port - 0F12 0x92216000-0x922167FF Intel(R) Atom(TM)/Celeron(R)/Pentium(R) Processor AHCI - 0F23 0xE0000000-0xEFFFFFFF Motherboard resources 0xE00000D0-0xE00000DB Intel(R) Atom(TM)/Celeron(R)/Pentium(R) Processor MBI Device - 33BD 0xFED00000-0xFED003FF High precision event timer BE-0961 SERIES USER MANUAL Page: B-15...
  • Page 106 Appendix B Technical Summary MEMORY MAP ASSIGNMENT 0xFED01000-0xFED01FFF Motherboard resources 0xFED03000-0xFED03FFF Motherboard resources 0xFED04000-0xFED04FFF Motherboard resources 0xFED08000-0xFED08FFF Motherboard resources 0xFED0C000-0xFED0FFFF Motherboard resources 0xFED1C000-0xFED1CFFF Motherboard resources 0xFEE00000-0xFEEFFFFF Motherboard resources 0xFEF00000-0xFEFFFFFF Motherboard resources 0xFF000000-0xFFFFFFFF Intel(R) 82802 Firmware Hub Device BE-0961 SERIES USER MANUAL Page: B-16...

  • Page 107: Watchdog Timer Configuration

    To exit the Extended Function Mode, writing 0xAA to the EFER is required. Once the chip exits the Extended Function Mode, it is in the normal running mode and is ready to enter the configuration mode. BE-0961 SERIES USER MANUAL Page: B-17...
  • Page 108 ;------ Select Logical Device 7 of watchdog timer -------------------------------------------- ;------ Enable Watch dog feature ----------------------------------------------------------------- 030h ;------ Enable Watch PME------------------------------------------------------------------------- 0FAh ;------ Set second as counting unit ---------------------------------------------------------------- 0f5h ;------ Set timeout interval as 30seconds and start counting --------------------------------- 0f6h BE-0961 SERIES USER MANUAL Page: B-18...
  • Page 109 Appendix B Technical Summary ;------ Exit the extended function mode --------------------------------------------------------- 0aah BE-0961 SERIES USER MANUAL Page: B-19...

  • Page 110: Flash Bios Update

    System will go into the BIOS setup menu. d. Select [Boot] menu. e. Select [Hard Drive BBS Priorities], set the USB bootable device to be the 1 boot device. Press <F4> key to save configuration and exit the BIOS setup menu. BE-0961 SERIES USER MANUAL Page: B-20...
  • Page 111 Appendix B Technical Summary BE-0961 SERIES USER MANUAL Page: B-21...
  • Page 112 AFUDOS /? to see all the definition of each control options. The recommended options for BIOS ROM update consist of following parameters: program main BIOS image program Boot Block program NVRAM don’t check ROM ID BE-0961 SERIES USER MANUAL Page: B-22...
  • Page 113 Restart the system and boot up with the new BIOS configurations. The BIOS Update is completed after the system is restarted. Reboot the system and verify if the BIOS version shown on the initialization screen has been updated. BE-0961 SERIES USER MANUAL Page: B-23...
  • Page 114 Appendix B Technical Summary ® ® Intel 4th Gen. Celeron E3000 series screen: ® Intel 4th Gen. Atom N2000 series screen: BE-0961 SERIES USER MANUAL Page: B-24...
